ICON Front Remote Reservoir Coil Over Shock Kit w/ CDCV for 2009, 2010, 2011, 2012, 2013 Ford F150 4WD

Part: 91800C

Overview:

The ICON Vehicle Dynamics V.S. Series 2.5” remote reservoir coilover shocks w/ CDCV are an incredible upgrade for the front end of the 2009-2013 Ford F150 4wd truck. ICON’s Vehicle-specific valving provides a sport tuned feel on and off-road while offering 0-3” of lift height adjustability for use of larger, more aggressive wheel and tire combinations. ICON’s larger 2.5” shock body and increased piston area over stock components provides improved damping ability and outstanding ride characteristics across varying types of terrain. Remote reservoir ensure optimum performance by increasing the duration of consistent damping regardless of situation, keeping the shocks at a cooler operating temperature during heavy use. The ICON CDC Valve upgrade is included for those desiring an easy way to tune the ride externally with 10 settings from soft to hard. When paired with ICON rear 2.0 Aluminum Series or 2.5 Series shocks, vehicle control will be balanced front to rear resulting in the best overall driving experience for your Ford F150 4wd.

Key Features:

• Increased wheel travel and ride quality over stock

• Vehicle specific tuned for superior shock damping and control

• External reservoir to attain cooler operating temperatures during extended offroad use

• ICON CDCV equipped for external tuneability of your shocks

• Adjustable 0-3″ lift height

• ICON engineered Eibach Springs

• 6061 Aircraft grade aluminum CNC machined components

• Corrosion resistant CAD plated shock body with 7/8 shaft

• FK rod end bearings for extended longevity and minimal deflection

• 100% Bolt-on – no drilling, cutting or welding necessary for installation

• KDSS compliant

• Made in the USA

System Components Included:

• (2) 2.5″ Remote Reservoir Coilover Shocks with Coils

• Necessary hardware

• Installation Instructions

Options:

198000    Universal 2 Pin Spanner Wrench

191009    ICON Coilover Shock Wraps

98500      2004-2014 Ford F150 2WD/4WD Uniball Upper Control Arm Kit

ICON 2 pin Spanner Wrench – ALL ICON Coilover Shocks, ICON Shock Wraps Neoprene Coil Over Shock Protection Covers (large)

510

on

ICON Front Remote Reservoir Coil Over Shock Kit for 2009, 2010, 2011, 2012, 2013 Ford F150 4WD

Part: 91800

Overview:

ICON Vehicle Dynamics V.S. Series 2.5” remote reservoir coilover shocks are an incredible upgrade for the front end of the 2009-2013 Ford F150 4wd truck. ICON’s Vehicle-specific valving provides a sport tuned feel on and off-road while offering 0-3” of lift height adjustability for use of larger, more aggressive wheel and tire combinations. The larger 2.5” shock body and increased piston area over stock components provides improved damping ability and outstanding ride characteristics across varying types of terrain. Remote reservoir ensures optimum performance by increasing the duration of consistent damping regardless of situation, keeping the shocks at a cooler operating temperature during heavy use. When paired with ICON rear 2.0 Aluminum Series or 2.5 Series shocks, vehicle control will be balanced front to rear resulting in the best overall driving experience for your Ford F150 4wd.

Key Features:

• Increased wheel travel and ride quality over stock

• Vehicle specific tuned for superior shock damping and control

• External reservoir to attain cooler operating temperatures during extended offroad use

• Adjustable 0-3″ lift height

• ICON engineered Eibach Springs

• 6061 Aircraft grade aluminum CNC machined components

• Corrosion resistant CAD plated shock body with 7/8 shaft

• FK rod end bearings for extended longevity and minimal deflection

• 100% Bolt-on – no drilling, cutting or welding necessary for installation

• KDSS compliant

• Made in the USA

System Components Included:

• (2) 2.5″ Remote Reservoir Coilover Shocks with Coils

• Necessary hardware

• Installation Instructions

Options:

198000    Universal 2 Pin Spanner Wrench

191009    ICON Coilover Shock Wraps

98500      04-14 Ford F150 Tubular Uniball Upper Control Arms

713

on

ICON 0-2″ Lift Rear V.S. 2.5 Series PBR Shocks w/CDCV for 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014 Ford F150 4WD

Part: 97720CP (old: 97700CP)

OVERVIEW:

ICON Vehicle Specific (V.S.) 2.5 Series shocks are designed and built to give your vehicle outstanding performance off-road and a smooth ride on the street. These shocks are configured specifically for each application in both length and damping tune. Like all ICON shock absorbers, V.S. 2.5 Series shocks are 100% rebuildable and 100% revalveable. For piggyback and specific remote reservoir applications; ICON’s unique use of a 6061 billet aluminum manifold a few inches below the top cap of the shock creates an internal “Bump Zone” that when used creates an additional 20% of damping force. This additional force helps prevent harsh bottom outs and controls the suspension when compressing at high velocity. The ICON CDC Valve is an externally adjustable valve that restricts oil flow into the reservoir which creates 10 levels of compression damping force ranges. If you are looking for a more user defined tune, consider looking into the OMEGA Series bypass shocks.

KEY FEATURES:

  • ICON’s CDC Valve technology allows for 10 levels of high-resolution compression adjustability with the turn of a knob
  • ICON’s internal “Bump Zone” increases damping by 20% to provide more control as the shock approaches full compression
  • Remote reservoir design improves heat dissipation to reduce shock fade during prolonged use
  • Premium grade 5WT shock oil for consistent suspension damping along a wide temperature range
  • Nitrogen charged monotube design with piggyback reservoir
  • One piece digressive piston design with vehicle specific valving for unsurpassed performance and ride quality on and off-road
  • 7/8” diameter induction hardened, chrome plated shock shaft
  • PTFE lined spherical bearings and application specific mounting hardware
  • 6061 aircraft grade aluminum CNC machined components
  • CAD plated, precision machined 1026 DOM steel shock body for maximum durability and corrosion resistance
  • 100% Rebuildable
  • 100% Revalveable
  • Made in the U.S.A.

NOTES:

  • ICON V.S. 2.5 Series shocks are sold in pairs
  • Price listed is for two (2) shock absorbers
  • For individual shock purchase, please contact an authorized ICON dealer
746

on

ICON 0-2″ Lift Rear V.S. 2.5 Series PBR Shocks for 2009, 2010, 2011, 2012, 2013, 2014 Ford F150 2WD/4WD

Part: 97720P (old: 97700P)

OVERVIEW:

ICON Vehicle Specific (V.S.) 2.5 Series shocks are designed and built to give your vehicle outstanding performance off-road and a smooth ride on the street. These shocks are configured specifically for each application in both length and damping tune. Like all ICON shock absorbers, V.S. 2.5 Series shocks are 100% rebuildable and 100% revalveable. For piggyback and specific remote reservoir applications; ICON’s unique use of a 6061 billet aluminum manifold a few inches below the top cap of the shock creates an internal “Bump Zone” that when used creates an additional 20% of damping force. This additional force helps prevent harsh bottom outs and controls the suspension when compressing at high velocity. If you are looking for a more user defined tune, consider looking into the Compression Damping Control Valve (CDCV) or the OMEGA Series bypass shocks.

KEY FEATURES:

  • ICON’s internal “Bump Zone” increases damping by 20% to provide more control as the shock approaches full compression
  • Remote reservoir design improves heat dissipation to reduce shock fade during prolonged use
  • Premium grade 5WT shock oil for consistent suspension damping along a wide temperature range
  • Nitrogen charged monotube design with piggyback reservoir
  • One piece digressive piston design with vehicle specific valving for unsurpassed performance and ride quality on and off-road
  • 7/8” diameter induction hardened, chrome plated shock shaft
  • PTFE lined spherical bearings and application specific mounting hardware
  • 6061 aircraft grade aluminum CNC machined components
  • CAD plated, precision machined 1026 DOM steel shock body for maximum durability and corrosion resistance
  • 100% Rebuildable
  • 100% Revalveable
  • All ICON 2.5 Series Piggyback and Remote Reservoir shocks can be upgraded to ICON’s Compression Damping Control Valve (CDCV)

NOTES:

  • ICON V.S. 2.5 Series shocks are sold in pairs
  • Price listed is for two (2) shock absorbers
  • For individual shock purchase, please contact an authorized ICON dealer
513
