Zone Offroad 4″ Radius Arm Drop Brackets 2014, 2015, 2016, 2017, 2018 Ram 2500 (GAS)

Part: D62

Zone Offroad 2014-18 Ram 2500 4″ Radius Arm Drop Suspension System. This new lift system utilizes heavy duty drop brackets to relocate the new factory Ram radius arms. The new relocation brackets tie into the factory radius arm mounts as well as additional support to the frame. This relocation corrects the suspension geometry to compensate for the 4″ of lift provided by the progressive rate coil springs.

Extended bump stops, dropped pitman arm, track bar relocation and brake line relocation round out the front components. In the rear, the new 4 link suspension designed is modified for 2.5″ of lift via a new heavy duty coil spring spacer setup. The coil spring spacers located and bolt directly to the factory axle mount. The new provided track bar relocation bracket centers the axle. Extended sway bar links and bump stops round out the rear kit components.

Featured Technology & Benefits

  • Utilizes Heavy Duty Drop Brackets
  • Correct Suspension Geometry
  • Progressive Rate Coil Springs

Important Notes!

  • Although very rare, front driveline vibration may occur at speeds over 35 mph when in 4WD. If this occurs, install the appropriate optional t-case indexing kit. Optional t-case indexing ring kit recommended to reduce front driveline angle. Models with a 6 bolt transfer case use part # D5623. Models with an 8 bolt transfer case use part #D5813.
  • Vehicles equipped with a two piece drive shaft and a carrier bearing require bearing drop kit D5405.
  • Not designed for factory rear airbag suspension models.
  • Fits 6.4L equipped models.
  • Will not fit Power Wagon models

This product fits the following applications:

  • 2014 Dodge/Ram Ram 2500 4WD Gas
  • 2015 Dodge/Ram Ram 2500 4WD Gas
  • 2016 Dodge/Ram Ram 2500 4WD Gas
  • 2017 Dodge/Ram Ram 2500 4WD Gas
  • 2018 Dodge/Ram Ram 2500 4WD Gas

Quick Specs

  • Front Lift Height: 4
  • Front Lift Method: Radius Arm Drop Brackets
  • Rear Lift Height: 2.5
  • Rear Lift Method: Coil Spring Spacer
  • Difficulty Level 1-5: 3
  • Wheel Size: 17×9+
  • Back Spacing: 4.5″
  • Max Tire Size: 35 X 12.50
  • Wheel Size: 17×9+
  • Back Spacing: 5.625″
  • Max Tire Size: 37 X 12.50
1178

on

Zone Offroad 4″ Coil Springs & Bracket Kit 2005, 2006, 2007 Ford F250/F350

Part: F5/F13

The revolutionary new Zone 4″ radius arm drop bracket system features new front coil springs that are designed to not only ride great, but will hold up over the long haul. A 1-1/2″ solid steel track bar is included to properly center the axle after lifting. This track bar features new oversized, highdurometer urethane bushings for long term performance. The shocks were custom valved to work perfectly with the new Zone coil springs to increase off road performance while still offering unmatched on road ride quality, and the rear kit comes with 5″ blocks to replace your factory blocks.

Featured Technology & Benefits

  • New front coil springs capable of full coil bind offering off-road performance and great ride qualtiy
  • Radius arm drop brackets included to properly rotate the front axle
  • 1-1/2″ Solid steel track bar with urethane mounts to properly center the axle
  • New front & rear U-bolt with high nuts & washers
  • Rear 5″ Block kit to eliminate the factory block – NO stacking blocks!
  • Performance custom valved Zone Shocks included

Important Notes!

  • Although rare, if your vehicle is equipped with both a stock 4″ rear block and a top mounted over load spring, 4 of u-bolt part number UBT4035 may be required.
  • Dually trucks will require different rear u-bolts.
  • Vehicles equipped with 2 piece rear driveshaft’s may required the carrier bearing to be lowered. If required, order part #F5401.

This product fits the following applications:

  • 2005 Ford F250 4WD Gas/Diesel
  • 2006 Ford F250 4WD Gas/Diesel
  • 2007 Ford F250 4WD Gas/Diesel
  • 2005 Ford F350 4WD Gas/Diesel
  • 2006 Ford F350 4WD Gas/Diesel
  • 2007 Ford F350 4WD Gas/Diesel

Quick Specs

  • Front Lift Height: 4″
  • Front Lift Method: Coil Springs & Bracket Kit
  • Rear Lift Height: 5″
  • Rear Lift Method: Block kit
  • Install Time Hrs: 6
  • Difficulty Level 1-5: 2
  • Wheel Size: 17 x 9
  • Back Spacing: 4.5″
  • Max Tire Size: 35 x 12.50
900

on

Bilstein 4600 4 Quad Front and 2 Rear Shocks for 1980, 1981, 1982, 1983 ,1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996 Ford Bronco

Part: 6Bronco

Included:

  • Part Number: 24-013284
    Series: B6 4600
    Position: Front
    Descriptor: Quad Shock Option
    Descriptor: Rearward mounting of the axle
    Old Part Number: AK1289
    Old Part Number: B46-1328
    Old Part Number: F4-B46-1328-H1
Extended Length (IN): 14.67 Inch
Compressed Length (IN): 10.07 Inch
Rod Diameter (IN): 0.55 Inch
Upper Mounting Style: Stem Mount
Lower Mounting Style: Eyelet



  • Part Number: 24-184809
    Series: B6 4600
    Position: Front
    Descriptor: Auxiliary Shock
    Descriptor: Front Mounting Position
    Old Part Number: B46-1616
    Old Part Number: F4-B46-1616-H0
Extended Length (IN): 18.39 Inch
Compressed Length (IN): 11.81 Inch
Rod Diameter (IN): 0.55 Inch
Upper Mounting Style: Stem Mount
Lower Mounting Style: Eyelet



  • Part Number: 33-188218
    Series: B6 4600
    Position: Rear
    Old Part Number: B46-1327
    Old Part Number: F4-B46-1327-H1
Extended Length (IN): 21.63 Inch
Compressed Length (IN): 13.58 Inch
Rod Diameter (IN): 0.55 Inch
Upper Mounting Style: Eyelet
Lower Mounting Style: Eyelet

Includes 6 Shocks

16049

on

SuperLift 6.5″ Lift Kit with Bilstein Rear Shocks for 2007, 2008, 2009, 2010, 2011, 2012, 2013 Chevy Silverado & GMC Sierra 1500 4WD

Part: K162B

FEATURES & BENEFITS:

• Allows the use of 20” factory wheels

• Makes room for up to 35” tires

• Maintains awesome ride quality and handling characteristics

• No Coil-over disassembly required.

• Aligns to OEM specifications

• Corrects front to rear factory rake for a level stance

• Lifetime Warranty

• 60-Day Satisfaction Guarantee

• Qualifies for exclusive Factory Warranty Assurance Policy

INCLUDES:

FRONT

  • CNC machined extended ductile iron steering knuckles
  • All fabricated steel components are laser cut, CNC formed and finished with a durable black powder coat:
  • Front top mount strut spacers
  • One-piece front and rear cross members
  • Front differential skid plate
  • Front Sway Bar Links
  • Differential relocation brackets
  • Brake line relocation brackets

REAR

  • Lift blocks
  • U-bolts and hardware
  • Compression stop extensions
  • Bilstein shocks (2)

Tire & Wheel Info

width=

















Installation Notes

INSTALLATION INFO:

Install Time = 8-10 hours

Difficulty rating = 4 out 5.  5 being the most complicated.

Tires: 35×12.50

Wheels: Works with 20 in or larger factory wheels*

NOTES:

Requires cutting and drilling

Installation Instructions

Product Overview

The look you want for the price you want!

Give your truck the look you want and still maintain excellent ride quality with Superlift’s new 6.5” lift systems for the 2007-2013 Chevrolet Silverado 1500 4WD and GMC Sierra 1500 4WD. These complete systems are the best most cost effective solution available to make room for 35” tires. It allow the use of 20” or larger factory wheels

Designed from OEM supplied models using the latest 3D CAD software, our engineers did all the research to ensure a precise fit. These 6.5” lifts retain proper CV and drive shaft angles and align to OEM specifications to ensure great ride and handling characteristics.

Available with Bilstein rear shock absorbers

Backed by a Lifetime Warranty, 60 Day Satisfaction Guarantee and Superlift’s Factory Warranty Assurance Policy

FAQ’s:

Q – Is there welding required?

A – No. There is no welding required with the installation.

Q – Can I run my factory wheels?

A – Yes.  You can run 20” or larger factory wheels depending on the overall section width of the tire

Fitment Table

2007 – 2013 Chevrolet Silverado and GMC Sierra 1500 4WD
