Zone Offroad 3.5″ Upper Control Arms Lift Kit 2007, 2008, 2009, 2010, 2011, 2012, 2013 Chevy/GMC 1500 2WD

Part: C30

Zone Offroad 2007-2013 Chevy 1500 2wd 3.5″ Adventure Series Lift System.

Just like the Zone Offroad 1500 Ram Adventure Series Kits, this system is built around the Zone Offroad heavy-duty replacement upper control arms. Made from fully weld 1/8″ steel plate construction as well as CNC machined ball joint and bushing mounts, these arms dwarf the factory components. In addition to overall strength of construction, the new arms trump the factory components by providing more range of motion. The arms utilize high quality MOOG brand ball joints that can handle heavy duty use and work in conjunction with OE-style rubber mount bushings to provide a quiet ride.

The ball joints are greaseable and easily replaced with readily available parts at the end of their service. Proper brake line attachment points are included on the arms where needed for a factory-like fit. Matching the construction and quality of the new UCAs is a fully integrated front differential drop and differential skid plate system that relocates the differential for optimal driveline angles.

The included strut spacers provide a full 3.5″ of lift and install easily on the factory struts without the need of a strut compressor. In order to match up rear with the newly lifted front, a 3″ block and u-bolt system is included that replaces the factory 1″ block to net 2″ and provide an overall level vehicle stance. The choice of standard hydraulic or Nitro rear shocks rounds out the kit.

Featured Technology & Benefits

  • Fully welded, heavy duty upper control arms that dwarf the factory arms.
  • CNC-machined UCA bushing and ball joint cups.
  • OE rubber bushings and greasable factory style ball joints for quiet, reliable, and low maintenance operation.
  • Improved UCA range of motion compared to stock arms
  • UCAs utilize replaceable ball joints

Important Notes!

  • *Kit images show upgraded Nitro (black) shocks*
  • Certain tire/wheel packages can fit with the addition of the provided weld-on steering stops. These are necessary for deeper backspaced wheels to maintain proper tire clearance to the new upper control arms.
  • Minor frame and front differential trimming required – see installation instructions for details
  • Do Not combine with any other suspension lift
  • Does Not Fit 4WD Models
  • Will not fit 2007 classic body style (aka 99-06)

This product fits the following applications:

  • 2007 Chevy 1500 Pickup 2WD
  • 2008 Chevy 1500 Pickup 2WD
  • 2009 Chevy 1500 Pickup 2WD
  • 2010 Chevy 1500 Pickup 2WD
  • 2011 Chevy 1500 Pickup 2WD
  • 2012 Chevy 1500 Pickup 2WD
  • 2013 Chevy 1500 Pickup 2WD
  • 2007 GMC 1500 Pickup 2WD
  • 2008 GMC 1500 Pickup 2WD
  • 2009 GMC 1500 Pickup 2WD
  • 2010 GMC 1500 Pickup 2WD
  • 2011 GMC 1500 Pickup 2WD
  • 2012 GMC 1500 Pickup 2WD
  • 2013 GMC 1500 Pickup 2WD
1074

on

Zone Offroad 3.5″ Strut Spacers/leveling+body lift kit 2014,2015 Chevy/GMC Silverado/Sierra 1500

Part: C1351

Adding to our popular Chevy line of unique combo kits, this system is inexpensive and easy to install. By combining a front 2″ suspension leveling kit and 1.5″ body lift the truck will set level and allow for 33″ tall tires. The 1.5″ body lifts gives that extra bit of height and tire clearance without showing off too much of the frame.

The kit comes complete with everything needed to properly lift the body and bumpers of the new ’14 Chevy/GMs. High-strength class 10.9 body mount bolts are included to insure the crush-proof body lift blocks stay put for the long haul. The front bumper brackets install easily and properly align the bumper with the lifted body. The rear bumper brackets are full-replacement design. No trimming of the stock brackets necessary.

The leveling kit portion of the combo kit is straight forward and easy to install. This design hasn’t change since 2007 making it one of our most popular leveling kits. Detailed instructions are included to make the entire installation go smoothly.

Featured Technology & Benefits

  • Maintains Factory Ride
  • Fast and Easy Install
  • 100% Made in the USA
  • Complete and Detailed Instructions

Important Notes!

  • Will NOT fit models equipped with stamped steel control arms.

This product fits the following applications:

  • 2014 Chevy 1500 Pickup 2WD/4WD
  • 2015 Chevy 1500 Pickup 2WD/4WD
  • 2014 GMC 1500 Pickup 2WD/4WD
  • 2015 GMC 1500 Pickup 2WD/4WD

Quick Specs

  • Front Lift Height: 3.5
  • Front Lift Method: Strut Spacers/Body Blocks
  • Rear Lift Height: 1.5″
  • Rear Lift Method: Body Blocks
  • Install Time Hrs: 4-5
  • Difficulty Level 1-5: 3
  • Back Spacing: Stock
  • Max Tire Size: 33×12.50
1267

on

Zone Offroad 3-1/2″ Strut Spacers & leveling+body lift kit 2007-2013 Silverado/Sierra 1500

Part: C1350

Looking for an affordable lift to clear 33’s? Spacer kits with more than 2″ of lift cause premature wearing of the upper ball joints. Upper control arm lifts with new joints lead to increased camber changes during suspension travel. Zone Offroad has engineered the perfect, best performing solution. We’ve combined a 2″ leveling lift with a 1.5″ body lift to give optimum performance at a budget price.

This system fits 2007 – 2013 models with the new body style. If your 2007 is the Classic body style you will need to purchase the Zone Combo Kit 1352

Featured Technology & Benefits

  • Maintains factory ride.
  • Front bumper is relocated for factory look.
  • Grade 10.9 body bolts included
  • No strut compressor required for installation
  • Easy to follow – detailed instructions

Important Notes!

  • Will not fit 2007 Classic models.
  • Will not fit Denali models.
  • The optional rear bumper relocation system is for appearance only and cannot be used for towing.

This product fits the following applications:

  • 2007 Chevy 1500 Pickup 2WD/4WD
  • 2008 Chevy 1500 Pickup 2WD/4WD
  • 2009 Chevy 1500 Pickup 2WD/4WD
  • 2010 Chevy 1500 Pickup 2WD/4WD
  • 2011 Chevy 1500 Pickup 2WD/4WD
  • 2012 Chevy 1500 Pickup 2WD/4WD
  • 2013 Chevy 1500 Pickup 2WD/4WD
  • 2007 GMC 1500 Pickup 2WD/4WD
  • 2008 GMC 1500 Pickup 2WD/4WD
  • 2009 GMC 1500 Pickup 2WD/4WD
  • 2010 GMC 1500 Pickup 2WD/4WD
  • 2011 GMC 1500 Pickup 2WD/4WD
  • 2012 GMC 1500 Pickup 2WD/4WD
  • 2013 GMC 1500 Pickup 2WD/4WD

Quick Specs

  • Front Lift Height: 3 1/2″
  • Front Lift Method: Strut Spacers & Body Lift
  • Install Time Hrs: 3
  • Difficulty Level 1-5: 2
  • Wheel Size: Stock
  • Back Spacing: Stock
  • Max Tire Size: 33×12.50
2493

on

Zone Offroad 3.5″ UCA & leveling+body lift kit 2012, 2013, 2014, 2015, 2016, 2017, 2018 Dodge/Ram Ram 1500 4WD

Part: D59

This combo kit brings together the great features of our popular line of 1.5″ Ram Body Lifts and Adventure Series Upper Control Arm suspension systems. What you get is a perfect combination to clear a 35″ tire at a very affordable price without skimping on features or performance, including massive replacement UCAs, strut spacer system and differential relocation.

This kit utilizes the same UCAs with a slightly different strut spacer system and does not require the differential relocation.

Everything is included for the body lift to properly lift the body and bumpers 1.5″.

Featured Technology & Benefits

  • Combo Package: 2″ Adventure Series (UCA) System & 1.5″ Body Lift
  • Includes Heavy Duty Upper Control Arms w/ Replaceable Ball Joints
  • Allows up to a 35×12.50
  • Limited Lifetime Warranty

Important Notes!

  • Will not work on MegaCab models
  • Will work with 3.0L V6 Diesel models
  • Rear bumper relocation is for appearance only and cannot be used for towing. Standard receiver hitch function is not affected
  • Not to be used with any other form of leveling/lifting suspension systems

This product fits the following applications:

  • 2012 Dodge/Ram Ram 1500 4WD
  • 2013 Dodge/Ram Ram 1500 4WD
  • 2014 Dodge/Ram Ram 1500 4WD
  • 2015 Dodge/Ram Ram 1500 4WD
  • 2016 Dodge/Ram Ram 1500 4WD
  • 2017 Dodge/Ram Ram 1500 4WD
  • 2018 Dodge/Ram Ram 1500 4WD

Quick Specs

  • Front Lift Height: 3 1/2″
  • Front Lift Method: UCA & Body Lift
  • Install Time Hrs: 6
  • Difficulty Level 1-5: 3
  • Wheel Size: 17×9
  • Back Spacing: 4.75″ – 5″
  • Max Tire Size: 35×12.50
3762
