Zone Offroad 3-1/2″ Torsion Bar Keys & leveling+body lift kit 1999, 2000, 2001, 2002 Chevrolet Silverado 1500

Part: C1354

If you’re looking to go taller than 2″ but are not interested in the expense of a full IFS system, our 3.5″ combination lift is the answer. Beware of torsion key systems taller than 2″ that can adversely affect your ride. This system will clear 33’s with your stock wheels for a clean lift at a low cost.

Featured Technology & Benefits

  • Maintains factory ride.
  • Front bumper is relocated for factory look.
  • Grade 10.9 body bolts included
  • Easy to follow – detailed instructions

Important Notes!

  • Will not fit HD models.
  • If rear bumper bracket system is purchased and installed, the rear bumper connot be used for towing. The rear bumper system is for appearance only.
  • Torsion bar unloading tool required for install.
  • C1352 & C9152 systems do not fit new body style 2007
  • models.

This product fits the following applications:

  • 1999 Chevy 1500 Pickup 4WD
  • 2000 Chevy 1500 Pickup 4WD
  • 2001 Chevy 1500 Pickup 4WD
  • 2002 Chevy 1500 Pickup 4WD
  • 1999 GMC 1500 Pickup 4WD
  • 2000 GMC 1500 Pickup 4WD
  • 2001 GMC 1500 Pickup 4WD
  • 2002 GMC 1500 Pickup 4WD

Quick Specs

  • Front Lift Height: 3 1/2″
  • Front Lift Method: Torsion Bar Keys & Body Lift
  • Rear Lift Height: 1.5″
  • Rear Lift Method: Body Lift
  • Install Time Hrs: 4
  • Difficulty Level 1-5: 2
  • Max Tire Size: 33 x12.50 on sto
754

on

Bilstein 4600 Stock Height Rear Shocks for 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004 Toyota Tacoma 6-lug 2WD/4WD

Part: 24-184960_24-184977

Stock Height Rear Shocks

Rear left:
* * *
Extended Length (IN): 19.61 Inch
Compressed Length (IN): 12.8 Inch
Rod Diameter (IN): 1.81 Inch
Upper Mounting Style: Eyelet
Lower Mounting Style: Eyelet
– – – – –

Rear right:
* * *
Extended Length (IN): 20.28 Inch
Compressed Length (IN): 13.19 Inch
Rod Diameter (IN): 1.81 Inch
Upper Mounting Style: Eyelet
Lower Mounting Style: Eyelet

Fitment: Bilstein 4600 Stock Height Rear Shocks for 1995-2004 Toyota Tacoma 2WD/4WD

Important fitment notes:
Includes Shocks exactly as pictured

11941

on

ICON 1.5-3.5″ Lift Kit Stage 2 for 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021 Toyota Land Cruiser 200

Part: K53072

OVERVIEW:

The 200 Series Toyota Land Cruiser is a luxurious vehicle packed with “all the bells and whistles”, but underneath all of the sophistication it is still a very capable vehicle that sees heavy use both on and off-road worldwide. While the 200 Series has exceptional ride characteristics in stock form, it is clear that the suspension is in need of a serious upgrade if the vehicle is to serve any measurable amount of time in the dirt. ICON Vehicle Dynamics has addressed this need for a comprehensive suspension solution and is proud to re-introduce several suspension systems that drastically increase the overall ability of the 2008-UP Toyota Land Cruiser.



KEY FEATURES:

  • Increased wheel travel and ride quality over stock
  • Improved vehicle dynamics and decreased body roll
  • Height adjustable coilovers provide 1.5-3.5″ of lift height
  • ICON engineered dual rate rear coil springs
  • Vehicle-specific tuned front and rear shocks provide superior damping and control
  • Corrosion resistant CAD plated shock bodies with 7/8″ shafts (2.5 Series) or 1” shafts (3.0 Series)
  • CDCV technology allows for quick and easy compression damping adjustment without the need for tools
  • Shocks are fully rebuildable and revalveable
  • Bolt-on design means no cutting or welding necessary for install



WHEEL & TIRE FITMENT INFO:

OEM Wheels & Tires: Yes

Aftermarket Wheels: 8-8.5″ Wide, 5.75″ Backspace

Aftermarket Tires: 34 x 10.50

(Larger Tires May Fit but Fender Trimming and Modifications will be Required)



SYSTEM COMPONENTS:

58760 (QTY.1) | 08-UP LAND CRUISER (200 SERIES) 2.5 VS RR COILOVER KIT

52750 (QTY.1) | 08-UP LAND CRUISER (200 SERIES) REAR 1.75″ DUAL RATE SPRING KIT

57825P (QTY.1) | 08-UP LAND CRUISER (200 SERIES) REAR 2.5 VS RR PAIR

OPTIONS:

98570        2008-Up Land Cruiser 200 Series Billet Uniball Upper Control Arm Kit

58760C      2008-Up Land Cruiser 200 Series (0-3″ Lift) Remote Reservoir Coilover Shocks w/ CDCV

57825CP    2008-Up Land Cruiser 200 Series (0-2″ Lift) 2.5″ V.S. Series Remote Reservoir Rear Shocks w/ CDCV

54000   08-UP LAND CRUISER (200 SERIES) BILLET LOWER TRAILING ARM KIT

58570DJ   08-UP LAND CRUISER (200 SERIES) LAND CRUISER BILLET UCA DJ KIT

198000     ICON 2 Pin Spanner Wrench for Adjusting Ride Height of Coilover Shocks

191009     ICON Coilover Shock Wraps

ICON Front Remote Reservoir Coil Over Shock Kit w/ CDCV for 2008-2021 Toyota Land Cruiser 200 Series, ICON 0-2" Lift Rear V.S. 2.5 Series RR w/CDCV Shocks for 2008-2021 Toyota Land Cruiser 200 Series, ICON Aluminum Lower Rear Trailing Arms for 2007-2014 Toyota FJ Cruiser, ICON Delta Joint Billet Aluminum Upper Control Arm Kit For 2008-2021 Toyota Land Cruiser 200 Series, ICON 2 pin Spanner Wrench – ALL ICON Coilover Shocks, ICON Shock Wraps Neoprene Coil Over Shock Protection Covers (large)

9296

on

ICON 1.5-3.5″ Lift Kit for 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021 Toyota Land Cruiser 200

Part: K53071

OVERVIEW:

The 200 Series Toyota Land Cruiser is a luxurious vehicle packed with “all the bells and whistles”, but underneath all of the sophistication it is still a very capable vehicle that sees heavy use both on and off-road worldwide. While the 200 Series has exceptional ride characteristics in stock form, it is clear that the suspension is in need of a serious upgrade if the vehicle is to serve any measurable amount of time in the dirt. ICON Vehicle Dynamics has addressed this need for a comprehensive suspension solution and is proud to re-introduce several suspension systems that drastically increase the overall ability of the 2008-UP Toyota Land Cruiser.



KEY FEATURES:

  • Increased wheel travel and ride quality over stock
  • Improved vehicle dynamics and decreased body roll
  • Height adjustable coilovers provide 1.5-3.5″ of lift height
  • ICON engineered dual rate rear coil springs
  • Vehicle-specific tuned front and rear shocks provide superior damping and control
  • Corrosion resistant CAD plated shock bodies with 7/8″ shafts
  • CDCV technology allows for quick and easy compression damping adjustment without the need for tools
  • Shocks are fully rebuildable and revalveable
  • Bolt-on design means no cutting or welding necessary for install

WHEEL & TIRE FITMENT INFO:

OEM Wheels & Tires: Yes

Aftermarket Wheels: 8-8.5″ Wide, 5.75″ Backspace

Aftermarket Tires: 34 x 10.50

(Larger Tires May Fit but Fender Trimming and Modifications will be Required)



SYSTEM COMPONENTS:

58660 (QTY.1) | 08-UP LAND CRUISER (200 SERIES) 2.5 VS IR COILOVER KIT

52750 (QTY.1) | 08-UP LAND CRUISER (200 SERIES) REAR 1.75″ DUAL RATE SPRING KIT

57625P (QTY.1) | 08-UP LAND CRUISER (200 SERIES) REAR 2.5 VS NR PAIR

OPTIONS:

98570        2008-Up Land Cruiser 200 Series Billet Uniball Upper Control Arm Kit

58760        2008-Up Land Cruiser 200 Series (0-3″ Lift) Remote Reservoir Coilover Shocks

58760C      2008-Up Land Cruiser 200 Series (0-3″ Lift) Remote Reservoir Coilover Shocks w/ CDCV

57825P      2008-Up Land Cruiser 200 Series (0-2″ Lift) 2.5″ V.S. Series Remote Reservoir Rear Shocks

57825CP    2008-Up Land Cruiser 200 Series (0-2″ Lift) 2.5″ V.S. Series Remote Reservoir Rear Shocks w/ CDCV

54000   08-UP LAND CRUISER (200 SERIES) BILLET LOWER TRAILING ARM KIT

58570DJ   08-UP LAND CRUISER (200 SERIES) LAND CRUISER BILLET UCA DJ KIT

198000     ICON 2 Pin Spanner Wrench for Adjusting Ride Height of Coilover Shocks

191009     ICON Coilover Shock Wraps

ICON Front Remote Reservoir Coil Over Shock Kit for 2008-2021 Toyota Land Cruiser 200 Series, ICON Front Remote Reservoir Coil Over Shock Kit w/ CDCV for 2008-2021 Toyota Land Cruiser 200 Series, ICON 0-2" Lift Rear Remote Reservoir Shocks for 2008-2021 Toyota Land Cruiser 200 Series, ICON 0-2" Lift Rear V.S. 2.5 Series RR w/CDCV Shocks for 2008-2021 Toyota Land Cruiser 200 Series, ICON Aluminum Lower Rear Trailing Arms for 2007-2014 Toyota FJ Cruiser, ICON Delta Joint Billet Aluminum Upper Control Arm Kit For 2008-2021 Toyota Land Cruiser 200 Series, ICON 2 pin Spanner Wrench – ALL ICON Coilover Shocks, ICON Shock Wraps Neoprene Coil Over Shock Protection Covers (large)
