ICON 5″ Lift Kit for 2000, 2001, 2002, 2003, 2004, 2005 Ford Excursion 4WD

Part: K45000-99

Need shocks? ICON 3-6" Lift Front Rear 2.0 Body Aluminum Shocks for 2000-2005 Ford Excursion 4WD

Overview:

Our 5” Suspension System for the 2000-2005 Excursion, isolates the use of our front and rear progressive rated springs. This system gives vlearance of 35″ tall tires and combined with the use of our ICON series Mono-tube or Reservoir Shocks, this system will give you best ride quality on and off-road. This system is price without shocks.

Technical Specs:

  • Less body-roll than stock truck
  • Progressive Rate Leaf springs
  • Lifetime guarantee that leaf springs won’t sag
  • Clears 35″ Tall Tires
  • No drive shaft modifications needed
  • 100% Bolt-on system – no drilling,cutting or welding necessary for install
  • Made in the USA
  • OEM Wheels & Tires Fitment: Yes
  • Recommended Aftermarket Wheels: ICON Alloys | 17×8.5″ w/ 5.00” Backspace / 6mm Offset
  • Recommended Aftermarket Wheels: ICON Alloys | 18×9″ w/ 5.25” Backspace / 6mm Offset
  • Recommended Aftermarket Wheels: ICON Alloys | 20×9″ w/ 5.25” Backspace / 6mm Offset
  • Recommended Aftermarket Tires: 35″ x 12.50″ (Larger tires may fit but fender trimming and modifications will be required.)
  • APPLICATION NOTE #1: FRONT U-BOLT NOTE: ALL FRONT SPRINGS COME COMPLETE WITH FRONT U-BOLTS, WASHERS, AND NUTS. WHEN ORDERING ANY FRONT SPRING SYSTEM FROM ICON VEHICLE DYNAMICS PLEASE SPECIFY MANUFACTURE YEAR.
  • APPLICATION NOTE #3: NO FRONT DRIVESHAFT MODIFICATION NEEDED. STOCK DRIVESHAFT IS FULLY FUNCTIONAL.
  • APPLICATION NOTE #6: SPRINGS ARE RATED FOR DIESEL ENGINES ONLY
  • APPLICATION NOTE #17: THESE ARE STAND-ALONE KITS AND ARE NOT TO BE USED IN CONJUNCTION WITH ANY OTHER AFTERMARKET KITS



System Contains:

  • 2×138508 – 99-07 FSD 5″ REAR LEAF SPRING PACK
  • 2×138507 – FSD 4″ FRONT LEAF SPRING PACK
  • 37001 – 00-04 FSD FRONT SEMI ROUND U-BOLT KIT
  • 31020 – Box Kit w/ Pitman Arm, Track Bar Bracket & Sway Bar Links
  • 33100 – 1″ Bump Stop Spacers
  • 37004 – Rear U-bolt Kit
  • 2×196001 3″ Shock Bar Pins
5822

on

ICON 4.5″ Lift Kit Hanger System for 2000, 2001, 2002, 2003, 2004, 2005 Ford Excursion

Part: K44000-99

Overview:

This 4.5″ system is designed to lift your Ford Excursion 4.5″ in front to provide room for 35” tires. This system drops your stock springs 4.5″, which allows for 4.5″ of lift while maintaining the stock spring rate. This system comes with a 1.75″ bump stop spacer to prevent spring fatigue during the suspension cycle.  Also included in this kit is 5” rear block kit, with 17” u-bolts for a leveled stance.  This system is the ideal for all Excursion’s.

Technical Specs:

  • Increased wheel travel
  • Durable powder coat finish
  • Less body-roll than stock truck
  • Isolates Stock springs for Factory Like Ride Quality
  • No change in towing capacity
  • No drive shaft modifications needed
  • 100%Bolt-on system – no drilling, cutting or welding necessary for install
  • Made in the USA

Wheel & Tire Fitment Info:

  • OEM Wheels & Tires:  YES
  • Aftermarket Wheels:  8 – 9″ Wide Wheels with 4.5″ Backspace
  • Aftermarket Tires:  35″ on an 8″ wide wheel  (Larger Tires & Wheels May Fit but Fender Trimming and Modifications will be Required)

System Contains:

  • 34000 – 4.5″ Front Hanger and Shackles w/ Bash Bar
  • 33100 – 1.75″ Bump Stop Spacers
  • 31020 – Front Box Kit
  • 195275 – 5” Rear Block Kit
  • 37002 – 17” Rear U-Bolt Kit
  • 196001 – Rear Bar Pins (x2)

Options:

  • 32170    99-04 Dual Steering Stabilizer Bracket Kit
  • 36511    99-Up Stabilizer (Dual Opposing) 2.0 VS IR
  • 33600    99-04 Standard Sway Bar Link Kit
  • 33700    99-04 Carrier Bearing Drop Kit
  • 33900    99-04 10.5-12″ Lift Sway Bar Link Kit
  • 39010    99-04 Dual Shock Mount Kit
  • 39012    99-04 Dual Shock Hoop Kit
  • 39290    99-04 Adjustable Track Bar
  • 39350    99-04 10.5-12″ Lift Adjustable Track Bar
  • 191000  99Early Drop Pitman Arm
  • 191001  00-04 Drop Pitman Arm
  • 194275  99-Up 4″ Block
  • 195275  99-Up 5″ Block
  • 196275  99-Up 6″ Block
  • 37002    99-10 Rear 17″ U-Bolt Kit
  • 37003    99-10 Rear 15″ U-Bolt Kit
  • 37004    99-10 Rear 12″ U-Bolt Kit

ICON Dual Steering Stabilizer Bracket Kit for 1999-2004 Ford F250 Super Duty, ICON Steering Stabilizer Shock for 1999-2020 Ford F-250/F-350 Super Duty 4WD, ICON 3-8" Lift Sway Bar Link Kit For 1999-2004 Ford Super Duty F250/F350, ICON Carrier Bearing Drop For 1999-2004 Ford Super Duty F250/F350, ICON Dual shock Mount Kit For 1999-2004 Ford Super Duty F250/F350, ICON Adjustable Pan Rod Track Bar For 1999-2004 Ford Super Duty F250/F350, ICON 4" Drop Pitman Arm For 1999-2004 Ford Super Duty F250/F350, ICON 4" Fabricated Blocks w/ Built in Bump Stop for 1999-2016 Ford F250 Super Duty, ICON 5" Fabricated Blocks w/ Built in Bump Stop for 1999-2016 Ford F250 Super Duty, ICON 6" Fabricated Blocks w/ Built in Bump Stop for 1999-2016 Ford F250 Super Duty, ICON 17" Rear Long U-bolt Kit (Non Dually) for 1999-2010 Ford F250 Super Duty, ICON 15" Long U-bolt Kit (Non Dually) for 1999-2010 Ford F250 Super Duty, ICON 12" Rear Long U-bolt Kit (Non Dually) for 1999-2010 Ford F250 Super Duty

1357

on

Bilstein Reservoir Mounting Clamps – Billet Aluminum for 5160 and 5165 Reservoir Shocks

Part: 2 x 11-176015

Sold as a pair

These Bilstein B1 reservoir mounting clamps are designed specifically for Bilstein B8 5160 and B8 5165 remote reservoir shocks. Made from high-quality billet aluminum, they securely hold the reservoir in place on the shock body, keeping it properly positioned even during aggressive off-road use. The clamp is a two-piece design, making installation quick and straightforward, and it uses heavy duty stainless steel hardware for long-term durability.

The black anodized finish protects the clamps from corrosion and harsh trail environments, ensuring they continue to perform and look good over time.

Features

  • Billet aluminum construction
  • Works with Bilstein 5160 and 5165 reservoir shocks
  • Two-piece clamp for easy installation
  • Heavy duty stainless steel bolts included
  • Black anodized finish for corrosion resistance
  • Perfect for securing remote reservoirs during off-road use
  • Includes 2 clamps

Frequently Asked Questions

Do these clamps fit all Bilstein 5160 and 5165 shocks?
Yes. They are designed specifically for B8 5160 and B8 5165 reservoir shock bodies.

Are these billet aluminum clamps stronger than plastic brackets?
Yes. Billet aluminum provides a much stronger and more secure reservoir hold, especially off-road.

Are stainless steel bolts included?
Yes. Each pair comes with stainless hardware for mounting.

How many clamps are included?
You receive 2 clamps per set.

14040

on

ICON 3″ Lift Kit Hanger System for 2000, 2001, 2002, 2003, 2004, 2005 Ford Excursion

Part: K43000-99

Overview:

This 3″ system is designed to lift your Ford Excursion 3″ in front to provide room for 33” tires. This system drops your stock springs 3″, which allows for 3″ of lift while maintaining the stock spring rate. This system comes with a 1″ bump stop spacer (not pictured) to prevent spring fatigue during the suspension cycle.  This system is the ideal for all Excursion’s.

Technical Specs:

  • Increased wheel travel
  • Durable powder coat finish
  • Less body-roll than stock truck
  • Isolates Stock springs for Factory Like Ride Quality
  • No change in towing capacity
  • No drive shaft modifications needed
  • 100%Bolt-on system – no drilling,cutting or welding necessary for install
  • Made in the USA

Wheel & Tire Fitment Info:

  • OEM Wheels & Tires:  YES
  • Aftermarket Wheels:  8 – 9″ Wide Wheels with 4.5″ Backspace
  • Aftermarket Tires:  34″ on an 8″ wide wheel  (Larger Tires & Wheels May Fit but Fender Trimming and Modifications will be Required)

System Contains:

  • 33000 – 3″ Front Hanger and Shackles w/ Bash Bar
  • 33100 – 1″ Bump Stop Spacers
  • 194275 – 4″ Block Kit
  • 37003 – 99-Up Rear 15″ U-Bolt
  • 196001 – Excursion Rear Bar Pin (x2)

Options:

  • 32170    99-04 Dual Steering Stabilizer Bracket Kit
  • 36511    99-Up Stabilizer (Dual Opposing) 2.0 VS IR
  • 33600    99-04 Standard Sway Bar Link Kit
  • 39010    99-04 Dual Shock Mount Kit
  • 39012    99-04 Dual Shock Hoop Kit
  • 39290    99-04 Adjustable Track Bar
  • 191001  00-04 Drop Pitman Arm
  • 194275  99-Up 4″ Block
  • 195275  99-Up 5″ Block
  • 196275  99-Up 6″ Block
  • 37002    99-10 Rear 17″ U-Bolt Kit
  • 37003    99-10 Rear 15″ U-Bolt Kit
  • 37004    99-10 Rear 12″ U-Bolt Kit

ICON Dual Steering Stabilizer Bracket Kit for 1999-2004 Ford F250 Super Duty, ICON Steering Stabilizer Shock for 1999-2020 Ford F-250/F-350 Super Duty 4WD, ICON 3-8" Lift Sway Bar Link Kit For 1999-2004 Ford Super Duty F250/F350, ICON Dual shock Mount Kit For 1999-2004 Ford Super Duty F250/F350, ICON Adjustable Pan Rod Track Bar For 1999-2004 Ford Super Duty F250/F350, ICON 4" Drop Pitman Arm For 1999-2004 Ford Super Duty F250/F350, ICON 4" Fabricated Blocks w/ Built in Bump Stop for 1999-2016 Ford F250 Super Duty, ICON 5" Fabricated Blocks w/ Built in Bump Stop for 1999-2016 Ford F250 Super Duty, ICON 6" Fabricated Blocks w/ Built in Bump Stop for 1999-2016 Ford F250 Super Duty, ICON 17" Rear Long U-bolt Kit (Non Dually) for 1999-2010 Ford F250 Super Duty, ICON 15" Long U-bolt Kit (Non Dually) for 1999-2010 Ford F250 Super Duty, ICON 12" Rear Long U-bolt Kit (Non Dually) for 1999-2010 Ford F250 Super Duty
