ARB 2882 Set of 2 Front Old Man Emu Coil Springs for 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002 Toyota Prado 90 Series LWB Diesel

Part: 2882

Product Specs:
Product Type: Coil Spring
Material: X5K Steel
Vehicle Placement: Front
Spring: 51-110Kgs
Estimated Lift: 40 mm
Bar Diameter: 16.5 mm
Free Height A: 395 mm
Free Height B: 395 mm
Number of Turns: 11.1
Coil Weight: 5.3 kg
Spring Rate: 500 lbf/in
Spring Rate: 87 N/mm
OE Spring Rate: 490 lbs

Product Description:
Old Man Emu (OME) designs a range of coil springs individually tailored to each vehicle make and model, and that vehicle’s load carrying capacity. OME coils springs generally provide a 1/2 to 3 inch suspension lift, depending on the model, but they are not actually designed around achieving a particular lift height. They are designed around providing ideal handling and control for the vehicle and the particular load you’re carrying. The lift height is more of a side effect than an aim and we choose to do this so that you can have the safest and most controlled handling combined with the most comfortable ride. OME coils are the ideal way to handle all of the additional weight you pack into your vehicle when heading out for your next adventure. Further fine tuning for your vehicle suspension system can be achieved when the springs are matched to a corresponding set of Old Man Emu shock absorbers, delivering a fully integrated system, designed specifically to suit your vehicle. A four-wheel drive equipped with an OME Suspension combination will exhibit better towing and load carrying characteristics, improved wheel travel, and will ride and handle better over any road or trail surface.

Features:
Durable powder coat finish
Springs are formed on precision mandrels
Scragging before and after shot peening to prevent sagging
Constant and variable rate coils available for multiple applications
Easy installation. Can directly replace the OE components, no custom installation required
Coil spring end configurations designed to exact specifications guaranteeing perfect fit to your vehicle

Additional Information:
Coil Springs – A & B springs are used to compensate for uneven vehicle weight distribution. ‘A’ type springs are generally higher in free high than the ‘B’ spring
X5K Micro-Alloyed Spring Steel – New generation high strength spring steel grade designed to withstand higher operating stresses with superior resistance to sag and improved toughness and corrosion fatigue properties
Lift Height – Is shown as a guide only and equates to the amount of lift over the vehicle’s original ride height. This amount can vary from vehicle to vehicle
Shot Peened – To reduce stress, which greatly enhances spring life
Double Scragged – To eliminate spring sag
Variable and Constant Rate – Designs used to obtain optimum ride comfort and load carrying capabilities
Load Rating Front: Weights shown are maximum permissible loads with regard to accessories fitted, eg. Bull bar, winch, dual battery, etc..
Load Rating Rear – The explanations below indicates the passenger and load weights that will provide optimum ride and handling
Light Load: Full passenger load with luggage weights up to 150kg
Medium Load: Full passenger load with weight varying from 200kg to 300kg
Constant Load: The minimum constant load is required for optimum spring performance
*Note: These loads are approximate only

Complete Fitment List:
Toyota Prado 90 Series 1985-10/2002 LWB Diesel Engine
