ICON 0-3″ Front Lift Extended Travel Coilovers for Toyota 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004 Tacoma, 1996, 1997, 1998, 1999, 2000, 2001, 2002 4Runner

Part: 58615

Overview:

These adjustable coil-over shocks have proven their strength and longevity for years on end and they keep going. These shocks offer the best ride quality and handling. They increase suspension travel and dramatically increase the capabilities of your 4Runner’s front suspension. These coil-over’s are meant to be installed with an aftermarket uniball upper control arm kit to ensure the proper amount of wheel travel and to prevent premature ball joint wear. Recommended tire size 285/75R16, wheel 16X8 with 4.5″ back spacing.

Technical Specs:

  • Adjustable ride height from 0″ – 3″
  • Race shock piston with flutter stack compression valving
  • Cad-plated threaded body / Extreme Weather Plating Option Available
  • Billet aluminum upper mount
  • 5/8″ PTFE-lined spherical bearing
  • Completely re-buildable
  • 2.5″ shock diameter to prevent overheating
  • Chrome-silicon spring
  • 250 PSI nitrogen-charged internal reservoir
  • Made in the USA
  • Nitro-steel shaft will not chip or rust like chrome shafts

Download Installation Instructions

4955

on

ICON 0-3″ Front Lift Coilovers for Toyota 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004 Tacoma, 1996, 1997, 1998, 1999, 2000, 2001, 2002 4Runner

Part: 58610

Overview:

These adjustable coilover shocks have proven their strength and longevity for years on end and they keep going. These shocks offer the best ride quality and handling. They increase suspension travel and dramatically increase the capabilities of your 4Runner’s front suspension. These coilovers come complete with all the hardware necessary to complete the installation. These are a Race-Proven shock designed for the daily driver and the avid offroader all in one! Recommended tire size 285/75R16, wheel 16X8 with 4.5″ back spacing.

Technical Specs:

  • Adjustable ride height from 0″ – 3″
  • Race shock piston with flutter stack compression valving
  • Cad-plated threaded body / Extreme Weather Plating Option Available
  • Billet aluminum upper mount
  • 5/8″ PTFE-lined spherical bearing
  • Completely re-buildable
  • 2.5″ shock diameter to prevent overheating
  • Chrome-silicon spring
  • 250 PSI nitrogen-charged internal reservoir
  • Made in the USA
  • Nitro-steel shaft will not chip or rust like chrome shafts

Download Installation Instructions for ICON Coilovers for 96-04 Tacoma

4442

on

Bilstein 0-2″ Lift Front Shocks and 0-1″ Lift Rear Shocks for 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023 Toyota Tacoma

Part: 24-263108_24-186728

Bilstein B8 5100 Front (Ride Height Adjustable) shock absorbers are designed for trucks and SUV’s with a front OE coilover style suspension. Multiple snap-ring grooves in the body allow for different spring seat positions, providing 0-2 inches of front lift (depending on application). The monotube shock absorbers feature a 46mm digressive piston a with self-adjusting deflective disc valve setting. Bilstein B8 5100 (Ride Height Adjustable) shock absorbers provide increased wheel travel and improved handling. Utilizing a B8 5100 (Ride Height Adjustable) shock absorber is the easiest way to level out your vehicle.

Settings:

​1st clip = 0″ (stock)
2nd clip = 0.65″
3rd clip = 1.1″
4th clip = 1.55″
5th clip = 2″ (5th notch not recommended for 4×4 V6/4cyl Access Cab or 4×2 V6 Double Cab 6′ bed)

Collapsed Length (IN): 17.58
Extended Length (IN): 22.22
Collapsed Length (MM): 446.5
Extended Length (MM): 564.5

Bilstein B8 5100 rear shock absorbers are designed as a direct fit solution for lifted trucks and SUV’s. These shock absorbers feature a monotube design which provides consistent fade free performance. B8 5100 shock absorbers utilize a unique, velocity sensitive, digressive piston which reacts to changing road conditions. All B8 5100 shock absorbers are tuned for each specific application to assure optimal performance is achieved. B8 5100 shock absorbers offer a significant improvement in ride quality, handling, and comfort.

Collapsed Length (IN): 14.02
Extended Length (IN): 22.94
Collapsed Length (MM): 356
Extended Length (MM): 582.7

Includes 4 Shocks only.

129175

on

Zone Offroad 4-1/2″ Coil Springs Lift Kit 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001 Jeep XJ

Part: J23/J24

The Zone Offroad 4.5″ XJ system with rear leaf springs includes all of the high quality parts necessary at a very affordable price. This system includes made in the USA coil springs that will not sag. The key is using the correct size wire with the correct spring rate to offer the perfect ride and still hold up over time. In fact, the system includes just 2″ bump stop extensions to drastically increase wheel travel.

This system also comes with extended sway bar links to compensate for the lift and brake line relocation brackets which makes the job easy to do at home. New extremely heavy duty lower control arms are supplied to correct alignment as well as axle location. These lower control arms are made from heavy wall tube and include pre-installed factory style rubber bushings to absorb the road rather than transmitting it into your seat.

The rear is lifted via new Zone Offroad leaf springs. Many hours of development and testing have finally produced a capable spring that we are proud to introduce to our lineup. The new springs are a 5 leaf pack with anti-friction pads and center leaf spacer plates between each leaf. This design greatly decreases leaf pack internal friction. These springs are designed to give 3″ of lift and are also set up to give the max amount of compression travel before the shackle is limited by the rear portion of the body. This allows the springs to flatten out as much as possible, which translates to increased wheel travel. These are designed to flex, but can still hold up and handle your load of gear. To achieve 4″ of lift in the rear, longer greasable boomerang shackles have been added to improve articulation while improving the pinion angle.

Gas charged Nitro shocks are available as an option for added handling control.

Featured Technology & Benefits

  • Front coil springs designed to give a full 4.5″ of lift while maintaining an factory style ride
  • Only 2″ bump stop extensions are included because our springs are designed for extreme travel.
  • A minimal (1″) transfer case drop is included to correct the driveline angle while maintaining as much ground clearance as possible.
  • New extended sway bar links are supplied with urethane mounts for long term performance
  • Front and Rear brake line relocation brackets are included.
  • Front lower control arms with pre-installed factory like rubber bushings
  • Replacement Rear Leaf Springs that will ride great and replace the tired factory XJ springs.
  • Longer Boomerang shackles made to lift the vehicle, correct pinion angle, and improve articulation.
  • New rear U-bolts are included with high nuts and washers
  • Extended length shackles are also supplied for the rear to allow your springs to really flex!
  • Option available for: New front and rear shocks are included that are valved specifically for your XJ

Important Notes!

  • The XJ was produced with different possible rear axles. You will have to identify your rear axle before being able to complete an order. The easiest way to tell the difference is to measure the I.D. of your rear u-bolts. The Chrysler rear end uses a 3″ I.D. u-bolt and the Dana 35 rear axle requires a 2-3/4″ I.D. u-bolt.

This product fits the following applications:

  • 1984 Jeep Cherokee XJ w/ Chrysler 8.25 4WD Gas
  • 1985 Jeep Cherokee XJ w/ Chrysler 8.25 4WD Gas
  • 1986 Jeep Cherokee XJ w/ Chrysler 8.25 4WD Gas
  • 1987 Jeep Cherokee XJ w/ Chrysler 8.25 4WD Gas
  • 1988 Jeep Cherokee XJ w/ Chrysler 8.25 4WD Gas
  • 1989 Jeep Cherokee XJ w/ Chrysler 8.25 4WD Gas
  • 1990 Jeep Cherokee XJ w/ Chrysler 8.25 4WD Gas
  • 1991 Jeep Cherokee XJ w/ Chrysler 8.25 4WD Gas
  • 1992 Jeep Cherokee XJ w/ Chrysler 8.25 4WD Gas
  • 1993 Jeep Cherokee XJ w/ Chrysler 8.25 4WD Gas
  • 1994 Jeep Cherokee XJ w/ Chrysler 8.25 4WD Gas
  • 1995 Jeep Cherokee XJ w/ Chrysler 8.25 4WD Gas
  • 1996 Jeep Cherokee XJ w/ Chrysler 8.25 4WD Gas
  • 1997 Jeep Cherokee XJ w/ Chrysler 8.25 4WD Gas
  • 1998 Jeep Cherokee XJ w/ Chrysler 8.25 4WD Gas
  • 1999 Jeep Cherokee XJ w/ Chrysler 8.25 4WD Gas
  • 2000 Jeep Cherokee XJ w/ Chrysler 8.25 4WD Gas
  • 2001 Jeep Cherokee XJ w/ Chrysler 8.25 4WD Gas
  • 1984 Jeep Cherokee XJ w/ Dana 35 4WD Gas
  • 1985 Jeep Cherokee XJ w/ Dana 35 4WD Gas
  • 1986 Jeep Cherokee XJ w/ Dana 35 4WD Gas
  • 1987 Jeep Cherokee XJ w/ Dana 35 4WD Gas
  • 1988 Jeep Cherokee XJ w/ Dana 35 4WD Gas
  • 1989 Jeep Cherokee XJ w/ Dana 35 4WD Gas
  • 1990 Jeep Cherokee XJ w/ Dana 35 4WD Gas
  • 1991 Jeep Cherokee XJ w/ Dana 35 4WD Gas
  • 1992 Jeep Cherokee XJ w/ Dana 35 4WD Gas
  • 1993 Jeep Cherokee XJ w/ Dana 35 4WD Gas
  • 1994 Jeep Cherokee XJ w/ Dana 35 4WD Gas
  • 1995 Jeep Cherokee XJ w/ Dana 35 4WD Gas
  • 1996 Jeep Cherokee XJ w/ Dana 35 4WD Gas
  • 1997 Jeep Cherokee XJ w/ Dana 35 4WD Gas
  • 1998 Jeep Cherokee XJ w/ Dana 35 4WD Gas
  • 1999 Jeep Cherokee XJ w/ Dana 35 4WD Gas
  • 2000 Jeep Cherokee XJ w/ Dana 35 4WD Gas
  • 2001 Jeep Cherokee XJ w/ Dana 35 4WD Gas

Quick Specs

  • Front Lift Height: 4-1/2″
  • Front Lift Method: Coil Springs
  • Rear Lift Height: 4″
  • Rear Lift Method: Leaf Springs & Shackles
  • Install Time Hrs: 5-6
  • Difficulty Level 1-5: 3
  • Wheel Size: 15″ x 8″
  • Back Spacing: 4.75″
  • Max Tire Size: 32″ x 11.50″
