Zone Offroad 4″ Leaf Springs Lift Kit 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995 Jeep Wrangler YJ

Part: J28

The Zone 2″ & 4″ YJ systems include springs that are a 5 leaf pack design with anti-friction pads and center leaf spacer plates between each leaf. This design significantly decreases leaf pack internal friction for a smooth, consistent spring rate. These also come with bolt together Hendricks clamps to maintain leaf alignment and urethane bushings for long lasting performance. To complement these high quality springs in the 4″ system, Zone Offroad adds a dropped pitman arm, front track bar relocation bracket, front and rear bump stop extensions, front sway bar links, front and rear brake line brackets, leaf shims, center pins, u-bolts and a transfer case drop all with easy to follow instructions to guide you along the way. Zone Offroad’s nitro shocks are an option.

Featured Technology & Benefits

  • Front and rear Zone Offroad leaf springs.
  • Urethane spring bushings.
  • Front and rear yellow zinc plated U-bolts.
  • Front and rear brake line relocation brackets..
  • Leaf spring shims & center pins.
  • Front sway bar links
  • Front and rear bump stop extensions
  • Front track bar relocation bracket
  • Transfer case drop

Important Notes!

  • Pitman arm will not fit YJ models with manual steering.

This product fits the following applications:

  • 1987 Jeep Wrangler YJ 4WD Gas
  • 1988 Jeep Wrangler YJ 4WD Gas
  • 1989 Jeep Wrangler YJ 4WD Gas
  • 1990 Jeep Wrangler YJ 4WD Gas
  • 1991 Jeep Wrangler YJ 4WD Gas
  • 1992 Jeep Wrangler YJ 4WD Gas
  • 1993 Jeep Wrangler YJ 4WD Gas
  • 1994 Jeep Wrangler YJ 4WD Gas
  • 1995 Jeep Wrangler YJ 4WD Gas

Quick Specs

  • Front Lift Height: 4″
  • Front Lift Method: Leaf Springs
  • Rear Lift Height: 4″
  • Rear Lift Method: Leaf Springs
  • Install Time Hrs: 4-6
  • Difficulty Level 1-5: 3
  • Wheel Size: 15 x 8
  • Back Spacing: 3.5-4″
  • Max Tire Size: 33″ x 12.50″
6750

on

Zone Offroad 4″ Radius Arm Drop Brackets Lift Kit 2013, 2014, 2015, 2016, 2017 Ram 3500 (GAS)

Part: D64

Zone Offroad 2013-17 Ram 3500 (Gas, Including 6.4L) 4″ Suspension System. This new lift system utilizes heavy duty drop brackets to relocate the new factory Ram radius arms. The new relocation brackets tie into the factory radius arm mounts as well as additional support to the frame. This relocation corrects the suspension geometry to compensate for the 4″ of lift provided by the progressive rate coil springs.

Extended bump stops, dropped pitman arm, track bar relocation and brake line relocation round out the front components. The rear is lifted via a 3″ block and u-bolts. For those looking for a lower rear stance, choose the 2″ rear block kit. Available with both standard and Nitro shocks.

Featured Technology & Benefits

  • Utilizes Heavy Duty Drop Brackets
  • Correct Suspension Geometry
  • Progressive Rate Coil Springs

Important Notes!

  • Although very rare, front driveline vibration may occur at speeds over 35 mph when in 4WD. If this occurs, install the appropriate optional t-case indexing kit. Optional t-case indexing ring kit recommended to reduce front driveline angle. Models with a 6 bolt transfer case use part # D5623. Models with an 8 bolt transfer case use part #D5813.
  • Vehicles equipped with a two piece drive shaft and a carrier bearing require bearing drop kit D5405.
  • Not designed for dually models.
  • Not designed for factory rear airbag suspension models.
  • Fits 6.4L equipped models.

This product fits the following applications:

  • 2013 Dodge/Ram Ram 3500 4WD Gas
  • 2014 Dodge/Ram Ram 3500 4WD Gas
  • 2015 Dodge/Ram Ram 3500 4WD Gas
  • 2016 Dodge/Ram Ram 3500 4WD Gas
  • 2017 Dodge/Ram Ram 3500 4WD Gas

Quick Specs

  • Front Lift Height: 4″
  • Front Lift Method: Radius Arm Drop Brackets
  • Rear Lift Height: 4
  • Rear Lift Method: Block
  • Difficulty Level 1-5: 3
  • Wheel Size: 17×9+
  • Back Spacing: 4.5″
  • Max Tire Size: 35 X 12.50
  • Wheel Size: 17×9+
  • Back Spacing: 5.625″
  • Max Tire Size: 37 X 12.50
1003

on

Zone Offroad 4″ Coil Springs & Bracket Lift Kit 2008, 2009, 2010 Ford F250/F350

Part: F6/F12 (or F6N F12N or ZONF6 ZONF12)

The revolutionary new Zone 4″ system features new front coil springs that are designed to not only ride great, but will hold up over the long haul. A 1-1/2″ solid steel track bar is included to properly center the axle after lifting. This track bar features new oversized, high-durometer urethane bushings for long term performance. The optional shocks were custom valved to work perfectly with the new Zone coil springs to increase off road performance while still offering unmatched on road ride quality.

The rear kit comes with 5″ blocks to replace your factory blocks so there is not stacking of blocks when you are in the Zone. This reduces rear axle wrap compared to other similar systems on the market. With the front replacement track bar and the rear block kit, this system is one of the easiest installations on the market for a 4″ system.

Featured Technology & Benefits

  • New front coil springs capable of full coil bind offering off-road performance and great ride qualtiy
  • Radius arm drop brackets included to properly rotate the front axle
  • 1-1/2″ Solid steel track bar with urethane mounts to properly center the axle
  • New front & rear U-bolt with high nuts & washers
  • Rear 5″ Block kit to eliminate the factory block – NO stacking blocks!
  • Performance custom valved Zone Shocks – optional

Important Notes!

  • Although rare, if your vehicle is equipped with both a stock 4″ rear block and a top mounted over load spring, 4 of u-bolt part number UBT4035 may be required.
  • Dually trucks will require different rear u-bolts.
  • Vehicles equipped with 2 piece rear driveshaft’s may required the carrier bearing to be lowered. If required, order part # ZONF5401.
  • Front exhaust modification may be required to clear the front driveshaft on gas models.

This product fits the following applications:

  • 2008 Ford F250 4WD Gas/Diesel
  • 2009 Ford F250 4WD Gas/Diesel
  • 2010 Ford F250 4WD Gas/Diesel
  • 2008 Ford F350 4WD Gas/Diesel
  • 2009 Ford F350 4WD Gas/Diesel
  • 2010 Ford F350 4WD Gas/Diesel

Quick Specs

  • Front Lift Height: 4″
  • Front Lift Method: Coil Springs & Bracket Kit
  • Rear Lift Height: 5″
  • Rear Lift Method: Block Kit
  • Install Time Hrs: 6 hrs
  • Difficulty Level 1-5: 2
  • Wheel Size: 17 X 9
  • Back Spacing: 4.5″
  • Max Tire Size: 35 X 12.50



1960

on

Zone Offroad 4″ Coil Springs Lift Kit 1999, 2000, 2001, 2002, 2003, 2004 Jeep Grand Cherokee WJ 4WD

Part: J17

This 4″ WJ system offers dramatic improvement in both ground clearance as well as wheel travel. The system uses made in the USA coils springs that are designed not to sag. The new massive lower control arms not only correct front alignment but include factory like rubber bushing to absorb the road. This system comes with a small transfer case drop to correct driveline angles. A heavy duty front adjustable track bar is used to center the front axle. The rear used an upper A-arm spacer to ensure the factory joint does not get maxed out through wheel travel. Check out some of our competitors and you will find that most don’t include both lower control arms and the rear a-arm spacer at the price offered by Zone Offroad. With 4″ of lift, you can clear those 31’s with room to twist as well as use your Jeep for a daily driver. The system is available with Zone hydro or nitrogen charged shocks.

Featured Technology & Benefits

  • Four new Zone coils are included that are capable of being fully smashed down and they will always come back to their original height.
  • Rear extended sway bar links are included. These links come with urethane bushings to increase performance and reduce body roll.
  • A front adjustable track bar is included to properly center the front axle.
  • A rear upper tri-link spacer is included
  • A minimal transfer case drop is supplied to correct the driveline angle while maintaining as much ground clearance as possible.
  • 2″ bump stop extensions are included to protect your vehicle while still greatly increasing wheel travel
  • New massive front lower control arms with factory like rubber bushings
  • The system is completed with 4 new Zone shocks that are specifically valved for your WJ to perform well both on and off road.
  • Option to get the kit with Bilstein 5100 Shocks Front and Rear

Important Notes!

  • Vehicles equipped with V8 may not achieve stated lift height.
  • AWD models may require front drive line modification.
  • Some vehicles may experience front wheel shimmy that is attributable to the OE design. Specific tire and wheel combinations may induce steering shimmy. In most cases, alignment and/or tire and wheel changes will correct this problem. Zone Offroad assumes no incurred expenses associated with the correction of this problem.

This product fits the following applications:

  • 1999 Jeep Grand Cherokee WJ 4WD Gas
  • 2000 Jeep Grand Cherokee WJ 4WD Gas
  • 2001 Jeep Grand Cherokee WJ 4WD Gas
  • 2002 Jeep Grand Cherokee WJ 4WD Gas
  • 2003 Jeep Grand Cherokee WJ 4WD Gas
  • 2004 Jeep Grand Cherokee WJ 4WD Gas

Quick Specs

  • Front Lift Height: 4″
  • Front Lift Method: Coil Springs
  • Rear Lift Height: 3-1/2″
  • Rear Lift Method: Coil Springs
  • Install Time Hrs: 4
  • Difficulty Level 1-5: 3
  • Wheel Size: 16 x 8
  • Back Spacing: 4.5 – 6″
  • Max Tire Size: 31″ x 10.50″
