ICON S2 Secondary Shock System Stage 1 for 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021 Toyota Tundra

Part: K53151

OVERVIEW:

The ICON Vehicle Dynamics Stage 1 S2 Secondary Shock System redefines the off-road capability of the 2007-UP Toyota Tundra by allowing for the installation of a secondary shock to an existing ICON coilover setup. The addition of a 2.5 Series piggyback reservoir secondary shock means rougher terrain and larger off-road obstacles can be overcome with confidence as the damping ability of the vehicle’s front suspension is effectively doubled.

As opposed to overly complicated and expensive long travel kits, the ICON S2 System is an affordable, mostly bolt-on upgrade that drastically increases off-road performance, is easy to install, and has a modular design that allows 2007-UP Toyota Tundra owners to upgrade in steps or all at once. The S2 Secondary Shock System utilizes the factory lower control arms and maintains OE track width while a combination of a billet aluminum shock tower adapters, fabricated shock hoops, and steel lower shock mounts make for a straightforward install with the exceptional build quality you would expect from an ICON Vehicle Dynamics product.

KEY FEATURES:

  • Drastically improves vehicle damping ability off-road
  • Increased vehicle stability on-road
  • Utilizes factory lower control arms
  • Maintains OE track width
  • Vehicle-specific tuned 2.5 Series secondary shocks provide increased damping and oil volume
  • Shocks are fully rebuildable and revalveable
  • Simple and straightforward installation



WHEEL & TIRE FITMENT INFO:

OEM Wheels & Tires: Yes

Aftermarket Wheels: 8-8.5″ Wide, 5.75″ Backspace

Aftermarket Tires: 35″ x 12.50″

(Larger Tires May Fit but Fender Trimming and Modifications will be Required)

Recommended Wheel: ICON Alloys ‘Six Speed’ | 17×8.5, 5.75″ BS, 25mm Offset

SYSTEM COMPONENTS:

56109 (QTY.1) | 07-UP TUNDRA S2 HOOP KIT

57722P (QTY.1) | 07-UP TUNDRA S2 2.5 VS PB PAIR

728

on

ICON RXT Rear Suspension System Stage 3 for 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021 Toyota Tundra

Part: K53157

OVERVIEW:

The 2007-2019 Toyota Tundra is a very capable and versatile truck with features that make it suitable for use as everything from daily driver, to tow rig, to adventure vehicle and everything in between. From the brutal deserts of the Southwest to the wooded trails of the East coast ICON suspension systems have been put to the test and performed flawlessly for this popular Toyota. Over the span of hundreds of hours in the shop and over a thousand miles in the dirt, ICON Vehicle Dynamics’ engineers have pushed this vehicle to extremes in order to develop the most sophisticated suspension components on the market. Unable to leave “well-enough” alone, ICON is aiming to raise the bar in Tundra performance with the introduction of the RXT Rear Suspension System.

Through an accelerated testing process dubbed the “ICON1K” R&D program, ICON has spent over a year pushing the Tundra to off-road extremes to identify limiting factors in OE components and further extrapolate performance out of this vehicle. In a push to provide unparalleled ride quality and vehicle dynamics for everything from high-speed desert running to off the grid expedition, the RXT Rear Suspension System was born. The RXT Rear Suspension System is a combination of an all new ICON multi-rate leaf spring, a hydraulic rear bump stop kit, and three RXT-specific 2.5 Series rear shock options. Installation of this system replaces the aforementioned “limiting factors” and completely redefines the potential of the 2007-2019 Toyota Tundra with a 20% increase in wheel travel and the ability to adjust the leaf spring rate to compensate for varying vehicle setups.

KEY FEATURES:

ICON RXT Multi-Rate Leaf Spring

  • 3 user-adjustable spring rates for unique vehicle configurations
  • Military wrap front eyelet for increased durability
  • Galvanized leaf separators reduce friction and aid in corrosion resistance
  • Leaf tip inserts reduce noise and increase ride comfort
  • Potential for increased wheel travel when used with RXT shock without sacrificing up-travel (up to 20% over stock)
  • “ICON 1K” tested under rigorous off-road conditions to validate tune, performance, strength, and durability
  • Direct bolt-in to OEM spring location makes for an easy install

ICON RXT Rear Shock

  • Omega Series two-tube bypass allows for 24 settings of compression and rebound damping adjustment
  • Unique side-mounted lower eyelet allows for increased travel while utilizing factory mounting location
  • Vehicle-specific tuned shocks provide increased damping and oil volume
  • 10” aluminum reservoirs provide generous oil and nitrogen volume for consistent damping as shock temperature increases
  • Shocks are fully rebuildable and revalveable
  • Simple and straightforward installation
  • “ICON 1K” tested under rigorous off-road conditions to validate tune, performance, strength, and durability

ICON Hydraulic Rear Bump Stop Kit

  • 2.5” travel bump stop reduces rear end ‘kick’ and improves overall performance
  • Position sensitive technology exponentially increases bottom-out resistance
  • Vehicle specific bump stop tune to provide smooth engagement and best ride quality
  • Direct bolt-in to OEM bump stop location makes for an easy and straightforward install
  • Heavy duty 1.25” CNC machined nitro steel shaft
  • CAD plated body for maximum corrosion resistance
  • Double sealed high pressure Schrader valve
  • Operating range of 50-250 PSI
  • Replaceable noise-reducing striker pad
  • Fully serviceable
  • “ICON 1K” tested under rigorous off-road conditions to validate tune, performance, strength, and durability

SYSTEM COMPONENTS

51201 (QTY.1) | 07-UP TUNDRA MULTI RATE LEAF SPRING KIT W/ UBOLTS

56108 (QTY.1) | 07-UP TUNDRA REAR HYD BUMP STOP SYSTEM

59923P (QTY.1) | 07-UP TUNDRA RXT REAR 2.5 OMEGA RR (PAIR)

1396

on

ICON RXT Rear Suspension System Stage 2 for 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021 Toyota Tundra

Part: K53156

OVERVIEW:

The 2007-2019 Toyota Tundra is a very capable and versatile truck with features that make it suitable for use as everything from daily driver, to tow rig, to adventure vehicle and everything in between. From the brutal deserts of the Southwest to the wooded trails of the East coast ICON suspension systems have been put to the test and performed flawlessly for this popular Toyota. Over the span of hundreds of hours in the shop and over a thousand miles in the dirt, ICON Vehicle Dynamics’ engineers have pushed this vehicle to extremes in order to develop the most sophisticated suspension components on the market. Unable to leave “well-enough” alone, ICON is aiming to raise the bar in Tundra performance with the introduction of the RXT Rear Suspension System.

Through an accelerated testing process dubbed the “ICON1K” R&D program, ICON has spent over a year pushing the Tundra to off-road extremes to identify limiting factors in OE components and further extrapolate performance out of this vehicle. In a push to provide unparalleled ride quality and vehicle dynamics for everything from high-speed desert running to off the grid expedition, the RXT Rear Suspension System was born. The RXT Rear Suspension System is a combination of an all new ICON multi-rate leaf spring, a hydraulic rear bump stop kit, and three RXT-specific 2.5 Series rear shock options. Installation of this system replaces the aforementioned “limiting factors” and completely redefines the potential of the 2007-2019 Toyota Tundra with a 20% increase in wheel travel and the ability to adjust the leaf spring rate to compensate for varying vehicle setups.

KEY FEATURES:

ICON RXT Multi-Rate Leaf Spring

  • 3 user-adjustable spring rates for unique vehicle configurations
  • Military wrap front eyelet for increased durability
  • Galvanized leaf separators reduce friction and aid in corrosion resistance
  • Leaf tip inserts reduce noise and increase ride comfort
  • Potential for increased wheel travel when used with RXT shock without sacrificing up-travel (up to 20% over stock)
  • “ICON 1K” tested under rigorous off-road conditions to validate tune, performance, strength, and durability
  • Direct bolt-in to OEM spring location makes for an easy install

ICON RXT Rear Shock

  • CDC Valve technology allows for 10 settings of quick and easy compression damping adjustment
  • Unique side-mounted lower eyelet allows for increased travel while utilizing factory mounting location
  • Vehicle-specific tuned shocks provide increased damping and oil volume
  • 10” aluminum reservoirs provide generous oil and nitrogen volume for consistent damping as shock temperature increases
  • Shocks are fully rebuildable and revalveable
  • Simple and straightforward installation
  • “ICON 1K” tested under rigorous off-road conditions to validate tune, performance, strength, and durability

ICON Hydraulic Rear Bump Stop Kit

  • 2.5” travel bump stop reduces rear end ‘kick’ and improves overall performance
  • Position sensitive technology exponentially increases bottom-out resistance
  • Vehicle specific bump stop tune to provide smooth engagement and best ride quality
  • Direct bolt-in to OEM bump stop location makes for an easy and straightforward install
  • Heavy duty 1.25” CNC machined nitro steel shaft
  • CAD plated body for maximum corrosion resistance
  • Double sealed high pressure Schrader valve
  • Operating range of 50-250 PSI
  • Replaceable noise-reducing striker pad
  • Fully serviceable
  • “ICON 1K” tested under rigorous off-road conditions to validate tune, performance, strength, and durability

SYSTEM COMPONENTS

51201 (QTY.1) | 07-UP TUNDRA MULTI RATE LEAF SPRING KIT W/ UBOLTS

56108 (QTY.1) | 07-UP TUNDRA REAR HYD BUMP STOP SYSTEM

57823CP (QTY.1) | 07-UP TUNDRA RXT REAR 2.5 VS RR CDCV (PAIR)

1078

on

ICON RXT Rear Suspension System Stage 1 for 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021 Toyota Tundra

Part: K53155

OVERVIEW:

The 2007-2019 Toyota Tundra is a very capable and versatile truck with features that make it suitable for use as everything from daily driver, to tow rig, to adventure vehicle and everything in between. From the brutal deserts of the Southwest to the wooded trails of the East coast ICON suspension systems have been put to the test and performed flawlessly for this popular Toyota. Over the span of hundreds of hours in the shop and over a thousand miles in the dirt, ICON Vehicle Dynamics’ engineers have pushed this vehicle to extremes in order to develop the most sophisticated suspension components on the market. Unable to leave “well-enough” alone, ICON is aiming to raise the bar in Tundra performance with the introduction of the RXT Rear Suspension System.

Through an accelerated testing process dubbed the “ICON1K” R&D program, ICON has spent over a year pushing the Tundra to off-road extremes to identify limiting factors in OE components and further extrapolate performance out of this vehicle. In a push to provide unparalleled ride quality and vehicle dynamics for everything from high-speed desert running to off the grid expedition, the RXT Rear Suspension System was born. The RXT Rear Suspension System is a combination of an all new ICON multi-rate leaf spring, a hydraulic rear bump stop kit, and three RXT-specific 2.5 Series rear shock options. Installation of this system replaces the aforementioned “limiting factors” and completely redefines the potential of the 2007-2019 Toyota Tundra with a 20% increase in wheel travel and the ability to adjust the leaf spring rate to compensate for varying vehicle setups.

KEY FEATURES:

ICON RXT Multi-Rate Leaf Spring

  • 3 user-adjustable spring rates for unique vehicle configurations
  • Military wrap front eyelet for increased durability
  • Galvanized leaf separators reduce friction and aid in corrosion resistance
  • Leaf tip inserts reduce noise and increase ride comfort
  • Potential for increased wheel travel when used with RXT shock without sacrificing up-travel (up to 20% over stock)
  • “ICON 1K” tested under rigorous off-road conditions to validate tune, performance, strength, and durability
  • Direct bolt-in to OEM spring location makes for an easy install

ICON RXT Rear Shock

  • Unique side-mounted lower eyelet allows for increased travel while utilizing factory mounting location
  • Vehicle-specific tuned shocks provide increased damping and oil volume
  • 10” aluminum reservoirs provide generous oil and nitrogen volume for consistent damping as shock temperature increases
  • Shocks are fully rebuildable and revalveable
  • Simple and straightforward installation
  • “ICON 1K” tested under rigorous off-road conditions to validate tune, performance, strength, and durability

ICON Hydraulic Rear Bump Stop Kit

  • 2.5” travel bump stop reduces rear end ‘kick’ and improves overall performance
  • Position sensitive technology exponentially increases bottom-out resistance
  • Vehicle specific bump stop tune to provide smooth engagement and best ride quality
  • Direct bolt-in to OEM bump stop location makes for an easy and straightforward install
  • Heavy duty 1.25” CNC machined nitro steel shaft
  • CAD plated body for maximum corrosion resistance
  • Double sealed high pressure Schrader valve
  • Operating range of 50-250 PSI
  • Replaceable noise-reducing striker pad
  • Fully serviceable
  • “ICON 1K” tested under rigorous off-road conditions to validate tune, performance, strength, and durability

SYSTEM COMPONENTS

51201 (QTY.1) | 07-UP TUNDRA MULTI RATE LEAF SPRING KIT W/ UBOLTS

56108 (QTY.1) | 07-UP TUNDRA REAR HYD BUMP STOP SYSTEM

57823P (QTY.1) | 07-UP TUNDRA RXT REAR 2.5 VS RR (PAIR)

1166
