RCD 4-6″ Lift Front & Rear Bilstein Shocks for 2000, 2001, 2002, 2003, 2004, 2005, 2006 Toyota Tundra

Front: F4-BE5-B109-T5

Extended length    23.25″

Collapsed length    18.52″

Rear: F4-BE5-B110-T5

Extended length    27.28″

Collapsed length  16.34″



These shocks are designed to work with RCD 4-6″ Lift Kit that utilizes Crossmember, Spindles and a lot of other items required to lift the truck. If you Just want to replace spacers then these shocks wont work.
Includes 4 Shocks

6617

on

ICON 0-3″ Shock System – Stage 3 for 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007 Toyota Land Cruiser (100 Series)

Part: K53083

Overview:

The 1998 – 2007 Toyota Lancrusier 100 Series has a compact torsion bar IFS front suspension, and requires a lot of work to be done in a small space. When lift is added via torsion bar adjustment there is even more spring energy that must be absorbed to adequately control the vehicle. Keeping this in mind, those looking to achieve 0-3″ of lift (aftermarket upper control required) can install the Stage 3 shock system for maximum suspension travel and performance with tuning adjustability. ICON engineers have developed a unique 2.5” diameter shock system, with remote reservoirs front and rear, that can handle these demands. 2.5″ reservoir shocks front and rear ensure optimum performance by increasing the duration of consistent damping regardless of situation, keeping the shocks at a cooler operating temperature during extended offroad use. With a lower spherical rod end bearing and heavy duty upper stem bushings, deflection is kept to a minimum for precise control of the suspension even under high loads. ICON’s CDC Valve upgrade is included in this stage front and rear for those desiring an easy way to tune the ride externally with 10 settings from soft to hard.

Key Features:

• Vehicle specific tuned front and rear shocks for superior shock damping and control

• Remote reservoirs provided for extended shock damping performance

• ICON CDCV equipped shocks front and rear for fully adjustable tuneability of your shocks

• 6061 Aircraft grade aluminum CNC machined components

• Corrosion resistant CAD plated shock bodies with 7/8 shaft

• FK rod end bearings for extended longevity and minimal deflection

• No cutting or welding necessary for install

• Made in the USA

Tech Info:

• Performance shock system for use with 0-3″ of lift, Uniball upper control arms required. Additional components required to achieve desired lift height over stock

System Components:
57807CP    (QTY – 2) – ICON V.S. 2.5 Series Remote Reservoir Front Shocks w/ CDCV (upper control arm required)

57802CP    (QTY – 2) – ICON V.S. 2.5 Series Remote Reservoir Rear Shocks w/ CDCV

1197

on

ICON 0-3″ Shock System – Stage 2 for 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007 Toyota Land Cruiser (100 Series)

Part: K53082

Overview:

The 1998 – 2007 Toyota Lancrusier 100 Series has a compact torsion bar IFS front suspension, and requires a lot of work to be done in a small space. When lift is added via torsion bar adjustment there is even more spring energy that must be absorbed to adequately control the vehicle. Keeping this in mind, those looking to achieve 0-3″ of lift (aftermarket upper control required) can install the Stage 2 shock system for maximum suspension travel and performance. ICON engineers have developed a unique 2.5” diameter shock system, with remote reservoirs front and rear, that can handle these demands. 2.5″ reservoir shocks front and rear ensure optimum performance by increasing the duration of consistent damping regardless of situation, keeping the shocks at a cooler operating temperature during extended offroad use. With a lower spherical rod end bearing and heavy duty upper stem bushings, deflection is kept to a minimum for precise control of the suspension even under high loads.

Key Features:

• Vehicle specific tuned 2.5″ front and rear shocks for superior shock damping and control

• Remote reservoirs provided for extended shock damping performance

• 6061 Aircraft grade aluminum CNC machined components• Corrosion resistant CAD plated shock bodies with 7/8 shaft

• FK rod end bearings for extended longevity and minimal deflection

• No cutting or welding necessary for install

• Made in the USA

Tech Info:

• Performance shock system for use with 0-3″ of lift, Uniball upper control arms required. Additional components required to achieve desired lift height over stock

System Components:
57807    (QTY – 2) – ICON V.S. 2.5 Series Remote Reservoir Front Shocks (upper control arm required)

57802    (QTY – 2) – ICON V.S. 2.5 Series Remote Reservoir Rear Shocks

Options:

57807C   ICON V.S. 2.5 Series Remote Reservoir Front Shocks w/ CDCV (upper control arm required)

57802C   ICON V.S. 2.5 Series Remote Reservoir Rear Shocks w/ CDCV

1576

on

ICON 2.5-3.5″ Lift Kit – Stage 6 for 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021 Toyota Land Cruiser (200 Series)

Part: K53076

OVERVIEW:

The 200 Series Toyota Land Cruiser is a luxurious vehicle packed with “all the bells and whistles”, but underneath all of the sophistication it is still a very capable vehicle that sees heavy use both on and off-road worldwide. While the 200 Series has exceptional ride characteristics in stock form, it is clear that the suspension is in need of a serious upgrade if the vehicle is to serve any measurable amount of time in the dirt. ICON Vehicle Dynamics has addressed this need for a comprehensive suspension solution and is proud to re-introduce several suspension systems that drastically increase the overall ability of the 2008-UP Toyota Land Cruiser.



KEY FEATURES:

  • Increased wheel travel and ride quality over stock
  • Improved vehicle dynamics and decreased body roll
  • Height adjustable coilovers provide 1.5-3.5″ of lift height
  • ICON engineered dual rate rear coil springs
  • Vehicle-specific tuned front and rear shocks provide superior damping and control
  • Corrosion resistant CAD plated shock bodies with 7/8″ shafts (2.5 Series) or 1” shafts (3.0 Series)
  • CDCV technology allows for quick and easy compression damping adjustment without the need for tools
  • Shocks are fully rebuildable and revalveable
  • Bolt-on design means no cutting or welding necessary for install

WHEEL & TIRE FITMENT INFO:

OEM Wheels & Tires: Yes

Aftermarket Wheels: 8-8.5″ Wide, 5.75″ Backspace

Aftermarket Tires: 34 x 10.50

(Larger Tires May Fit but Fender Trimming and Modifications will be Required)



SYSTEM COMPONENTS:

58765 (QTY.1) | 08-UP LAND CRUISER (200 SERIES) 3.0 VS RR CDCV COILOVER KIT

58570DJ (QTY.1) | 08-UP LAND CRUISER (200 SERIES) LAND CRUISER BILLET UCA DJ KIT

52750 (QTY.1) | 08-UP LAND CRUISER (200 SERIES) REAR 1.75″ DUAL RATE SPRING KIT

57825CP (QTY.1) | 08-UP LAND CRUISER (200 SERIES) REAR 2.5 VS RR CDCV PAIR

54000 (QTY.1) | 08-UP LAND CRUISER (200 SERIES) BILLET LOWER TRAILING ARM KIT

13011
