ARB CS038R Pair of 1.5″ Rear Lift Old Man EMU Leaf Springs for 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995 Suzuki Samurai

Part: 2xCS038R

Part of ARB’s integrated 4×4 suspension systems, Emu Dakar leaf springs are engineered to provide optimum ride performance irrespective of the operating conditions the vehicle’s suspension is required to work under. Numerous spring options are available to suit a multitude of applications, allowing you to set your vehicle up for recreational or commercial purposes. Feature packed, a set of Emu Dakar leaf springs matched to a set of Old Man Emu shocks will deliver vastly improved ride, handling and load carrying capability.
Number Of Leafs: 5
Quantity: Pair
Spring Rate: 171/ 291 Pounds Per Inch
Spring Type: Draw Tapered And Diamond Cut
Includes Bushings: No
Bushing Material: No Bushing
Features:
  • Draw Tapered And Diamond Cut Leaves: Ensure The Load Is Progressively Distributed Over A Larger Surface Area, Reducing The High Stresses That Develop At Leaf Ends, Provides Increased Ride Quality
  • Fully Scragged And Load Tested: Scragging Ensures The Spring Takes A Permanent ‘Set’ Which Reduces The Risk Of Sagging, Load Testing Ensures The Spring Meets The Required Specification
  • Two-Stage Leaf Pack: Featured On Most Rear Springs For Optimum Comfort, Unladen The Vehicle Is Largely Riding On The Primary Stage, With The Secondary Stage Providing Additional Support
  • Military Wrap: Designed To Provide Added Safety. Shot Peening: The Tension Side Of All Leaves Is Shot Peened To Reduce Spring Stress, Process Can Double The Life Of A Spring
  • Anti Friction Pads: Regreasable Nylon Interleaf Liners Reduce Friction At The Leaf Tips Where The Load Is The Greatest
  • Flat Axle Seat Area: Allows A Positive, Safe Axle Mount Reducing Spring Stress And Increasing Spring Life
  • Bolt Clamps And Liners: The Leaf Clamps Are Bolted To Allow Installation Of Anti Squeak Nylon Liners
  • Limited 2 Year Warranty

Fits:

  • DROVER ALL MODELS (NOT USA MANUFACTURED MODEL)
    (Rear)
    Estimated Lift: 40mm
  • SIERRA / SAMURAI ALL LEAF SPRING MODELS (SJ413)
    (Rear)
    Estimated Lift: 40mm
    STD TRACK : 1984 – 1988 WIDE TRACK : 1988 – 1996
    SJ50 – SWB SJ70 – SWB (also fits MG410)
    SJ51 – LWB SJ71 – LWB (also fits MG410WT)
    Note: MG410 & MG10WT are Indian built LWB Models.
  • SANTANA SAMURAI TO 2004 SWB MODELS
    (Rear)
    Estimated Lift: 40mm
    Front: LHS: OMEU60 x 2, RHS: OMEU61B x 2 required when fitting CS013FA/B
    Rear: OMEU60 x 4 required when fitting CS039R
3286

on

ARB 2850 Black 2″ Front Lift Old Man Emu Front Coil Springs for 1991, 1992, 1993, 1994, 1995, 1996, 1997 Toyota Landcruiser 105 & 80 Series Wagons

Part: 2850

Old Man Emu (OME) designs a range of coil springs individually tailored to each vehicle make and model, and that vehicle’s load carrying capacity. OME coils springs are designed around providing ideal handling and control for the vehicle and the particular load you’re carrying. The lift height is more of a side effect than an aim and we choose to do this so that you can have the safest and most controlled handling combined with the most comfortable ride. OME coils are the ideal way to handle all of the additional weight you pack into your vehicle when heading out for your next adventure. Further fine tuning for your vehicle suspension system can be achieved when the springs are matched to a corresponding set of Old Man Emu shock absorbers, delivering a fully integrated system, designed specifically to suit your vehicle.
Lift Height (IN): 2 Inch
Free Length (IN): 19-1/2 Inch
Spring Rate: 220 Pounds Per Square Inch
Finish: Powder Coated
Color: Black
Material: Steel
Quantity: Set Of 2
Features:
  • Springs Are Formed On Precision Mandrels
  • Scragging Before And After Shot Peening To Prevent Sagging
  • Coil Spring End Configurations Designed To Exact Specifications Guaranteeing Perfect Fit
  • Durable Powder Coat Finish
  • Easy Installation. Can Directly Replace The OE Components, No Custom Installation Required
  • Limited 3 Year Or 60,000 Kilometer Warranty

Fits:

  • LANDCRUISER 105 SERIES & 80 SERIES WAGONS (FRONT)
    LIVE AXLE FRONT SUSPENSION MODELS
    Estimated Lift: 10 – 50mm

NOTE:

For Models built from 8/1991 add 20mm to lift height shown which is based on average for petrol and diesel engines.

1330

on

ARB 2″ Rear Lift EL096R Medium-Heavy Duty Pair Leaf Springs for 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023 Toyota Tacoma

Part: 2xEL112R

new part: EL112R

Includes:

  • 2 Springs

Bushings, Ubolts are NOT included



  • Provides approximately 2″ of lift with constant 300 KGS/661 LBS load
  • **Requires new longer rear U-bolts, not included.
    • Recommend 7 1/2″ U-bolts for most applications
7288

on

ARB CS003F Old Man Emu Front Leaf Springs for 1980-1998 Nissan Patrol  (Pair)

Part: 2xCS003F

Part of ARB’s integrated 4×4 suspension systems, Emu Dakar leaf springs are engineered to provide optimum ride performance irrespective of the operating conditions the vehicle’s suspension is required to work under. Numerous spring options are available to suit a multitude of applications, allowing you to set your vehicle up for recreational or commercial purposes. Feature packed, a set of Emu Dakar leaf springs matched to a set of Old Man Emu 4×4 shock absorbers will deliver vastly improved ride, handling and load carrying capability.
Number Of Leafs: 5 Leaf
Quantity: Pair
Spring Rate: 220 Pounds Per Inch
Spring Type: Draw Tapered And Diamond Cut
Includes Bushings: No
Bushing Material: No Bushing
Features:
  • Draw Tapered And Diamond Cut Leaves: Ensure The Load Is Progressively Distributed Over A Larger Surface Area, Reducing The High Stresses That Develop At Leaf Ends
  • Fully Scragged And Load Tested: Scragging Ensures The Spring Takes A Permanent ‘Set’ Which Reduces The Risk Of Sagging
  • Graphite Coating: To Further Reduce The Friction Between The Spring Leaves And Friction Pads
  • Military Wrap: Designed To Provide Added Safety
  • Anti Friction Pads: Regreasable Nylon Interleaf Liners Reduce Friction At The Leaf Tips Where The Load Is The Greatest
  • Flat Axle Seat Area: Allows A Positive, Safe Axle Mount Reducing Spring Stress And Increasing Spring Life
  • Shot Peening: The Tension Side Of All Leaves Is Shot Peened To Reduce Spring Stress, This Process Can Double The Life Of A Spring
  • Limited 3 Year Or 60,000 Kilometer Warranty

Fits:

  • (1988-1998) PATROL GQ Y60 UTE & CAB CHASSIS LEAF SPRING MODELS (4.2 ENGINE)
    (CBS02 x 2 centre bolt spacers required for front spring fitment.)
    FRONT Estimated Lift: 1.2 inch
  • (1980-1989) LANDCRUISER 60, 61 & 62 SERIES  (Petrol Engine)
    (Front bump stop measurement must not exceed 100mm to ensure good shackle angle. To reduce bump stop gap, remove the 4th leaf from the top of the spring. OMECW2 Caster Wedge Kit may be required to restore correct caster angle.)
    (Shackles: FK08 Anti Inversion Kit is mandatory fitment if greasable shackles are not fitted. Refer OME Technical & Fitting Manual.)
    (D1XL only suitable for CS003F & CS004F.)
    FRONT Estimated Lift: 2 inch
551
