Icon 1.75-2.25″ Coilover Conversion System For 2020 Ford F-250 4WD (Stage 4)

Description

Icon 1.75-2.25″ Coilover Conversion System For 2020 Ford F-250 4WD (Stage 4)

Part: K63144

ICON’s 2.5 VS Series Remote Reservoir Bolt-In Coilover Conversion Kit will add a new level of performance and adjustability to 2017-UP F-250 and F-350 trucks. The advantage of utilizing a coilover conversion kit is that they have been designed to increase the overall damping ability of the vehicle while at the same time allowing for user-defined ride height adjustment. The 2.5″ Remote Reservoir Coilover featured in these kits is based off of ICON’s 2.5 VS Series shock line – meaning that features like Eibach coil springs, FK Rod End bearings, and vehicle-specific valving come standard. Quality machined components and a fully serviceable design make for a product that will stand the test of time, yet retain the ability to be rebuilt or re-valved as necessary.

KEY FEATURES:

• Bolt-in system fits in OE coil bucket location
• Ride height adjustable coilovers (1.75-2.25″)
• Decreased body roll and improved on and off-road ride dynamics
• Vehicle-specific shock valving provides unparalleled ride quality and control
• Shocks are fully rebuildable and revalveable
• Coilover conversion allows for addition of secondary shock
• Corrosion resistant CAD plated coilover shock body with 7/8″ shaft
• Eibach coil springs guaranteed for life against sagging or breakage
• FK Rod End bearings for extended longevity and minimal deflection

WHEEL & TIRE FITMENT INFO:

OEM Wheels & Tires: Yes

Aftermarket Wheels: 8.5″ Wide, 5″ Backspace

Aftermarket Tires: 35 x 12.50

(Larger Tires May Fit but Fender Trimming and Modifications will be Required)

SYSTEM COMPONENTS:

61720C (QTY.1) | 05-UP FSD 4WD 1.75-2.25″ 2.5 VS RR CDCV BOLT IN CO CONVERSION KIT

64038 (QTY.1) | 17-UP FSD ADJ TRACK BAR KIT

65000 (QTY.1) | 05-UP FSD DUAL STABILIZER KIT

36511 (QTY.2) | 99-UP FSD 4WD STABILIZER (DUAL OPPOSING) 2.0 VS IR

37705CP (QTY.1) | 99-UP FSD 0-3″ REAR 2.5 VS PB CDCV PAIR
