ICON 7″ Lift Kit Stage 1 for 2005, 2006, 2007 Ford Super Duty F250/F350

Part: K67100

OVERVIEW:

ICON’s 7” Suspension System for the 2005-2007 Ford Super Duty offers unparalleled performance and ride quality while giving the vehicle clearance for 38” Tall tires. This system comes complete with ICON 2.0 Aluminum Series Shocks, Dual Rate Coil Springs, Drop Pitman Arm, Pan Rod Bracket, Brake Line Brackets, Radius Arm Drop Down Brackets, ICON’s Fabricated 6″ Blocks and U-bolts. All of these components (excluding shocks) are covered by ICON’s Limited Lifetime Warranty.

KEY FEATURES:

  • 75% increase in wheel travel
  • Less body roll than stock
  • 7” more travel from ride height to front bump stops
  • State of the art dual-rate coil spring
  • Lifetime guarantee that coil springs won’t sag
  • Clears 38″ Tall Tires
  • No change in towing capacity
  • No drive shaft modifications needed
  • 100% Bolt-on system – No drilling, cutting, or welding necessary
  • Made in the USA



SYSTEM COMPONENTS:

  • 67010 – 7″-9″ Box Kit (Sway Bar Links, Bump Stop Spacers, Pan Rod Bracket and Brake Line Brackets
  • 67015 – 7″ Lift Dual Rate Coil-Spring
  • 64040 – Radius Arm Drop Down Brackets
  • 62530 – Alignment Cam Kit
  • 196275 – 6″ Lift Fabricated Rear Blocks
  • 37004 – Rear U-Bolt Kit
  • 66514 – Front ICON 2.0 Aluminum Series Shocks
  • 36508 – Rear ICON 2.0 Aluminum Series Shocks
503

on

ICON 7″ Lift Kit Stage 5 for 2017, 2018, 2019 Ford F250/F350 4WD

Part: K67115

OVERVIEW:

This ICON Vehicle Dynamics 7” suspension system is a great way to lift your 4WD 2017-UP Ford F250/350 Super Duty while drastically improving ride quality and performance. This suspension system is perfect for on-road and off-road use including towing, job site duty, and provides ultimate performance for extreme off-road adventure. ICON’s 7″ Stage 5 System is comprised of dual rate coil springs, progressive leaf springs, 4-Link kit, adjustable track bar, dual opposing steering stabilizer kit, ICON CDC Valve 2.5 Series piggyback reservoir front and rear shocks, plus all of the necessary hardware for installation.

The Stage 5 system sees the inclusion of the ICON Vehicle Dynamics Ford Super Duty 4-Link kit, which further improves performance by eliminating suspension bind commonly experienced with factory radius arms during articulation. This “freeing up” of the front end and the ability of the 4-Link Kit to maintain positive caster through the range of travel equates to an unparalleled ride quality in all conditions. With the endless hours ICON has spent testing and tuning our suspension components and shocks as a complete package, you can rest assured knowing that you have the best suspension solution on the market.

KEY FEATURES:

  • Fits 2017-UP F250 / F350 4WD applications
  • Approximately 50% increased front wheel travel over stock
  • ICON-engineered dual rate coil springs deliver exceptional vehicle control over varying terrain
  • Progressive leaf springs improve ride quality without reducing towing capacity
  • ICON 4-Link system eliminates binding during articulation and maintains positive caster through the entire range of travel
  • ICON CDC Valve allows for 10 clicks of quick and easy compression adjustability
  • ICON shocks feature vehicle specific tune for superior performance and ride quality
  • Shocks are fully rebuildable and revalvable
  • Corrosion resistant CAD plated shock body with 7/8″ shaft (2.5 Series shocks)
  • FK Rod End bearings provide extended longevity and minimal deflection
  • Lifetime guarantee against coil spring breakage or sag
  • Lifetime guarantee against ICON fabricated component breakage or manufacturer defect

WHEEL & TIRE FITMENT INFO:

OEM Wheels & Tires: Yes

Aftermarket Wheels: 8.5-9″ Wide, 5″ Backspace

Aftermarket Tires: 37 x 12.50

(Larger Tires May Fit but Fender Trimming and Modifications will be Required)

SYSTEM COMPONENTS:

67015 (QTY.1) | 05-UP FSD FRONT 7″ DUAL RATE SPRING KIT

67035 (QTY.1) | 17-UP FSD FRONT 7″ BOX KIT

164501 (QTY.1) | 05-UP FSD FRONT UPPER LINKS

64038 (QTY.1) | 17-UP FSD ADJUSTABLE TRACK BAR KIT

164502 (QTY.1) | 05-UP FSD FRONT LOWER LINKS

164504 (QTY.1) | 17-UP FSD 4 LINK FRAME BRACKET KIT

65501 (QTY.1) | 11-UP FSD U-BOLT PLATE KIT

67003 (QTY.1) | 11-UP FSD REAR 15″ U-BOLT KIT

67031 (QTY.1) | 11-UP FSD REAR 7″ BRAKE BRACKET KIT

67720CP (QTY.1) | 05-17 FSD 4WD 7″ FRONT 2.5 VS PB CDCV PAIR

37701CP (QTY.1) | 99-UP 3-6″ FSD REAR 2.5 VS PB CDCV PAIR

65000 (QTY.1) | 05-UP FSD DUAL STABILIZER KIT

36511 (QTY.2) | 99-UP FSD 4WD STABILIZER (DUAL OPPOSING) 2.0 VS IR

168506 (QTY.2) | 17-UP FSD 5″ REAR SPRING W BUSH

65505H (QTY.1) | 17-UP FSD 5″ LEAF SPRING HARDWARE KIT

812

on

ICON 7″ Lift Kit Stage 4 for 2017, 2018, 2019 Ford F250/F350 4WD

Part: K67114

OVERVIEW:

This ICON Vehicle Dynamics 7” suspension system is a great way to lift your 4WD 2017-UP Ford F250/350 Super Duty while drastically improving ride quality and performance. This suspension system is perfect for on-road and off-road use including towing, job site duty, and hardcore off-road adventure. ICON’s 7″ Stage 4 System is comprised of dual rate coil springs, progressive leaf springs, 4-Link kit, adjustable track bar, dual opposing steering stabilizer kit, ICON 2.5 Series piggyback reservoir front and rear shocks, plus all of the necessary hardware for installation.

The Stage 4 system sees the inclusion of the ICON Vehicle Dynamics Ford Super Duty 4-Link kit, which further improves performance by eliminating suspension bind commonly experienced with factory radius arms during articulation. This “freeing up” of the front end and the ability of the 4-Link Kit to maintain positive caster through the range of travel equates to an unparalleled ride quality in all conditions. With the endless hours ICON has spent testing and tuning our suspension components and shocks as a complete package, you can rest assured knowing that you have the best suspension solution on the market.

KEY FEATURES:

  • Fits 2017-UP F250 / F350 4WD applications
  • Approximately 50% increased front wheel travel over stock
  • ICON-engineered dual rate coil springs deliver exceptional vehicle control over varying terrain
  • Progressive leaf springs improve ride quality without reducing towing capacity
  • ICON 4-Link system eliminates binding during articulation and maintains positive caster through the entire range of travel
  • ICON shocks feature vehicle specific tune for superior performance and ride quality
  • Shocks are fully rebuildable and revalvable
  • Corrosion resistant CAD plated shock body with 7/8″ shaft (2.5 Series shocks)
  • FK Rod End bearings provide extended longevity and minimal deflection
  • Lifetime guarantee against coil spring breakage or sag
  • Lifetime guarantee against ICON fabricated component breakage or manufacturer defect

WHEEL & TIRE FITMENT INFO:

OEM Wheels & Tires: Yes

Aftermarket Wheels: 8.5-9″ Wide, 5″ Backspace

Aftermarket Tires: 37 x 12.50

(Larger Tires May Fit but Fender Trimming and Modifications will be Required)

SYSTEM COMPONENTS:

67015 (QTY.1) | 05-UP FSD FRONT 7″ DUAL RATE SPRING KIT

67035 (QTY.1) | 17-UP FSD FRONT 7″ BOX KIT

164501 (QTY.1) | 05-UP FSD FRONT UPPER LINKS

64038 (QTY.1) | 17-UP FSD ADJUSTABLE TRACK BAR KIT

164502 (QTY.1) | 05-UP FSD FRONT LOWER LINKS

65505H (QTY.1) | 17-UP FSD 5″ LEAF SPRING HARDWARE KIT

65501 (QTY.1) | 11-UP FSD U-BOLT PLATE KIT

67003 (QTY.1) | 11-UP FSD REAR 15″ U-BOLT KIT

67031 (QTY.1) | 11-UP FSD REAR 7″ BRAKE BRACKET KIT

67720P (QTY.1) | 05-17 FSD 4WD 7″ FRONT 2.5 VS PB PAIR

37701P (QTY.1) | 99-UP 3-6″ FSD REAR 2.5 VS PB PAIR

65000 (QTY.1) | 05-UP FSD DUAL STABILIZER KIT

36511 (QTY.2) | 99-UP FSD 4WD STABILIZER (DUAL OPPOSING) 2.0 VS IR

164504 (QTY.1) | 17-UP FSD 4 LINK FRAME BRACKET KIT

168506 (QTY.2) | 17-UP FSD 5″ REAR SPRING W BUSH

1143

on

ICON 7″ Lift Kit Stage 3 for 2017, 2018, 2019 Ford F250/F350 4WD

Part: K67113

OVERVIEW:

This ICON Vehicle Dynamics 7” suspension system is a great way to lift your 4WD 2017-UP Ford F250/350 Super Duty while drastically improving ride quality and performance. This suspension system is perfect for on-road and off-road use including towing, job site duty, and spirited off-road adventure. ICON’s 7″ Stage 3 System is comprised of dual rate coil springs, progressive leaf springs, radius arm drop brackets, adjustable track bar, dual opposing steering stabilizer kit, ICON 2.5 Series piggyback reservoir front and rear shocks, plus all of the necessary hardware for installation. With the endless hours ICON has spent testing and tuning our suspension components and shocks as a complete package, you can rest assured you have the best suspension solution on the market.

KEY FEATURES:

  • Fits 2017-UP F250 / F350 4WD applications
  • Approximately 50% increased front wheel travel over stock
  • ICON-engineered dual rate coil springs deliver exceptional vehicle control over varying terrain
  • Progressive leaf springs improve ride quality without reducing towing capacity
  • Radius arm drop brackets correct geometry and caster for optimal alignment specs
  • ICON shocks feature vehicle specific tune for superior performance and ride quality
  • Shocks are fully rebuildable and revalvable
  • Corrosion resistant CAD plated shock body with 7/8″ shaft (2.5 Series shocks)
  • FK Rod End bearings provide extended longevity and minimal deflection
  • Lifetime guarantee against coil spring breakage or sag
  • Lifetime guarantee against ICON fabricated component breakage or manufacturer defect

WHEEL & TIRE FITMENT INFO:

OEM Wheels & Tires: Yes

Aftermarket Wheels: 8.5-9″ Wide, 5″ Backspace

Aftermarket Tires: 37 x 12.50

(Larger Tires May Fit but Fender Trimming and Modifications will be Required)

SYSTEM COMPONENTS:

67015 (QTY.1) | 05-UP FSD FRONT 7″ DUAL RATE SPRING KIT

67035 (QTY.1) | 17-UP FSD FRONT 7″ BOX KIT

62530 (QTY.1) | 05-UP FSD 2.3 DEG ALIGNMENT CAM KIT

64038 (QTY.1) | 17-UP FSD ADJUSTABLE TRACK BAR KIT

64055 (QTY.1) | 17-UP FSD RADIUS ARM DROP BRACKET KIT

65505H (QTY.1) | 17-UP FSD 5″ REAR LEAF SPRING KIT

65501 (QTY.1) | 11-UP FSD U-BOLT PLATE KIT

67003 (QTY.1) | 11-UP FSD REAR 15″ U-BOLT KIT

67031 (QTY.1) | 11-UP FSD REAR 7″ BRAKE BRACKET KIT

67720P (QTY.1) | 05-17 FSD 4WD 7″ FRONT 2.5 VS PB PAIR

37701P (QTY.1) | 99-UP 3-6″ FSD REAR 2.5 VS PB PAIR

65000 (QTY.1) | 05-UP FSD DUAL STABILIZER KIT

36511 (QTY.2) | 99-UP FSD 4WD STABILIZER (DUAL OPPOSING) 2.0 VS IR

168506 (QTY.2) | 17-UP FSD 5″ REAR SPRING W BUSH
