Zone Offroad 4″ Upper Strut Mounts Lift Kit 2009, 2010, 2011 Dodge Ram 1500

Part: D1/D23

The Zone Dodge 4″ Suspension System is centered around two main crossmembers that are locked together with a substantial differential skid plate. CNC machined steering knuckles correct steering geometry while reducing installation time. Strut top spacers are used to maintain factory ride and no strut disassembly is required. Due to factory ride height variances, Zone Offroad offers rear 3″ coil springs or 2″ coil spring spacers so you can achieve your desired stance. Completeing the rear, the kit includes hydraulic or nitro shocks as well as a track bar relocation bracket and four link relocation system. Buy from Zone Offroad and be glad you did.

Featured Technology & Benefits

  • Strut Top Spacer – Not Strut Disassembly Required
  • 3″ Rear Coil Springs or 2″ Coil Spacers
  • Factory Like Ride And Handling Characteristics
  • Differential Skid Plate Included
  • CNC Machined Steering Knuckles

Important Notes!

  • Will not fit Mega-Cab models.
  • Not recommended for AWD models.
  • TRX models require removal of the lower skid plate but it is replaces in our lift system.
  • These trucks vary 1″ to 3″ tail high from the factory. Measure your truck and order the appropriate rear lift height.

This product fits the following applications:

  • 2009 Dodge/Ram Ram 1500 4WD
  • 2010 Dodge/Ram Ram 1500 4WD
  • 2011 Dodge/Ram Ram 1500 4WD

Quick Specs

  • Front Lift Height: 4″
  • Front Lift Method: Upper Strut Mounts
  • Rear Lift Height: 3″
  • Rear Lift Method: Coil Springs
  • Install Time Hrs: 8-10
  • Difficulty Level 1-5: 3
  • Wheel Size: 17 x 9
  • Back Spacing: 4.5″
  • Max Tire Size: 35 x 12.50
  • Wheel Size: 18 x 9
  • Back Spacing: 5″
  • Max Tire Size: 35 x 12.50
  • Wheel Size: 20 x 9
  • Back Spacing: 5″
  • Max Tire Size: 35 x 12.50
682

on

Zone Offroad 4″ IFS System w/Strut Top Spacers Lift Kit 2006-2008 Dodge Ram 1500

Part: D3

This 4″ system is not only perfect as a daily driver, but excels offroad as well. The CNC machined steering knuckles work perfectly with the heavy duty crossmembers to offer factory like geometry and handling characteristics. The strut top spacer combined with the rear block kit drastically reduce installation time as well as maintain the factory ride quality.

Featured Technology & Benefits

  • Strut Top Spacer and Rear Block Kit reduces installation time
  • Factory like ride
  • Differential Skid Plate Included
  • CNC Machined Steering Knuckles Made in the USA

Important Notes!

  • Will not fit Mega-Cab models.
  • Not recommended for AWD models
  • TRX models require removal of the lower skid plate but it is replaced in our lift system.

This product fits the following applications:

  • 2006 Dodge/Ram Ram 1500 4WD
  • 2007 Dodge/Ram Ram 1500 4WD
  • 2008 Dodge/Ram Ram 1500 4WD

Quick Specs

  • Front Lift Height: 4″
  • Front Lift Method: IFS System w/Strut Top Spacers
  • Rear Lift Height: 2″
  • Rear Lift Method: Block & U-Bolt kit
  • Install Time Hrs: 8
  • Difficulty Level 1-5: 3
  • Wheel Size: 17 x 9
  • Back Spacing: 4.5″
  • Max Tire Size: 35 x 12.50
  • Wheel Size: 20 x 9
  • Back Spacing: 4.5″-5″
  • Max Tire Size: 35 x 12.50
1016

on

Zone Offroad 4″ IFS System w/Upper Strut Mounts Lift Kit 2004-2008 Ford F150 4WD

Part: F8

The Zone 4″ system mirrors it’s 6″ big brother. The 3/16″ solid steel differential skid plate locks the main crossmember together and protects the differential during those more serious offroad adventures. The CNC machined knuckles ensure factory steering geometry for a solid steering feel both on and off road. An optional rear add-a-leaf is available.

Featured Technology & Benefits

  • No track width change
  • Factory like ride and handling
  • CNC Machined knuckles for reduced installation time

Important Notes!

  • AWD models will require front driveshaft modification.
  • Will not fit HD models with 7 Lug wheels.

This product fits the following applications:

  • 2004 Ford F150 4WD
  • 2005 Ford F150 4WD
  • 2006 Ford F150 4WD
  • 2007 Ford F150 4WD
  • 2008 Ford F150 4WD

Quick Specs

  • Front Lift Height: 4″
  • Front Lift Method: IFS System w/Upper Strut Mounts
  • Rear Lift Height: 3″
  • Rear Lift Method: Block & U-bolt Kit
  • Install Time Hrs: 8
  • Difficulty Level 1-5: 3
  • Wheel Size: 17 X 9
  • Back Spacing: 4.5
  • Max Tire Size: 35 X 12.50
  • Wheel Size: 18 X 9
  • Back Spacing: 4.5-5
  • Max Tire Size: 35 X 12.50
  • Wheel Size: 20 X 9
  • Back Spacing: 4.5-5.5
  • Max Tire Size: 35 X 12.50
1957

on

Zone Offroad 4″ Leaf Springs Lift Kit 2000, 2001, 2002, 2003, 2004 Ford F250/F350 4WD

Part: F1

This 4″ system features new front leaf springs that are designed to not only ride great, but will hold up to the abuse super duty trucks are made for. Optional, progressively valved shocks are designed to increase offroad performance and provide excellent ride quality. A heavy duty track bar is used to center the front axle and makes the kit much easier to install than a track bar bracket system. A 3″ block is supplied for the rear to level the vehicle. This is the easiest installation and best value on the market for a 4″ system.

Featured Technology & Benefits

  • New front leaf springs with bolt style leaf alignment clamps, anti-friction pads, OE style rubber bushings and tapered leaves for long term performance and great ride qualtiy
  • 1-1/4″ Solid steel track bar with urethane mounts to properly center the axle
  • New front & Rear U-bolt with high nuts & washers
  • Rear 3″ Block kit
  • Performance custom valved Zone Shocks are optional

Important Notes!

  • Dually applications will require different rear 3-7/8″ I.D. u-bolts
  • Will not fit vehicles manufactured before 3-1-1999 with 5/8″ track bar bolt head size.
  • Vehicles equipped with 2 piece rear driveshafts may require the carrier bearing to be lowered.
  • If vehicle is equipped with rear top mounted overload springs 4 of u-bolt part number UBT4035 may be required. Selecting the Ubolt option below will add four (4) UBT4035s to the base kit.
  • Trucks equiped with gas engine may achieve a slightly higher front stance.
  • If truck is equipped with curved/radiussed style front ubolts order kit # F1. If truck is equipped with square style front ubolts order kit # F2.

This product fits the following applications:

  • 2000 Ford F250 4WD Gas/Diesel
  • 2001 Ford F250 4WD Gas/Diesel
  • 2002 Ford F250 4WD Gas/Diesel
  • 2003 Ford F250 4WD Gas/Diesel
  • 2004 Ford F250 4WD Gas/Diesel
  • 2000 Ford F350 4WD Gas/Diesel
  • 2001 Ford F350 4WD Gas/Diesel
  • 2002 Ford F350 4WD Gas/Diesel
  • 2003 Ford F350 4WD Gas/Diesel
  • 2004 Ford F350 4WD Gas/Diesel

Quick Specs

  • Front Lift Height: 4″
  • Front Lift Method: Leaf Springs
  • Rear Lift Height: 3″
  • Rear Lift Method: Block Kit
  • Install Time Hrs: 6
  • Difficulty Level 1-5: 2
  • Wheel Size: 16 x 10
  • Back Spacing: 4″
  • Max Tire Size: 35 x 12.50
