FOX 3″ Suspension Lift Kit for 2003, 2004, 2005, 2006, 2007, 2008, 2009 Toyota 4Runner



Kit includes:

  • 883-06-130 – FOX 2.5 Factory Series 0-3″ Lift Front Extended Travel Coil-Over Reservoir with DSC Adjuster. Preset at approximately 2″ of lift from factory. Before any of FOX shocks reach production, they’ve had to stand the test of time and live up to incredible abuse by the fastest athletes in racing. FOX pushes the boundaries to give you that same precise control and race-proven performance you can feel. FOX bolt-on Factory Race Series Coil-over Reservoir shocks provide improved damping in any terrain.Coil-over shocks provide suspension damping and suspend the weight of the vehicle. The integrated coil spring can be adjusted for preload and ride height and come pre-set to level your vehicle right out of the box. Experience for yourself the incredible performance and precise control that Factory Series Coil-over Reservoir shocks deliver.
    Body 2.5″ Smooth bore and honed seamless alloy body
    Body Plating Zinc-plated and double-clear coated for long lasting finish
    External Reservoir 2.5″ Smooth bore and honed seamless alloy reservoir
    Components Black-anodized, CNC-machined 6061-T6 billet aluminum
    Spring Application specific, adjustable 3.0 Eibach® racing springs
    Shaft 7/8″ hard chrome plated steel shafts
    Piston 6061-T6 hard-anodized, high flow aluminum piston
    Valving Application specific valving to maximize performance
    Seals Redundant sealing pack system main seal, wiper seal, scraper seal
    Oil JM92 Advanced Suspension Fluid for improved performance at variable temperatures
    Bearing PTFE-lined, heat-treated, alloy steel spherical
    Mounting Direct replacement for stock and aftermarket lifts kits
    Adjustments
    • Ride height preload ring



  • 985-26-118 – FOX 2.0 Performance Series Reservoir 2-3″ Rear Lift Shocks with CD AdjusterThe aluminum bodied 2.0 Performance Series Reservoir smooth body shock delivers FOX’s industry leading and race dominating performance in an affordable, hassle-free bolt on package. Its heat reducing design includes a metal impacted clear anodized aluminum shock body that dissipates heat faster than a conventional steel body shock.Its external reservoir allows for increase oil and nitrogen capacity while delivering striking race look. The included black anodized reservoir mounting clamp and other components are CNC machined from 6061-T6 aluminum. The race developed high flow damping piston matched with application specific vavling provides the 2.0 Performance Series Reservoir shock a predicable ride quality capable of handling the roughest road conditions.
    Body 2.0″ Metal impacted 6061-T6 aluminum will resist rust over time
    Body Plating Clear-anodized for a durable finish
    External Reservoir 2.0″ Smooth bore 6061-T6 Aluminum is hard anodized
    Components Black-anodized, CNC-machined 6061-T6 billet aluminum
    Shaft 5/8″ hard chrome plated heat-treated alloy steel
    Piston Race-developed high-flow piston design
    Valving Application specific valving to maximize performance
    Seals Redundant sealing pack system main seal, wiper seal, scraper seal
    Oil JM92 Advanced Suspension Fluid for improved performance at variable temperatures
    Bushings Quiet nitrile rubber allows for increased suspension articulation
    Mounting Direct replacement for stock and aftermarket lifts kits
    Options
    • Compression Damping (CD) Adjuster (Included)



  •    OME 2″ Rear Coils
  •  ICON Delta Joint Tubular UCAS 58451DJ:

    FEATURES & BENEFITS

    • ICON Delta Joint
    • 1026 DOM Steel Construction
    • CNC Bent Tubing
    • Serviceable Dual Stage Bushings
    • CNC Machined Bushing Housings and Sleeves
    • Built-In Caster Correction
    • Black Semi-Gloss Powder Coat Finish

    TECH INFO:

    • Factory Wheels & Tires Fitment: Yes
    • Recommended Aftermarket Wheels: ICON Alloys | 17×8.5 w/ 4.75″ Backspace / 0mm Offset
    • Recommended Aftermarket Wheels: ICON Alloys | 18×9 w/ 5″ Backspace / 0mm Offset
    • Recommended Aftermarket Tires: 33″ x 11.50″
8534

on

Icon 2.5-3″ Lift Bolt-In Coilover Conversion Kit For 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016 Ford F250/F350 4WD

Part: 61720

OVERVIEW:

ICON’s 2.5 VS Series Remote Reservoir Bolt-In Coilover Conversion Kit will add a new level of performance and adjustability to 2005-UP F-250 and F-350 trucks.The advantage of utilizing a coilover conversion kit is that they have been designed to increase the overall damping ability of the vehicle while at the same time allowing for user-defined ride height adjustment. The 2.5″ Remote Reservoir Coilover featured in these kits is based off of ICON’s 2.5 VS Series shock line – meaning that features like Eibach coil springs, FK Rod End bearings, and vehicle-specific valving come standard. Quality machined components and a fully serviceable design make for a product that will stand the test of time, yet retain the ability to be rebuilt or revalved as necessary.

KEY FEATURES:

  • Bolt-in system fits in OE coil bucket location
  • Ride height adjustable coilovers (2.5-3″)
  • Decreased body roll and improved on and off-road ride dynamics
  • Vehicle-specific shock valving provides unparalleled ride quality and control
  • Shocks are fully rebuildable and revalveable
  • Coilover conversion allows for addition of secondary shock
  • Corrosion resistant CAD plated coilover shock body with 7/8″ shaft
  • Eibach coil springs guaranteed for life against sagging or breakage
  • FK Rod End bearings for extended longevity and minimal deflection
  • Made in the USA

COMPONENTS INCLUDED:

  • (2) 2.5″ coilover shocks with coils
  • Necessary hardware and bracketry
  • Installation instructions
2465

on

Icon 4.5-9″ Front Lift V.S. 2.5 Series PBR Secondary Shocks For 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016 Ford F250/F350 4WD

Part: 61710P

OVERVIEW:

ICON Vehicle Specific (V.S.) 2.5 Series shocks are designed and built to give your vehicle outstanding performance off-road and a smooth ride on the street. These shocks are configured specifically for each application in both length and damping tune. Like all ICON shock absorbers, V.S. 2.5 Series shocks are 100% rebuildable and 100% revalveable. For piggyback and specific remote reservoir applications; ICON’s unique use of a 6061 billet aluminum manifold a few inches below the top cap of the shock creates an internal “Bump Zone” that when used creates an additional 20% of damping force. This additional force helps prevent harsh bottom outs and controls the suspension when compressing at high velocity. If you are looking for a more user defined tune, consider looking into the Compression Damping Control Valve (CDCV) or the OMEGA Series bypass shocks.

KEY FEATURES:

  • ICON’s internal “Bump Zone” increases damping by 20% to provide more control as the shock approaches full compression
  • Remote reservoir design improves heat dissipation to reduce shock fade during prolonged use
  • Premium grade 5WT shock oil for consistent suspension damping along a wide temperature range
  • Nitrogen charged monotube design with piggyback reservoir
  • One piece digressive piston design with vehicle specific valving for unsurpassed performance and ride quality on and off-road
  • 7/8” diameter induction hardened, chrome plated shock shaft
  • PTFE lined spherical bearings and application specific mounting hardware
  • 6061 aircraft grade aluminum CNC machined components
  • CAD plated, precision machined 1026 DOM steel shock body for maximum durability and corrosion resistance
  • 100% Rebuildable
  • 100% Revalveable
  • Made in the U.S.A.
  • All ICON 2.5 Series Piggyback and Remote Reservoir shocks can be upgraded to ICON’s Compression Damping Control Valve (CDCV)

NOTES:

  • ICON V.S. 2.5 Series shocks are sold in pairs
  • Price listed is for two (2) shock absorbers
509

on

Icon 7-9″ Lift Coilovers Kit For 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016 Ford F250/F350 Super Duty

Part: 61700

Overview:

These coil-over shocks are the ultimate suspension modification for your Super Duty. These are not race style shocks that were modified to fit they were designed from the ground up for the 2005 – Current Model Super Duty. They are adjustable in ride height from 7″ to 9″ of lift. They have any external Reservoir for excellent heat dissipation, a Dual Rate Spring for a great ride quality on or offroad, and are completely rebuilable. These shocks are sold as a pair

Installation Instructions

40159043_I61950_REVA

2286
