ARB CS004F Pair of Front Leaf Springs 2″ Lift for 1980, 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989 Toyota Land Cruiser

Part: 2xCS004F

Part of ARB’s integrated 4×4 suspension systems, Emu Dakar leaf springs are engineered to provide optimum ride performance irrespective of the operating conditions the vehicle’s suspension is required to work under. Numerous spring options are available to suit a multitude of applications, allowing you to set your vehicle up for recreational or commercial purposes. Feature packed, a set of Emu Dakar leaf springs matched to a set of Old Man Emu 4×4 shock absorbers will deliver vastly improved ride, handling and load carrying capability.
Number Of Leafs: 6 Leaf
Quantity: Pair
Spring Rate: 257 Pounds Per Inch
Spring Type: Draw Tapered And Diamond Cut
Includes Bushings: No

Bushing Material: No Bushing



Features:
  • Draw Tapered And Diamond Cut Leaves: Ensure The Load Is Progressively Distributed Over A Larger Surface Area, Reducing The High Stresses That Develop At Leaf Ends
  • Fully Scragged And Load Tested: Scragging Ensures The Spring Takes A Permanent ‘Set’ Which Reduces The Risk Of Sagging
  • Graphite Coating: To Further Reduce The Friction Between The Spring Leaves And Friction Pads
  • Military Wrap: Designed To Provide Added Safety
  • Anti Friction Pads: Regreasable Nylon Interleaf Liners Reduce Friction At The Leaf Tips Where The Load Is The Greatest
  • Flat Axle Seat Area: Allows A Positive, Safe Axle Mount Reducing Spring Stress And Increasing Spring Life
  • Shot Peening: The Tension Side Of All Leaves Is Shot Peened To Reduce Spring Stress, This Process Can Double The Life Of A Spring
  • Limited 3 Year Or 60,000 Kilometer Warranty

Fits:

  • PATROL GQ Y60 UTE & CAB CHASSIS LEAF SPRING MODELS (FRONT) (4.2 ENGINE)
    (CBS02 x 2 centre bolt spacers required for front spring fitment.)
    Estimated Lift: 30mm
  • LANDCRUISER 60, 61 & 62 SERIES (FRONT)
    (Front bump stop measurement must not exceed 100mm to ensure good shackle angle. To reduce bump stop gap, remove the 4th leaf from the top of the spring. OMECW2 Caster Wedge Kit may be required to restore correct caster angle.)
    (Shackles: FK08 Anti Inversion Kit is mandatory fitment if greasable shackles are not fitted. Refer OME Technical & Fitting Manual.)
    (D1XL only suitable for CS003F & CS004F.)
    Estimated Lift: 50mm
1274

on

ARB OMEU63 Old Man Emu Rear U Bolts for Nissan Navara D21 & D22

Part: 4xOMEU63

The OME range doesn’t just stop with shocks, springs and bushes. At ARB we take integration to the highest level with our own range of U bolts, center bolts, spring liners, trim packers, and suspension fitting kits.
Inner Length (IN): 7.480 Inch
Inner Width Between Center of the Bolts (IN): 2.91 Inch
Shape: Square

Thread Size: 12 Millimeter X 1.25



Features:
  • Limited 3 Year Or 60,000 Kilometer Warranty

Fits:

  • NAVARA D22 10/2002 ON ALL MODELS (Rear)
    NP300 2008 TO 2014 ALL MODELS (Rear)
  • NAVARA D21 & D22 TO 8/2002 ALL MODELS (Rear)
448

on

ARB OMEU53 Old Man Emu Rear U Bolts for Toyota Hilux/Pickup/4Runner

Part: 4xOMEU53

The OME range doesn’t just stop with shocks, springs and bushes. At ARB we take integration to the highest level with our own range of U bolts, center bolts, spring liners, trim packers, and suspension fitting kits.
Inner Length (IN): 6.614 Inch
Inner Width Between Center of the Bolts (IN): 2.95 Inch
Shape: Square

Thread Size: 14 Millimeter X 1.5



Features:
  • Limited 3 Year Or 60,000 Kilometer Warranty

Fits:

  • TRITON / L200 MQ ALL 4X4 MODELS (Rear)
    (Use OMEU53 when fitting EL086R.)
    Estimated Lift: 20mm
  • HILUX & 4 RUNNER PRE 1997 ALL LEAF SPRING MODELS (Rear)
    Estimated Lift: 50mm
  • HILUX PRE 1997 EXTRA CAB & DUAL CAB SR5 (Rear)
    IFS & REAR LEAF MODELS
    (Compare original spring stack height to OME spring stack to decide whether OMEU53 or OMEU53B U bolts are required.)
    Estimated Lift: 50mm
  • 4 RUNNER 1986 TO 1990 (TO 1989 IN USA) (Rear)
    IFS REAR LEAF SPRING MODELS
    (Compare original spring stack height to OME spring stack to decide whether OMEU53 or OMEU53B U bolts are required.)
    Estimated Lift: 50mm
2801
