Icon 0-3″ Lift Coilovers For 2004, 2005, 2006, 2007, 2008 Ford F-150 2WD

Part: 91500

Overview:

ICON Vehicle Dynamics V.S. Series 2.5” coilover shocks are an incredible upgrade for the front end of 2004-2008 Ford F-150 2WD trucks. ICON’s Vehicle-specific valving provide a sport tuned feel on and off-road while 0-3”  lift height adjustability allows the use of larger, more aggressive wheel and tire combinations. The larger 2.5” shock body and increased piston area over stock components provides improved damping ability and outstanding ride characteristics across varying types of terrain.  When paired with ICON rear 2.0 Aluminum Series or 2.5 Series shocks vehicle control will be balanced front to rear, resulting in the best overall driving experience for your F-150 truck.

Key Features:

• Increased wheel travel and ride quality over stock

• Vehicle specific tuned for superior shock damping and control

• Adjustable 0-3″ lift height

• ICON engineered Eibach Springs

• 6061 Aircraft grade aluminum CNC machined components

• Corrosion resistant CAD plated shock body with 7/8 polished nitro steel shaft

• FK rod end bearings for extended longevity and minimal deflection

• 100% Bolt-on – no drilling,cutting or welding necessary for installation

• Made in the USA

System Components Included:

• (2) 2.5″ Coilover Shocks with Coils

• Necessary hardware

• Installation Instructions

Options:

198000    Universal 2 Pin Spanner Wrench

191009      ICON Shock Wraps – Neoprene Coilover Shock Protection Covers

ICON 2 pin Spanner Wrench – ALL ICON Coilover Shocks, ICON Shock Wraps Neoprene Coil Over Shock Protection Covers (large)

744

on

Icon Delta Joint Tubular Upper Control Arm Kit For 2015, 2016, 2017, 2018, 2019, 2020 Chevy/GMC Colorado/Canyon

Part: 78650DJ

OVERVIEW:

Take the performance of your 2015-UP GM Colorado/Canyon to new levels with the ICON Vehicle Dynamics Delta Joint tubular upper control arm kit. All ICON tubular upper control arms are constructed from CNC bent 1026 DOM steel tubing and then powder coated to a semi-gloss black finish for maximum strength and corrosion resistance. ICON upper control arms are engineered with built-in caster correction for optimal alignment specifications and confidence inspiring handling. A main benefit of ICON upper control arms is the potential for increased wheel travel when paired with our 2.5 series coilovers, this translates into superior performance and ride quality for your 2015-UP GM Colorado/Canyon.

These upper control arms feature ICON’s patent pending Delta Joint. The Delta Joint is a heavy duty high angle ball joint that combines the durability of a ball joint with the performance characteristics of a traditional uniball. While the industry standard uniball does a great job of allowing the control arms of a vehicle to articulate with little bind, they do have an inherent weakness that leaves more to be desired when used in a daily driven application – exposure to the elements. The Delta Joint features a zinc plated housing providing the first layer of corrosion resistance, while a tough grease seal keeps potentially harmful elements out of the inner workings of the joint. Metal on metal construction and a greasable design increase the longevity of the Delta Joint while at the same time allowing for noise-free operation. What makes the Delta Joint unique is that it brings the best of both worlds to ICON upper control arms with features that make it more robust than a uniball, and at the same time capable of greater angularity than a typical ball joint.

KEY FEATURES:

• ICON Delta Joint

• 1026 DOM Steel Construction

• CNC Bent Tubing

• Serviceable Dual Stage Bushings

• CNC Machined Bushing Housings and Sleeves

• Built-In Caster Correction

• Black Semi-Gloss Powder Coat Finish

TECH INFO:

Fits 2WD & 4WD Applications

WHEEL & TIRE FITMENT INFO:

Factory Wheels & Tires: Yes

Aftermarket Wheels & Tires: 17″ or larger wheels with max 5.00″ back space.

KIT COMPONENTS:

• Tubular Delta Joint Control Arms

• Dual Stage Bushing Kit

• Necessary Hardware

• Installation Instructions

OPTIONS:

• 191011 – ICON Tubular Upper Control Arm Dust Cover

ICON Tubular Uniball Upper Control Arm Billet Cover Caps

2092

on

Icon Delta Joint Tubular Upper Control Arm Kit (Small Taper) For 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016 Chevy/GMC 1500

Part: 78600DJ

OVERVIEW:

Take the performance of your 2007-2016 GM 1500 truck to new levels with the ICON Vehicle Dynamics Delta Joint tubular upper control arm kit. All ICON tubular upper control arms are constructed from CNC bent 1026 DOM steel tubing and then powder coated to a semi-gloss black finish for maximum strength and corrosion resistance. ICON upper control arms are engineered with built-in caster correction for optimal alignment specifications and confidence inspiring handling. A main benefit of ICON upper control arms is the potential for increased wheel travel when paired with our 2.5 series coilovers, this translates into superior performance and ride quality for your 2007-2016 GM 1500.

These upper control arms feature ICON’s patent pending Delta Joint. The Delta Joint is a heavy duty high angle ball joint that combines the durability of a ball joint with the performance characteristics of a traditional uniball. While the industry standard uniball does a great job of allowing the control arms of a vehicle to articulate with little bind, they do have an inherent weakness that leaves more to be desired when used in a daily driven application – exposure to the elements. The Delta Joint features a zinc plated housing providing the first layer of corrosion resistance, while a tough grease seal keeps potentially harmful elements out of the inner workings of the joint. Metal on metal construction and a greasable design increase the longevity of the Delta Joint while at the same time allowing for noise-free operation. What makes the Delta Joint unique is that it brings the best of both worlds to ICON upper control arms with features that make it more robust than a uniball, and at the same time capable of greater angularity than a typical ball joint.

KEY FEATURES:

• ICON Delta Joint

• 1026 DOM Steel Construction

• CNC Bent Tubing

• Serviceable Dual Stage Bushings

• CNC Machined Bushing Housings and Sleeves

• Built-In Caster Correction

• Black Semi-Gloss Powder Coat Finish

TECH INFO:

Fits 2WD & 4WD Applications

Only fits trucks with small spindle taper

WHEEL & TIRE FITMENT INFO:

Factory Wheels & Tires: Yes

Aftermarket Wheels & Tires: 17″ or larger wheels with max 5.00″ back space.

KIT COMPONENTS:

• Tubular Delta Joint Control Arms

• Dual Stage Bushing Kit

• Necessary Hardware

• Installation Instructions

OPTIONS:

• 191011 – ICON Tubular Upper Control Arm Dust Cover

ICON Tubular Uniball Upper Control Arm Billet Cover Caps

1280

on

Icon 6-8″ Front Lift V.S. 2.5 Series Extended Travel Piggyback Reservoir CDCV Shocks For 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018 Chevy/GMC 2500/3500

Part: 77738CP

OVERVIEW:

ICON Vehicle Specific (V.S.) 2.5 Series shocks are designed and built to give your vehicle outstanding performance off-road and a smooth ride on the street. These shocks are configured specifically for each application in both length and damping tune. Like all ICON shock absorbers, V.S. 2.5 Series shocks are 100% rebuildable and 100% revalveable. For piggyback and specific remote reservoir applications; ICON’s unique use of a 6061 billet aluminum manifold a few inches below the top cap of the shock creates an internal “Bump Zone” that when used creates an additional 20% of damping force. This additional force helps prevent harsh bottom outs and controls the suspension when compressing at high velocity. The ICON CDC Valve is an externally adjustable valve that restricts oil flow into the reservoir which creates 10 levels of compression damping force ranges. If you are looking for a more user defined tune, consider looking into the OMEGA Series bypass shocks.

KEY FEATURES:

  • ICON’s CDC Valve technology allows for 10 levels of high-resolution compression adjustability with the turn of a knob
  • ICON’s internal “Bump Zone” increases damping by 20% to provide more control as the shock approaches full compression
  • Remote reservoir design improves heat dissipation to reduce shock fade during prolonged use
  • Premium grade 5WT shock oil for consistent suspension damping along a wide temperature range
  • Nitrogen charged monotube design with piggyback reservoir
  • One piece digressive piston design with vehicle specific valving for unsurpassed performance and ride quality on and off-road
  • 7/8” diameter induction hardened, chrome plated shock shaft
  • Polyurethane bushings and forged steel mounting stems for OE factory type fitment
  • PTFE lined spherical bearings and application specific mounting hardware
  • 6061 aircraft grade aluminum CNC machined components
  • CAD plated, precision machined 1026 DOM steel shock body for maximum durability and corrosion resistance
  • 100% Rebuildable
  • 100% Revalveable
  • Made in the U.S.A.

TECH NOTES:

  • Require installation of uniball upper control arms (ICON part # 78500)

NOTES:

  • ICON V.S. 2.5 Series shocks are sold in pairs
  • Price listed is for two (2) shock absorbers
713
