Zone Offroad 4″ Strut Spacers & leveling+body lift kit 2007, 2008, 2009, 2010 Chevy/GMC SUV

Part: C1400

Want a 4″ lift without breaking the bank? This combo kit includes Zone’s 2″ front leveling kit plus a 2″ body lift. This combination will allow you to run 33’s on those stock wheels. Perfect for a lift on a budget.

Featured Technology & Benefits

  • Maintains factory ride.
  • Front bumper is relocated for factory look.
  • Grade 10.9 body bolts included.
  • No strut compressor required for installation.
  • Easy to follow – detailed instructions.

Important Notes!

  • This is for new body style 2007 only. Will not fit classic models.
  • Bumper Brackets will not fit Avalanche models.
  • Autoride equipped vehicles will need the ride height sensor linkage to be lengthened.
  • Will not fit denali models

This product fits the following applications:

  • 2007 Chevy Suburban 1500 2WD/4WD
  • 2008 Chevy Suburban 1500 2WD/4WD
  • 2009 Chevy Suburban 1500 2WD/4WD
  • 2010 Chevy Suburban 1500 2WD/4WD
  • 2007 Chevy Tahoe 2WD/4WD
  • 2008 Chevy Tahoe 2WD/4WD
  • 2009 Chevy Tahoe 2WD/4WD
  • 2010 Chevy Tahoe 2WD/4WD
  • 2007 GMC Yukon 2WD/4WD
  • 2008 GMC Yukon 2WD/4WD
  • 2009 GMC Yukon 2WD/4WD
  • 2010 GMC Yukon 2WD/4WD
  • 2007 GMC Yukon XL 1500 2WD/4WD
  • 2008 GMC Yukon XL 1500 2WD/4WD
  • 2009 GMC Yukon XL 1500 2WD/4WD
  • 2010 GMC Yukon XL 1500 2WD/4WD

Quick Specs

  • Front Lift Height: 4″
  • Front Lift Method: Strut Spacers & Body Lift
  • Rear Lift Height: 2″
  • Rear Lift Method: Body Lift
  • Install Time Hrs: 6-8 hrs
  • Difficulty Level 1-5: 3
  • Wheel Size: stock
  • Back Spacing: stock
  • Max Tire Size: 33 x 11.50
1440

on

Zone Offroad 4″ Strut Spacer 2014 Ford F150 4WD

Part: F41

Zone Offroad 2014 Ford F150 4″ Suspension System.

This 4″ lift uses many of the heavy duty components from our 6″ lift. Full width crossmembers and beefy steering knuckles as well as proper differential drop brackets and a differential skid plate make this one tough kit. Like the 6″ kit, this 4″ kit uses new bolt-on upper strut spacers that work with the new 2014 strut configuration. The bolt-on spacer does not require disassembly of the strut (no strut compressor). In the rear a 4″ lift block is used after removing the factory block and nets a level-to-slightly tail high stance.

The kit is available with standard or Nitro rear shocks.

Featured Technology & Benefits

  • CNC Machined Steering Knuckles correctly drilled for the application
  • Heavy 1/4″ thick crossmembers
  • No Track Width Change
  • Differential Skid Plate Included

Important Notes!

  • AWD models will require front driveshaft modification
  • Will not work with 17″ wheels
  • If using 18×9 wheels with 5.5″ backspace, fit the wheels before mounting to check for proper tie rod clearance. Wheel manufacturing variances may affect this clearance.
  • Vehicles equipped with factory powersteps will require E-Brake Relocation Bracket F5608.
  • Vehicles equipped with a 2 piece rear driveshaft and carrier bearing may require carrier bearing drop kit # D5405.

This product fits the following applications:

  • 2014 Ford F150 4WD

Quick Specs

  • Front Lift Height: 4″
  • Front Lift Method: Strut Spacer
  • Rear Lift Height: 4″
  • Rear Lift Method: Block & U-Bolt Kit
  • Install Time Hrs: 6-8
  • Difficulty Level 1-5: 3
  • Wheel Size: 18×9
  • Back Spacing: 5″
  • Max Tire Size: 35 x 12.50
  • Wheel Size: 20×9
  • Back Spacing: 5-5.5″
  • Max Tire Size: 35 x 12.50
466

on

Zone Offroad 4″ Coil Springs 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018 Jeep Wrangler JK

Part: J14/J15

Prepare yourself for the perfect combination of off road performance and on road handling. This 4″ JK system offers dramatic improvement in both ground clearance as well as wheel travel. With 4″ of lift, you can clear those 35’s with tons of room to twist as well as use your Jeep for a daily driver. Zone coil springs are designed so they can be totally smashed flat and still return to their original height, so you don’t have to worry about your coils sagging!

A heavy duty adjustable front track bar is included with durometer specific urethane bushings as well as a rear track bar relocation system. Unique to Zone, this system comes with front cam locks to increase caster and ensure good handling characteristics. These cam locks are guaranteed not to slip out of position like other adjustable round cam designs can.

Top this all off with extreme travel custom valved shocks and you have a system that will not only get you through the trail, but will handle just as well as a daily driver.

Featured Technology & Benefits

  • Coil springs designed to give a full 4″ of lift while maintaining a factory style ride. Our coils are 2door/4door specific, so be sure to select the proper application.
  • A front adjustable track bar is included to properly center the front axle
  • Cam washers are included to correct front end alignment
  • Rear extended sway bar links are included. These links come with urethane bushings to increase performance and reduce body roll. The factory rear links are then used in the front.
  • A rear track bar relocation system is included to perfectly center the axle under your JK
  • 2″ bump stop extensions are included to protect your vehicle while still increasing wheel travel
  • Brake line relocation brackets are supplied to allow for the dramatic increase in wheel travel
  • New Zone front and rear shocks are included that are valved specifically for your JK

Important Notes!

  • This system works for the 2 door, 4 door and Rubicon models. The coils are specific for 2 door vs. 4 door, so be sure to select the correct model above.
  • Factory wheels cannot be re-installed due to rear sway bar link interference.
  • 2012-17 models using the stock front driveshaft require exhaust extension kit J5305

This product fits the following applications:

  • 2007 Jeep Wrangler JK 4WD Gas
  • 2008 Jeep Wrangler JK 4WD Gas
  • 2009 Jeep Wrangler JK 4WD Gas
  • 2010 Jeep Wrangler JK 4WD Gas
  • 2011 Jeep Wrangler JK 4WD Gas
  • 2012 Jeep Wrangler JK 4WD Gas
  • 2013 Jeep Wrangler JK 4WD Gas
  • 2014 Jeep Wrangler JK 4WD Gas
  • 2015 Jeep Wrangler JK 4WD Gas
  • 2016 Jeep Wrangler JK 4WD Gas
  • 2017 Jeep Wrangler JK 4WD Gas
  • 2018 Jeep Wrangler JK 4WD Gas

Quick Specs

  • Front Lift Height: 4″
  • Front Lift Method: Coil Springs
  • Rear Lift Height: 4″
  • Rear Lift Method: Coil Springs
  • Install Time Hrs: 4-5
  • Difficulty Level 1-5: 2
  • Wheel Size: 16 x 8
  • Back Spacing: 4.5″
  • Max Tire Size: 35 x 12.50
