Zone Offroad 5″ Coil Springs Lift Kit 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001 Dodge Ram 1500

Part: D44/D45

Turn your 1994-2001 Dodge 1500 into the truck you’ve always wanted! This 5″ system features upper and lower extended heavy-duty control arms with greasable polyurethane bushings to properly center the axle and correct caster. The dropped pitman arm combined with the heavy duty track bar bracket corrects the steering geometry and centers the axle.

Whether on road or offroad this system is built to perform including optional custom valved Zone shocks that have been tuned to the full height 5″ coils as well as extended polyurethane bump stops. This system also uses replacement sway bar links to eliminate any binding at the stem and correct sway bar geometry.

In the rear, a 5″ rear block and add-a-leaf is used to replace the factory block, no stacking in this system.

Featured Technology & Benefits

  • Heavy duty greasable control arms included
  • Extended length urethane bump stops
  • Track bar relocation to properly center your axle
  • Pitman arm included to maintain steering geometry
  • Completely bolt on system

Important Notes!

  • Aftermarket steering stabilizer required. Factory drag link mount taper will be flipped when dropped pitman arm is installed.
  • 2001 models with “Offroad Package” will not yield a full 5″ of lift.
  • Factory block is replaced with 5″ block and add-a-leaf combo to obtain a level stance.
  • Will not fit models built before February 9, 1994 due to track bar stud size.

This product fits the following applications:

  • 1994 Dodge/Ram Ram 1500 4WD
  • 1995 Dodge/Ram Ram 1500 4WD
  • 1996 Dodge/Ram Ram 1500 4WD
  • 1997 Dodge/Ram Ram 1500 4WD
  • 1998 Dodge/Ram Ram 1500 4WD
  • 1999 Dodge/Ram Ram 1500 4WD
  • 2000 Dodge/Ram Ram 1500 4WD
  • 2001 Dodge/Ram Ram 1500 4WD

Quick Specs

  • Front Lift Height: 5″
  • Front Lift Method: Coil Springs
  • Rear Lift Height: 3″
  • Rear Lift Method: 5″ Block & Add-a-Leaf
  • Install Time Hrs: 5-6
  • Difficulty Level 1-5: 2
  • Wheel Size: 16 x8
  • Back Spacing: 4″
  • Max Tire Size: 35 x 12.50
6457

on

Zone Offroad 5″ Coil Springs Lift Kit 2009 Dodge Ram 2500/3500

Part: D7/D12/D13

This Zone Offroad 4-link system replaces the weak upper and lower factory control arms with greasable DOM tubular arms. the arms mount in the factory control arm pockets for a completely bolt on easy installation that aligns to factory specs. Zone Offroad has engineered their coil springs for a comfortable ride on both gas and diesel trucks. Optional: black nitrogen gas charges shock for that performance handling feel. To correct the steering geometry and keep your axle centered, the kit includes a dropped pitman arm and 1/4″ thick fabricated track bar bracket that you will not be disappointed with! The kit also includes sway bar drop brackets and if you get serious, taller bump stops. The rear is lifted with 3″ blocks to give your truck a more level stance and make for a quick installation.

Featured Technology & Benefits

  • Heavy duty greasable control arms included
  • Extended Length Urethane Bump Stops
  • Track Bar Relocation to properly center your axle
  • Pitman Arm included to maintain steering geometry
  • Completely Bolt on System

Important Notes!

  • This truck was produced with different rear axles. Measure the diameter of your rear axle before ordering.
  • This system will not fit dually applications due to the rear u-bolt size.
  • If a carrier bearing exists in the rear driveshaft, a carrier bearing drop kit (D5505) may be required.
  • Gas models may sit approximately 1/2″ higher than the advertised lift height.
  • Kit includes a 3″ rear block kit. Measure your truck before ordering to determine the stance of your truck with the lift installed.
  • Power Wagon models came factory with a 2″ taller ride height so the net lift gain will be 3″ over the factory Power Wagon. Power Wagon models require sway bar link kit D5301.

This product fits the following applications:

  • 2009 Dodge/Ram Ram 1500 Mega Cab 4WD Gas/Diesel
  • 2009 Dodge/Ram Ram 2500 4WD Gas/Diesel
  • 2009 Dodge/Ram Ram 3500 4WD Gas/Diesel

Quick Specs

  • Front Lift Height: 5″
  • Front Lift Method: Coil Springs
  • Rear Lift Height: 3″
  • Rear Lift Method: Block & U-bolt Kit
  • Install Time Hrs: 6-8
  • Difficulty Level 1-5: 3
  • Wheel Size: 17 X 9
  • Back Spacing: 5″
  • Max Tire Size: 36 X 12.50
2261

on

Zone Offroad 5″ Coil Springs Lift Kit 2003, 2004, 2005, 2006, 2007 Dodge Ram 2500/3500/1500 MegaCab

Part: D5/D8/D9

This Zone Offroad 4-link system replaces the weak upper and lower factory control arms with greasable DOM tubular arms. the arms mount in the factory control arm pockets for a completely bolt on easy installation that aligns to factory specs. Zone Offroad has engineered their coil springs for a comfortable ride on both gas and diesel trucks. Custom valved hydraulic shocks are included for a great ride, or choose the black nitrogen gas charges shock for that performance handling feel. To correct the steering geometry
and keep your axle centered, the kit includes a dropped pitman arm and 1/4″ thick fabricated track bar bracket that you will not be disappointed with! The kit also includes sway bar drop brackets and if you get serious, taller bump stops. The rear is lifted with 3″ blocks to give your truck a more level stance and make for a quick installation.

Featured Technology & Benefits

  • Heavy duty greasable control arms included
  • Extended Length Urethane Bump Stops
  • Track Bar Relocation to properly center your axle
  • Pitman Arm included to maintain steering geometry
  • Completely Bolt on System

Important Notes!

  • This truck was produced with different rear axles. Measure the diameter of your rear axle before ordering.
  • This system will not fit dually applications due to the rear u-bolt size.
  • 2-piece rear driveshaft requires carrier bearing drop kit D5505
  • Gas models may sit approximately 1/2″ higher than the advertised lift height.
  • Kit includes a 3″ rear block kit. Measure your truck before ordering to determine the stance of your truck with the lift installed.
  • Power Wagon models came factory with a 2″ taller ride height so the net lift gain will be 3″ over the factory Power Wagon. Power Wagon models require sway bar link kit D5301.

This product fits the following applications:

  • 2006 Dodge/Ram Ram 1500 Mega Cab 4WD
  • 2007 Dodge/Ram Ram 1500 Mega Cab 4WD
  • 2003 Dodge/Ram Ram 2500 4WD Gas/Diesel
  • 2004 Dodge/Ram Ram 2500 4WD Gas/Diesel
  • 2005 Dodge/Ram Ram 2500 4WD Gas/Diesel
  • 2006 Dodge/Ram Ram 2500 4WD Gas/Diesel
  • 2007 Dodge/Ram Ram 2500 4WD Gas/Diesel
  • 2003 Dodge/Ram Ram 3500 4WD Gas/Diesel
  • 2004 Dodge/Ram Ram 3500 4WD Gas/Diesel
  • 2005 Dodge/Ram Ram 3500 4WD Gas/Diesel
  • 2006 Dodge/Ram Ram 3500 4WD Gas/Diesel
  • 2007 Dodge/Ram Ram 3500 4WD Gas/Diesel

Quick Specs

  • Front Lift Height: 5″
  • Front Lift Method: Coil Springs
  • Rear Lift Height: 3″
  • Rear Lift Method: Block & U-bolt Kit
  • Install Time Hrs: 6-8
  • Difficulty Level 1-5: 3
  • Wheel Size: 17 X 9
  • Back Spacing: 5″
  • Max Tire Size: 36 X 12.50
5932

on

Zone Offroad 5.5″ Radius Arm Drop Brackets Lift Kit 2013, 2014, 2015, 2016, 2017 Ram 3500 (GAS)

Part: D66

Zone Offroad 2013-17 Ram 3500 5.5″ Suspension System. The newest Zone Offroad lift option for the new 3500 Ram follows the same design as the current 4.5″ system. The system utilizes the same heavy-duty radius arm drop brackets to properly compensate for the massive 5.5″ progressive rate coil springs.

The supplied drop pitman arm, extended bump stops, track bar relocation bracket, sway bar drops and brake line relocation adjust all the rest of the critical components and angles. The system coupled with a choice of standard hydraulic or Nitro shocks provides a great handling, smooth ride suspension system. The rear of the truck is lifted via 5″ rear blocks.

For those looking to use their 4wd on the road at speed we highly recommend adding the optional t-case indexing kit to improve the front driveline angles. These two kits (for the 6-bolt and 8-bolt T-cases) come with a t-case indexing ring, front driveshaft spacer and heavy-duty replacement transmission crossmember. The t-case indexing kits can be installed when the lift is installed or anytime after if the need arises. The indexing kits will also work with other lift heights and brands for those customers in need of one.

Featured Technology & Benefits

  • Utilizes Heavy Duty Drop Brackets
  • Correct Suspension Geometry
  • Progressive Rate Coil Springs

Important Notes!

  • Front driveline vibration may occur at speeds over 35 mph when in 4WD. If this occurs, install the appropriate optional t-case indexing kit. Models with a 6 bolt transfer case use part # D5623. Models with an 8 bolt transfer case use part #D5813.
  • Vehicles equipped with a two piece drive shaft and a carrier bearing require bearing drop kit D5405.
  • Not designed for factory rear airbag suspension models.
  • Fits trucks equipped with the 6.4L gas engines.

This product fits the following applications:

  • 2013 Dodge/Ram Ram 3500 4WD Gas
  • 2014 Dodge/Ram Ram 3500 4WD Gas
  • 2015 Dodge/Ram Ram 3500 4WD Gas
  • 2016 Dodge/Ram Ram 3500 4WD Gas
  • 2017 Dodge/Ram Ram 3500 4WD Gas

Quick Specs

  • Front Lift Height: 5.5
  • Front Lift Method: Radius Arm Drop Brackets
  • Rear Lift Height: 5
  • Rear Lift Method: Block
  • Difficulty Level 1-5: 3
  • Wheel Size: 17×9+
  • Back Spacing: 4.5″
  • Max Tire Size: 35 X 12.50
  • Wheel Size: 17×9+
  • Back Spacing: 5.625″
  • Max Tire Size: 37 X 13.50
