ICON Stage 3 System 3″ Lift Kit for 1991, 1992, 1993, 1994, 1995, 1996, 1997 Toyota Land Cruiser 80 Series

Part: K53093

OVERVIEW:

After an in-depth R&D process, ICON engineers have developed a 3” suspension system for the 80 Series that is aimed to improve on-road handling characteristics while also maximizing the Land Cruiser’s off-road potential. This Stage 3 system includes ICON-designed dual rate coil springs, caster correction bushings, sway bar relocation components, all bracketry and hardware required for install, and ICON Vehicle Dynamics 2.5 Series remote reservoir shocks that feature a vehicle specific valving for optimized ride quality and balanced damping front to rear. The 2.5″ remote reservoir shocks front and rear ensure optimum performance by increasing the duration of consistent damping regardless of situation, keeping the shocks at a cooler operating temperature during extended offroad use. The Stage 3 system outfits the 80 Series Land Cruiser with ICON 2.5 Series shocks that feature CDCV, or Compression Damping Control Valve. This technology allows end-users to quickly adjust the ride quality of their shocks with the simple turn of a knob – no tools required! With ten high-resolution settings to choose from, the ICON CDC Valve will allow for the perfect ride quality across any terrain. This ICON Stage 3 System is the perfect suspension system for drivers seeking a quality on-road ride with outstanding off-road performance under extreme use, and the ability to fine tune the vehicle’s performance for any conditions encountered.

KEY FEATURES:

  • 3” lift height*
  • Approximately 40% increased front wheel travel over stock
  • Approximately 35% increased rear wheel travel over stock
  • ICON-engineered dual rate coil springs provide exceptional on-road ride quality and outstanding off-road performance
  • Vehicle specific tuned 2.5 Series front and rear shocks offer superior shock damping and control
  • 2.5 body remote reservoir shocks with 7/8″ shaft
  • Corrosion resistant CAD plated shock body
  • 6061 aircraft grade aluminum CNC machined components
  • ICON CDC Valve allows quick and easy end-user compression adjustability
  • 100% bolt-on design means no drilling, cutting or welding necessary for install
*Lift height measurement is based from a stock unloaded vehicle (with gas engine)

WHEEL & TIRE FITMENT INFO:

OEM Wheels & Tires: Yes

Aftermarket Wheels: 8-8.5″ Wide, 4.625″ Backspace

Aftermarket Tires: 33 x 11.50

(Larger Tires May Fit but Fender Trimming and Modifications will be Required)


SYSTEM COMPONENTS:

53005 (QTY.1) | 91-97 LAND CRUISER 3″ FRONT DUAL RATE SPRING KIT

53006 (QTY.1) | 91-97 LAND CRUISER 3″ REAR DUAL RATE SPRING KIT

53007 (QTY.1) | 91-97 LAND CRUISER SWAY BAR RELOCATION KIT

53008 (QTY.1) | 91-97 LAND CRUISER CASTER CORRECTION KIT

53009 (QTY.1) | 91-97 LAND CRUISER BRAKE LINE KIT +3″

57801CP (QTY.1) | 91-97 LAND CRUISER 80 0-3″ FRONT 2.5 VS RR CDCV PAIR

57802CP (QTY.1) | 91-07 LAND CRUISER 80/100 0-3″ REAR 2.5 VS RR CDCV PAIR



OPTIONS:

53009 | 91-97 LAND CRUISER BRAKE LINE KIT +3″



2841

on

ICON Stage 2 System 3″ Lift Kit for 1991, 1992, 1993, 1994, 1995, 1996, 1997 Toyota Land Cruiser 80 Series

Part: K53092

OVERVIEW:

After an in-depth R&D process, ICON engineers have developed a 3” suspension system for the 80 Series that is aimed to improve on-road handling characteristics while also maximizing the Land Cruiser’s off-road potential. This Stage 2 system includes ICON-designed dual rate coil springs, caster correction bushings, sway bar relocation components, all bracketry and hardware required for install, and ICON Vehicle Dynamics 2.5 Series remote reservoir shocks that feature a vehicle specific valving for optimized ride quality and balanced damping front to rear. The 2.5″ remote reservoir shocks front and rear ensure optimum performance by increasing the duration of consistent damping regardless of situation, keeping the shocks at a cooler operating temperature during extended offroad use. This ICON Stage 2 System is the perfect suspension system for drivers seeking a quality on-road ride with outstanding off-road performance under extreme use.


KEY FEATURES:
  • 3” lift height*
  • Approximately 40% increased front wheel travel over stock
  • Approximately 35% increased rear wheel travel over stock
  • ICON-engineered dual rate coil springs provide exceptional on-road ride quality and outstanding off-road performance
  • Vehicle specific tuned 2.5 Series front and rear shocks offer superior shock damping and control
  • 2.5 body remote reservoir shocks with 7/8″ shaft
  • Corrosion resistant CAD plated shock body
  • 6061 aircraft grade aluminum CNC machined components
  • 100% bolt-on design means no drilling, cutting or welding necessary for install
*Lift height measurement is based from a stock unloaded vehicle (with gas engine)

WHEEL & TIRE FITMENT INFO:

OEM Wheels & Tires: Yes

Aftermarket Wheels: 8-8.5″ Wide, 4.625″ Backspace

Aftermarket Tires: 33 x 11.50

(Larger Tires May Fit but Fender Trimming and Modifications will be Required)



SYSTEM COMPONENTS:

53005 (QTY.1) | 91-97 LAND CRUISER 3″ FRONT DUAL RATE SPRING KIT

53006 (QTY.1) | 91-97 LAND CRUISER 3″ REAR DUAL RATE SPRING KIT

53007 (QTY.1) | 91-97 LAND CRUISER SWAY BAR RELOCATION KIT

53008 (QTY.1) | 91-97 LAND CRUISER CASTER CORRECTION KIT

53009 (QTY.1) | 91-97 LAND CRUISER BRAKE LINE KIT +3″

57801P (QTY.1) | 91-97 LAND CRUISER 80 0-3″ FRONT 2.5 VS RR PAIR

57802P (QTY.1) | 91-07 LAND CRUISER 80/100 0-3″ REAR 2.5 VS RR PAIR

OPTIONS:

53009 | 91-97 LAND CRUISER BRAKE LINE KIT +3″

2316

on

Zone Offroad 4″ Coil Springs Lift Kit 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006 Jeep Wrangler TJ

Part: J10/J11



Prepare yourself for the perfect combination of off road performance and on road handling. This 4″ TJ system offers dramatic improvement in both ground clearance as well as wheel travel. The new massive lower control arms drastically increase the strength over stock, are formed to clear the mount for more wheel travel and correct front alignment. These arms feature rubber bushings to absorb the road and offer a degree of flexibility. This system comes with a transfer case drop as well as rear pinion cam locks that rotate the rear pinion for proper driveline angles. With 4″ of lift, you can clear those 33’s with room to twist as well as use your Jeep for a daily driver.

This Zone Offroad 4″ suspension lift kit fits 1997-2006 Jeep Wrangler TJ’s. There is a slight change to transfer case drop hardware so make the appropriate year selection for your vehicle. For a complete list of compatible applications click the vehicle fitment tab.

Featured Technology & Benefits

  • Four new Zone coils are included that are capable of being fully smashed down and they will always come back to their original height.
  • Front and rear extended sway bar links are included. These links come with urethane bushings to increase performance and reduce body roll.
  • A rear track bar relocation system is included to perfectly center the axle under your TJ.
  • A minimal transfer case drop is supplied to correct the driveline angle while maintaining as much ground clearance as possible.
  • 2″ bump stop extensions are included to protect your vehicle while still greatly increasing wheel travel
  • Four new massive lower control arms are included.
  • New rear pinion cam plates are included to rotate the rear pinion for proper drive line angles. In most cases the stock shafts can be used.
  • Optional: 4 new Zone shocks that are specifically valved for your TJ to perform well both on and off road.

Important Notes!

  • Also fits Rubicon and Unlimited versions.

This product fits the following applications:

  • 1997 Jeep Wrangler TJ 4WD Gas
  • 1998 Jeep Wrangler TJ 4WD Gas
  • 1999 Jeep Wrangler TJ 4WD Gas
  • 2000 Jeep Wrangler TJ 4WD Gas
  • 2001 Jeep Wrangler TJ 4WD Gas
  • 2002 Jeep Wrangler TJ 4WD Gas
  • 2003 Jeep Wrangler TJ 4WD Gas
  • 2004 Jeep Wrangler TJ 4WD Gas
  • 2005 Jeep Wrangler TJ 4WD Gas
  • 2006 Jeep Wrangler TJ 4WD Gas
  • 1997 Jeep Wrangler TJ Unlimited 4WD Gas
  • 1998 Jeep Wrangler TJ Unlimited 4WD Gas
  • 1999 Jeep Wrangler TJ Unlimited 4WD Gas
  • 2000 Jeep Wrangler TJ Unlimited 4WD Gas
  • 2001 Jeep Wrangler TJ Unlimited 4WD Gas
  • 2002 Jeep Wrangler TJ Unlimited 4WD Gas
  • 2003 Jeep Wrangler TJ Unlimited 4WD Gas
  • 2004 Jeep Wrangler TJ Unlimited 4WD Gas
  • 2005 Jeep Wrangler TJ Unlimited 4WD Gas
  • 2006 Jeep Wrangler TJ Unlimited 4WD Gas

Quick Specs

  • Front Lift Height: 4″
  • Front Lift Method: Coil Springs
  • Rear Lift Height: 4″
  • Rear Lift Method: Coil Springs
  • Install Time Hrs: 6
  • Difficulty Level 1-5: 3
  • Wheel Size: 15 X 8
  • Back Spacing: 3.5″
  • Max Tire Size: 33 x 12.50
