SuperLift 6″ Lift Kit For 2009, 2010, 2011, 2012, 2013, 2014 Ford F-150 4WD – w/ Superide Rear Shocks

Part: K179 (old: K105)

  • This is a complete replacement knuckle style suspension Lift Kit for the 2009-2014 Ford F-150 4WD; providing 6” of lift height.
  • Includes fabricated rear lift blocks and rear Superlift Superide shock absorbers.
  • Covered by our Limited Lifetime Warranty.
  • This kit also comes in a 5100 Series Bilstein rear shock option.

Include:

  • All brackets, cross-members, shocks, steering knuckles, u-bolts, spacers, and hardware required specific to the 2009-2014 4wd Ford F-150.
  • Detailed instruction manual walking you step-by-step through the lift kit installation procedures suitable for do-it-yourselfers (DIY) or professional installation
  • The best customer service and technical help in the industry.

PRODUCT DETAILS:

  • Direct bolt-on (No Weld Design)
  • Allows the use of 18″ or larger factory wheels
  • Makes room for up to 35″ tires
  • Maintains awesome ride quality and handling characteristics
  • Aligns to OEM specifications
  • Corrects front to rear factory rake
  • Retains OEM track width
  • Simple to follow DIY friendly instructions
  • Lifetime Warranty
  • 60-Day Satisfaction Guarantee

Includes:

Front

  • CNC machined extended ductile iron steering knuckles
  • CNC machined billet aluminum drive shaft spacer
  • All fabricated steel components are laser cut, CNC formed finished with a durable black powder coat
  • Front top mount strut spacers
  • One-piece front and rear cross members
  • Front differential skid plate
  • Sway-bar relocation brackets
  • Differential relocation brackets
  • Brake line relocation brackets
  • Eccentric cam-bolts

Rear

  • Fabricated lift blocks
  • Brake line relocation bracket
  • U-bolts and hardware
  • Compression stop extensions
  • Superlift Superide Shocks (2)

Notes:

  • Does not fit Single Cab Truck models
  • Models equipped with a two-piece rear driveshaft will need to order an additional kit box 9935 for the carrier bearing shims

FITMENT TABLE:

YEARS DRIVE MAKE MODEL
2009-2014 4WD Ford F-150

TIRE & WHEEL INFO:

TIRE WHEEL BACKSPACING OFFSET
35 x 12.5 18 x 9 5.3 +19
35 x 13.5 18 x 9 5 +13
35 x 13.5 18 x 9 4.5 –
35 x 12.5 20 x 9 5.5 +25
35 x 13.5 20 x 9 5 +13
35 x 13.5 20 x 9 4.5 –
35 x 12.5 20 x 10 4.3 -19

IMPORTANT DISCLAIMER: The provided tire/wheel fitments are approximate. Actual dimensions of a given tire size can vary considerably from one brand to another. Manufacturers’ wheel offset and backspacing measurement points are not always consistent. Backspacing greatly impacts tire-to-fender clearance when turning. Wheel width and backspacing influence whether the tires protrude past the fenders, and to what extent. Considering these important factors, we recommend that you fit-check your tire/wheel selection prior to purchasing.

Installation Notes:

  • Installation time: 7-8 hours
  • Difficulty level: 3 of 5

if you are interested in getting Bilstein shocks instead, here is the lift kit with Bilstein Shocks: SuperLift 6" Lift Kit For 2009-2014 Ford F-150 4WD – w/ Bilstein Rear Shocks

7186

on

SuperLift 6″ Lift Kit For 2009, 2010, 2011, 2012, 2013, 2014 Ford F-150 4WD – w/ Bilstein Rear Shocks

Part: K179B (old: K105B)

  • This is a complete replacement knuckle style suspension Lift Kit for the 2009-2014 Ford F-150 4WD; providing 6” of lift height.
  • Includes fabricated rear lift blocks and rear 5100 Series Bilstein shock absorbers.
  • Covered by our Limited Lifetime Warranty.
  • This kit also comes in a Superlift Superide rear shock option.

Include:

  • All brackets, cross-members, shocks, steering knuckles, u-bolts, spacers, and hardware required specific to the 2009-2014 4wd Ford F-150.
  • Detailed instruction manual walking you step-by-step through the lift kit installation procedures suitable for do-it-yourselfers (DIY) or professional installation
  • The best customer service and technical help in the industry.

PRODUCT DETAILS:

  • Direct bolt-on (No Weld Design)
  • Allows the use of 18″ or larger factory wheels
  • Makes room for up to 35″ tires
  • Maintains awesome ride quality and handling characteristics
  • Aligns to OEM specifications
  • Corrects front to rear factory rake
  • Retains OEM track width
  • Simple to follow DIY friendly instructions
  • Lifetime Warranty
  • 60-Day Satisfaction Guarantee

Includes:

Front

  • CNC machined extended ductile iron steering knuckles
  • CNC machined billet aluminum drive shaft spacer
  • All fabricated steel components are laser cut, CNC formed finished with a durable black powder coat
  • Front top mount strut spacers
  • One-piece front and rear cross members
  • Front differential skid plate
  • Sway-bar relocation brackets
  • Differential relocation brackets
  • Brake line relocation brackets
  • Eccentric cam-bolts

Rear

  • Fabricated lift blocks
  • Brake line relocation bracket
  • U-bolts and hardware
  • Compression stop extensions
  • Bilstein Shocks (2)

Notes:

  • Does not fit Single Cab Truck models
  • Models equipped with a two-piece rear driveshaft will need to order an additional kit box 9935 for the carrier bearing shims

FITMENT TABLE:

YEARS DRIVE MAKE MODEL
2009-2014 4WD Ford F-150

TIRE & WHEEL INFO:

TIRE WHEEL BACKSPACING OFFSET
35 x 12.5 18 x 9 5.3 +19
35 x 13.5 18 x 9 5 +13
35 x 13.5 18 x 9 4.5 –
35 x 12.5 20 x 9 5.5 +25
35 x 13.5 20 x 9 5 +13
35 x 13.5 20 x 9 4.5 –
35 x 12.5 20 x 10 4.3 -19

IMPORTANT DISCLAIMER: The provided tire/wheel fitments are approximate. Actual dimensions of a given tire size can vary considerably from one brand to another. Manufacturers’ wheel offset and backspacing measurement points are not always consistent. Backspacing greatly impacts tire-to-fender clearance when turning. Wheel width and backspacing influence whether the tires protrude past the fenders, and to what extent. Considering these important factors, we recommend that you fit-check your tire/wheel selection prior to purchasing.

Installation Notes:

  • Installation time: 8 hours
  • Difficulty level: 3 of 5

Includes Shocks exactly as pictured

2478

on

SuperLift 6″ Lift Kit For 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006 Chevy Silverado and GMC Sierra 1500 4WD – Knuckle Kit with Bilstein Shocks

Part: K121B

  • This is a complete knuckle style suspension lift kit for the 1999-2006 Chevy/GMC 1500 pickup 4wd; providing 6” of lift height
  • Includes rear blocks and front and rear 5100 Series Bilstein shock absorbers
  • Covered by our Limited Lifetime Warranty
  • This kit also comes in a 5100 Series Bilstein shock option

Include:

  • All brackets, cross-members, shocks, steering knuckles, rear 5” block and u-bolt kit, and hardware required specific to the 1999-2006 4wd Chevrolet/GMC 1500.
  • Detailed instruction manual walking you step-by-step through the lift kit installation procedures suitable for do-it-yourselfers (DIY) or professional installation
  • The best customer service and technical help in the industry.

PRODUCT DETAILS:

Features and Benefits:

  • Stylish high-clearance cross members are one-piece, laser cut, CNC formed and built to withstand a lifetime of use and abuse.
  • Replacement steering knuckles maintain OE alignment specifications.
  • Minimal differential modification required.
  • Longer front anti-sway bar links included.
  • Rear lift achieved via tried and true 5″ cast iron blocks for superior strength.
  • Applicable with Auto Trac models. Does not require replacement front driveshaft.
  • Allows use of factory spare tire / wheel.
  • Limited Lifetime Warranty.
  • 100% Satisfaction Guarantee.
  • Easy to follow DIY friendly installation instructions.

FITMENT TABLE:

YEARS DRIVE MAKE MODEL
1999-2006 4WD Chevrolet Silverado 1500
2007-2007 4WD Chevrolet Silverado 1500 – Classic
1999-2006 4WD GMC Sierra 1500
2007-2007 4WD GMC Sierra 1500 – Classic

TIRE & WHEEL INFO:

TIRE WHEEL BACKSPACING OFFSET
35 x 12.5 17 x 9 4.5 –
35 x 12.5 18 x 9 4.5 –
35 x 12.5 20 x 9 5 –

IMPORTANT DISCLAIMER: The provided tire/wheel fitments are approximate. Actual dimensions of a given tire size can vary considerably from one brand to another. Manufacturers’ wheel offset and backspacing measurement points are not always consistent. Backspacing greatly impacts tire-to-fender clearance when turning. Wheel width and backspacing influence whether the tires protrude past the fenders, and to what extent. Considering these important factors, we recommend that you fit-check your tire/wheel selection prior to purchasing.

Installation Notes:

  • Installation time: 8 hours
  • Difficulty level: 4 of 5

DOES THIS LIFT KIT INCREASE THE TRUCK’S FRONT TRACK WIDTH?

Replacing the steering knuckles on this vehicle increases the track width by 1-5/8 inches (1.625″).

Includes Shocks exactly as pictured

11925

on

SuperLift 4″ Lift Kit For 2014, 2015, 2016, 2017, 2018 Dodge Ram 2500 4WD – Diesel Engine – with Superide Shocks

Part: K124

  • This is a complete radius arm drop bracket suspension lift kit for the 2014-2018 Dodge Ram 2500 4wd – diesel engine; providing 4″ of lift height
  • Includes rear coil spacers to maintain factory load carrying, front and rear Superlift Superide shock absorbers
  • Covered by our Limited Lifetime Warranty
  • This kit also comes in a 5100 Series Bilstein shock option

Include:

  • Front lift includes 4″ coil springs, track bar bracket, pitman arm, sway bar correction, bump stops, brake line brackets, radius arm drops, Superide shocks, and all required hardware
  • Rear lift includes 2.5″ coil spacers, track bar bracket, sway bar correction, bump stops, Superide shocks and all required hardware.
  • Detailed instruction manual walking you step-by-step through the lift kit installation procedures suitable for do-it-yourselfers (DIY) or professional installation
  • The best customer service and technical help in the industry.

PRODUCT DETAILS:

Features and Benefits:

  • Replacement front springs improve ride quality while rear coil spacers maintain stock load capacity
  • Radius arm drops maintain proper caster
  • Track bar relocation bracket prevents stud bind and steering wheel kick
  • Pitman arm relieves drag link angle to prevent bump steer / wandering
  • Front and Rear Superlift Superide Shocks are Included
  • Limited Lifetime Warranty
  • Satisfaction Guarantee
  • Made in the USA

Recommended Tire and Wheel Size:

  • Wheel Size: 9″ Wide
  • Back Spacing: 4 1/2″
  • Tire Size: 35 X 12.50

Can fit up to:

  • Wheel Size: 9″ Wide
  • Back Spacing: 5 5/8″
  • Max Tire Size: 37 X 12.50

Install Time and Difficulty:

  • Install Time Hrs: 5-6
  • Difficulty Level 1-5: 3

NOTE: Does not fit Power Wagon models.

NOTE: Does NOT fit Models with rear air suspension

FITMENT TABLE:

YEARS DRIVE MAKE MODEL
2014-2017 4WD Dodge Ram 2500

TIRE & WHEEL INFO:

TIRE WHEEL BACKSPACING OFFSET
35 x 12.5 17 x 9 4.5 – 5 –
35 x 12.5 18 x 9 4.5 – 5 –
35 x 12.5 20 x 9 4.5 – 5 –

IMPORTANT DISCLAIMER: The provided tire/wheel fitments are approximate. Actual dimensions of a given tire size can vary considerably from one brand to another. Manufacturers’ wheel offset and backspacing measurement points are not always consistent. Backspacing greatly impacts tire-to-fender clearance when turning. Wheel width and backspacing influence whether the tires protrude past the fenders, and to what extent. Considering these important factors, we recommend that you fit-check your tire/wheel selection prior to purchasing.

Installation Notes:

  • Installation time: 7 hours
  • Difficulty level: 3 of 5

if you are interested in getting Bilstein shocks instead, here is the lift kit with Bilstein Shocks: SuperLift 4" Lift Kit For 2014-2018 Dodge Ram 2500 4WD Diesel with Bilstein Shocks
