Zone Offroad 3.5″ Upper Control Arms Lift Kit 2007-2013 Chevy/GMC 1500 4WD

Part: C29

Zone Offroad 2007-2013 Chevy 1500 4wd 3.5″ Adventure Series Lift System. Just like the Zone Offroad 1500 Ram Adventure Series Kits, this system is built around the Zone Offroad heavy-duty replacement upper control arms. Made from fully weld 1/8″ steel plate construction as well as CNC machined ball joint and bushing mounts, these arms dwarf the factory components. In addition to overall strength of construction, the new arms trump the factory components by providing more range of motion. The arms utilize high quality MOOG brand ball joints that can handle heavy duty use and work in conjunction with OE-style rubber mount bushings to provide a quiet ride. The ball joints are greaseable and easily replaced with readily available parts at the end of their service. Proper brake line attachment points are included on the arms where needed for a factory-like fit. Matching the construction and quality of the new UCAs is a fully integrated front differential drop and differential skid plate system that relocates the differential for optimal driveline angles. The included strut spacers provide a full 3.5″ of lift and install easily on the factory struts without the need of a strut compressor. In order to match up rear with the newly lifted front, a 3″ block and u-bolt system is included that replaces the factory 1″ block to net 2″ and provide an overall level vehicle stance. The choice of standard hydraulic or Nitro rear shocks rounds out the kit.

Featured Technology & Benefits

  • Fully welded, heavy duty upper control arms that dwarf the factory arms.
  • CNC-machined UCA bushing and ball joint cups.
  • OE rubber bushings and greasable factory style ball joints for quiet, reliable, and low maintenance operation.
  • Improved UCA range of motion compared to stock arms
  • UCAs utilize replaceable ball joints and bushings
  • Fully integraded front differential drop and skid plate for optimal driveline angles

Important Notes!

  • *Kit images show upgraded Nitro (black) shocks*
  • Certain tire/wheel packages can fit with the addition of the provided weld-on steering stops. These are necessary for deeper backspaced wheels to maintain proper tire clearance to the new upper control arms.
  • Minor frame and front differential trimming required – see installation instructions for details
  • Do Not combine with any other suspension lift
  • Will not fit 2007 classic body style (aka 99-06)

This product fits the following applications:

  • 2007 Chevy 1500 Pickup 4WD
  • 2008 Chevy 1500 Pickup 4WD
  • 2009 Chevy 1500 Pickup 4WD
  • 2010 Chevy 1500 Pickup 4WD
  • 2011 Chevy 1500 Pickup 4WD
  • 2012 Chevy 1500 Pickup 4WD
  • 2013 Chevy 1500 Pickup 4WD
  • 2007 GMC 1500 Pickup 4WD
  • 2008 GMC 1500 Pickup 4WD
  • 2009 GMC 1500 Pickup 4WD
  • 2010 GMC 1500 Pickup 4WD
  • 2011 GMC 1500 Pickup 4WD
  • 2012 GMC 1500 Pickup 4WD
  • 2013 GMC 1500 Pickup 4WD

Quick Specs

  • Front Lift Height: 3.5
  • Front Lift Method: Upper Control Arms
  • Rear Lift Height: 2
  • Rear Lift Method: Block
  • Install Time Hrs: 3-4
  • Difficulty Level 1-5: 3
  • Wheel Size: 17″
  • Back Spacing: 5″
  • Max Tire Size: 285/70-17
1720

on

Zone Offroad 3-1/2″ Torsion Bar Keys & leveling+body lift kit  2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012 Colorado/Canyon

Part: C1355

Zone Offroad has developed a comprehensive 3.5″ lift kit that combines the Zone 1.5″ body lift and Zone 2″ front and rear lift kit. The benefit? A package priced kit that is nearly the height of a 4″ suspension system and below the cost of a 3″ body lift. Not only does it avoid the frame to body gap caused by taller body lifts, but it has the capability to clear 32’s or even 33″ tires with trimming that is outlined in the instructions.

The body lift includes class 10.9 zinc plated body hardware, crush proof body lift blocks, fully integrated radiator relocation mounts, tow hook relocation and front bumper relocation. The radiator relocation utilizes a complete replacement set of radiator mounts that eliminate the need to modify the steel core support or fan shroud. This ensures proper airflow through the radiator and no loss of core support structural strength. Based on model year, Zone offers two rear bumper bracket kits that relocate the bumpers to maintain the factory relationship with the body while still leaving the factory receiver hitch in the stock location and functional.

Zone Offroad torsion bar keys are made in the USA and are 100% resonant frequency tested to ensure a solid casting. This easy to install torsion bar key leveling kit is designed to lift the front of your Chevrolet Colorado or GMC Canyon 2 inches. The kit includes front shock spacers to not only compensate for the added lift, but gain wheel travel by allowing the suspension to fully droop to the factory frame limiter. The rear is lifted with a pair of add-a-leafs for added capacity and reduced axle wrap. Zone Offroad rear shocks are available in the above upgrade section.

Featured Technology & Benefits

  • Body Lift Features
  • Class 10.9 zinc plated hardware
  • Fully integrated radiator relocation mounts
  • Front bumper 1.5″ spacers and detailed trimming instructions
  • Tow hook relocation & reinforcement included
  • Suspension Lift Features
  • 100% resonant frequency tested torsion keys
  • Includes front shock spacers
  • Add-a-leaf will lift the rear while reducing unwanted spring wrap and improved towing or hauling peformance.
  • Optional custom valved rear shocks available in the accessories

Important Notes!

  • For automatic transmission models only
  • Works with all cab configurations
  • Trimming of front bumper plastic valance or frame required for front bumper relocation
  • Bumper hitch not for towing after lifting rear bumper, factory/aftermarket receivers are not affected by lift
  • Radiator & condenser brackets not designed for V8 models.
  • Welding optional and required only if front factory tow hooks are retained.

This product fits the following applications:

  • 2004 Chevy Colorado 4WD
  • 2005 Chevy Colorado 4WD
  • 2006 Chevy Colorado 4WD
  • 2007 Chevy Colorado 4WD
  • 2008 Chevy Colorado 4WD
  • 2009 Chevy Colorado 4WD
  • 2010 Chevy Colorado 4WD
  • 2011 Chevy Colorado 4WD
  • 2012 Chevy Colorado 4WD
  • 2004 GMC Canyon 4WD
  • 2005 GMC Canyon 4WD
  • 2006 GMC Canyon 4WD
  • 2007 GMC Canyon 4WD
  • 2008 GMC Canyon 4WD
  • 2009 GMC Canyon 4WD
  • 2010 GMC Canyon 4WD
  • 2011 GMC Canyon 4WD
  • 2012 GMC Canyon 4WD

Quick Specs

  • Front Lift Height: 3.5″
  • Front Lift Method: Torsion Bar Keys & Body Lift
  • Rear Lift Height: 3″
  • Rear Lift Method: Add-A-Leafs & Body Lift
  • Install Time Hrs: 4-5
  • Difficulty Level 1-5: 3
  • Wheel Size: 16×8
  • Back Spacing: 5″
  • Max Tire Size: 32×11.50
4322

on

Zone Offroad 3-1/2″ Torsion Bar Keys & leveling+body lift kit 2006, 2007 Silverado/Sierra 1500

Part: C1352

If you’re looking to go taller than 2″ but are not interested in the expense of a full IFS system, our 3.5″ combination lift is the answer. Beware of torsion key systems taller than 2″ that can adversely affect your ride. This system will clear 33’s with your stock wheels for a clean lift at a low cost.

Featured Technology & Benefits

  • Maintains factory ride.
  • Front bumper is relocated for factory look.
  • Grade 10.9 body bolts included
  • Easy to follow – detailed instructions

Important Notes!

  • The optional rear bumper relocation system is for appearance only. The rear bumper cannot be used for towing after installation of the rear bumper relocation system. Factory or aftermarket receivers are not affected by lift.
  • This system fits 2006 and the 2007 Classic model.
  • Will not fit HD models.
  • Torision bar unloading tool required.

This product fits the following applications:

  • 2006 Chevy 1500 Pickup 4WD
  • 2007 Chevy 1500 Pickup 4WD
  • 2006 GMC 1500 Pickup 4WD
  • 2007 GMC 1500 Pickup 4WD

Quick Specs

  • Front Lift Height: 3 1/2″
  • Front Lift Method: Torsion Bar Keys & Body Lift
  • Rear Lift Height: 1.5″
  • Rear Lift Method: Body Lift
  • Install Time Hrs: 4
  • Difficulty Level 1-5: 2
  • Max Tire Size: 33 x12.50 on sto
971

on

Zone Offroad 3-1/2″ Torsion Bar Keys & leveling+body lift kit 2003-2005 Silverado/Sierra 1500

Part: C1353

If you’re looking to go taller than 2″ but are not interested in the expense of a full IFS system, our 3.5″ combination lift is the answer. Beware of torsion key systems taller than 2″ that can adversely affect your ride. This system will clear 33’s with your stock wheels for a clean lift at a low cost.

Featured Technology & Benefits

  • Maintains factory ride.
  • Front bumper is relocated for factory look.
  • Grade 10.9 body bolts included
  • Easy to follow – detailed instructions

Important Notes!

  • Will not fit Denali or 1500 HD models.
  • If rear bumper bracket system is purchased and installed, the rear bumper connot be used for towing. The rear bumper system is for appearance only.
  • Torsion bar unloading tool required for install.
  • C1352 & C9152 systems do not fit new body style 2007
  • models.

This product fits the following applications:

  • 2003 Chevy 1500 Pickup 4WD
  • 2004 Chevy 1500 Pickup 4WD
  • 2005 Chevy 1500 Pickup 4WD
  • 2003 GMC 1500 Pickup 4WD
  • 2004 GMC 1500 Pickup 4WD
  • 2005 GMC 1500 Pickup 4WD

Quick Specs

  • Front Lift Height: 3 1/2″
  • Front Lift Method: Torsion Bar Keys & Body Lift
  • Rear Lift Height: 1.5″
  • Rear Lift Method: Body Lift
  • Install Time Hrs: 4
  • Difficulty Level 1-5: 2
  • Max Tire Size: 33 x12.50 on sto
823
