Bilstein 5100 4-6″ Front and 3-4″ Rear Lift Shocks +Stabilizer for 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018 Chevy/GMC Silverado/Sierra 2500HD

Important Note: If your truck is 2016 and up year, then you might need this part SuspensionMaxx Steering Stabilizer bracket for 2016-2023 Chevrolet/GMC Silverado/Sierra 2500HD/3500HD Trucks.

Front Shocks:

Notes:

  • Fits Vehicles With 4-6″ Front Lift
  • Stock mounting points only
  • Not compatible with lower control arm torsion bar relocation bracket

Series: 5100

Front Extended Length(in): 24.23

Front Collapsed Length(in): 15.98

Part Number: 24-218023

Front Shocks Fitment Notes:

Rear Shocks:

Series: 5100

Rear Extended Length(in): 29.92

Rear Collapsed Length(in): 18.17

Part Number: 24-218030

Rear Shocks Fitment Notes:

Steering Stabilizer Shock:

Series: 5100

Extended Length(in):

Collapsed Length(in):

Part Number: 33-196619

Shock Fitment Notes:

Fitment: Bilstein 5100 4-6″ Front and 3-4″ Rear Lift Shocks +Stabilizer for 11-’18 Chevy/GMC Silverado/Sierra 2500HD

BIL24-218023 x2

BIL24-218030 x2

BIL33-196619 x1



  • Set of 4 Shocks & One Steering Stabilizer – w/4-6″ Front Lift and w/3-4″ Rear Lift
  • Shock boots included with all shocks except in cases of special fitment.
  • Monotube gas charged for longevity, durability, and performance.
  • All necessary washers, bushings, and nuts included. Factory shock mounting bolts are reused for installation.
  • Bilstein’s Limited Lifetime manufacturer’s Warranty protects against defects and premature failure.

Due to their larger tires and a heightened stance, lifted vehicles place extra demands on a shock absorbers damping ability. The 5100 monotube design and patented digressive valving is uniquely suited to confront these demands. On or off-road, loaded or unloaded, Bilstein shocks instantly react to changing road inputs to maintain a stable, controlled, and comfortable ride. Bilstein’s superior monotube high gas pressure design allows the excessive heat from the oil to transfer to the outer surface of the shock body and dissipate more efficiently. The dividing piston also permits the oil to expand as heat builds, preventing aeration (foaming) and viscosity loss. This allows the shock to maintain full damping characteristics as temperatures rise.

Includes Shocks exactly as pictured

3253

on

Bilstein 5100 1.5-3″ Front and 2″ Rear Lift Shocks +Stabilizer for 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018 Jeep Wrangler (JK) 2WD/4WD

Front Shocks:

Series: 5100

Front Extended Length(in): 24.63

Front Collapsed Length(in): 14.98

Part Number: 24-146708

Front Shocks Fitment Notes: Compression bump stop on chassis may need to be modified to prevent damage to the shock absorber, Must use wheel spacers or offset aftermarket wheels.

Rear Shocks:

Series: 5100

Rear Extended Length(in): 25

Rear Collapsed Length(in): 15.39

Part Number: 24-146715

Rear Shocks Fitment Notes: Compression bump stop on chassis may need to be modified to prevent damage to the shock absorber, Must use wheel spacers or offset aftermarket wheels.

Steering Stabilizer Shock:

Series: 5100

Extended Length(in): 20.01

Collapsed Length(in): 13.19

Part Number: 24-158428

Shock Fitment Notes:

Fitment: Bilstein 5100 1.5-3″ Front and 2″ Rear Lift Shocks +Stabilizer for 07-’17 Jeep Wrangler (JK) 2WD/4WD

Brand: Bilstein – B8 5100 Series

Listing Type: Kit (5 Shocks Total)
  • 2 Front Shocks (46mm) / Part #24-146708
  • 2 Rear Shocks (46mm) / Part #24-146715
  • 1 Steering Stabilizer Shock (36mm) / Part #24-158428
Vehicle Fitment:
  • 2007-2017 Jeep Wrangler
Fitment Notes:
  • Fits 1.5″-3″ front lift & 2″ rear lift
  • Steering stabilizer is single OE replacement
  • Requires wheel spacers or offset aftermarket wheels
Tech Specs:
  • Part Number: 24-146708
    Weight (lbs): 4.63
    Old Part Number: BE5-E670
    Old Part Number: F4-BE5-E670-H0
    Series: B8 5100
    Position: Front
    Descriptor: For Front Lifted Height: 1.5-3″
    Descriptor: Must use wheel spacers or purchase aftermarket offset wheels
    Collapsed Length (IN): 14.98
    Extended Length (IN): 24.63
    Lower Mount Type: Eye 12.1mm
    Upper Mount Type: Stem
    Internal Design: Monotube
    Finish: Zinc Plated
    Reservoir: No
    Body Design: 46mm ID Smooth Body (Non-Coilover)
  • Part Number: 24-146715
    Weight (lbs): 4.63
    Old Part Number: BE5-E671
    Old Part Number: F4-BE5-E671-H0
    Series: B8 5100
    Position: Rear
    Descriptor: For Rear Lifted Height: 2″
    Descriptor: Must use wheel spacers or purchase aftermarket offset wheels
    Collapsed Length (IN): 15.39
    Extended Length (IN): 25
    Lower Mount Type: Eye 12.1mm
    Upper Mount Type: Bar Pin
    Internal Design: Monotube
    Finish: Zinc Plated
    Reservoir: No
    Body Design: 46mm ID Smooth Body (Non-Coilover)
  • Part Number: 24-158428
    Weight (lbs): 2.9
    Old Part Number: BE3-F842
    Old Part Number: F4-BE3-F842-H0
    Series: B8 5100 (Steering Damper)
    Position: Front
    Collapsed Length (IN): 13.19
    Extended Length (IN): 20.01
    Lower Mount Type: Eye 12.7mm
    Upper Mount Type: Eye 12.7mm
    Internal Design: Monotube
    Finish: Zinc Plated
    Reservoir: No
    Body Design: 36mm ID Smooth Body (Non-Coilover)
  • Bilstein B8 5100 (Ride Height Adjustable) shock absorbers are designed for trucks and SUV’s with a front OE coilover style suspension. Multiple snap-ring grooves in the body allow for different spring seat positions, providing 0-2.75 inches of front lift (depending on application). The monotube shock absorbers feature a 46mm digressive piston a with self-adjusting deflective disc valve setting. Bilstein B8 5100 (Ride Height Adjustable) shock absorbers provide increased wheel travel and improved handling. Utilizing a B8 5100 (Ride Height Adjustable) shock absorber is the easiest way to level out your vehicle.

Includes 4 Shocks and 1 Steering Stabilizer

9391

on

Bilstein 5100 Steering Stabilizer Shock 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013 Chevrolet Suburban 2500

Steering Stabilizer Shock:

Series: 5100

Extended Length(in): 20.08

Collapsed Length(in): 12.83

Part Number: 33-174525

Shock Fitment Notes:

Fitment: Bilstein 5100 Steering Stabilizer Shock 00-13 Chevrolet Suburban 2500

Important fitment notes: Steering Stabilizer
Includes Shocks exactly as pictured

813

on

Bilstein 5100 Steering Stabilizer Shock 2007, 2008, 2009, 2010 Chevrolet/GMC Silverado/Sierra 3500 HD

Steering Stabilizer Shock:

Series: 5100

Extended Length(in): 20.08

Collapsed Length(in): 12.83

Part Number: 33-174525

Shock Fitment Notes:

Fitment: Bilstein 5100 Steering Stabilizer Shock 07-10 Chevrolet/GMC Silverado/Sierra 3500 HD

Important fitment notes: Steering Stabilizer
Includes Shocks exactly as pictured
