Zone Offroad 6″ Radius Arm Drop Brackets Lift Kit 2014, 2015, 2016, 2017, 2018 Ram 2500 (GAS)

Part: D68

Zone Offroad 2014-18 Ram 2500 5.5″ Suspension System. The newest Zone Offroad lift option for the new 2500 Ram follows the same design as the current 4.5″ system. The system utilizes the same heavy-duty radius arm drop brackets to properly compensate for the massive 5.5″ progressive rate coil springs.

The supplied drop pitman arm, extended bump stops, track bar relocation bracket, sway bar drops and brake line relocation adjust all the rest of the critical components and angles. The system coupled with a choice of standard hydraulic or Nitro shocks provides a great handling, smooth ride suspension system. The rear of the truck is lifted via 4.5″ rear coil springs.

For those looking to use their 4wd on the road at speed we highly recommend adding the optional t-case indexing kit to improve the front driveline angles. These two kits (for the 6-bolt and 8-bolt T-cases) come with a t-case indexing ring, front driveshaft spacer and heavy-duty replacement transmission crossmember. The t-case indexing kits can be installed when the lift is installed or anytime after if the need arises. The indexing kits will also work with other lift heights and brands for those customers in need of one.

Featured Technology & Benefits

  • Utilizes Heavy Duty Drop Brackets
  • Correct Suspension Geometry
  • Progressive Rate Coil Springs

Important Notes!

  • *Kit images show upgraded Nitro (black) shocks*
  • Front driveline vibration may occur at speeds over 35 mph when in 4WD. If this occurs, install the appropriate optional t-case indexing kit. Models with a 6 bolt transfer case use part # D5623. Models with an 8 bolt transfer case use part #D5813.
  • Vehicles equipped with a two piece drive shaft and a carrier bearing require bearing drop kit D5405.
  • Not designed for factory rear airbag suspension models.
  • Fits trucks equipped with the 6.4L gas engines.
  • Will not fit Power Wagon models

This product fits the following applications:

  • 2014 Dodge/Ram Ram 2500 4WD Gas
  • 2015 Dodge/Ram Ram 2500 4WD Gas
  • 2016 Dodge/Ram Ram 2500 4WD Gas
  • 2017 Dodge/Ram Ram 2500 4WD Gas
  • 2018 Dodge/Ram Ram 2500 4WD Gas

Quick Specs

  • Front Lift Height: 5.5
  • Front Lift Method: Radius Arm Drop Brackets
  • Rear Lift Height: 4.5
  • Rear Lift Method: Coil Spring
  • Difficulty Level 1-5: 3
  • Wheel Size: 17×9+
  • Back Spacing: 4.5″
  • Max Tire Size: 35 X 12.50
  • Wheel Size: 17×9+
  • Back Spacing: 5.625″
  • Max Tire Size: 37 X 13.50
821

on

Zone Offroad 6″ Replacement Radius Arms Lift Kit 2014, 2015, 2016, 2017, 2018 Ram 2500 (GAS)

Part: D69

Engineered to match the strength of the 2014-17 RAM 2500 4WD trucks, these systems upgrade the factory front radius arms and offer great ride quality and handling characteristics on road while improving offroad performance and allowing 37″ tires to be installed. The new radius arms are a substantial upgrade to the factory stamped units and improve the ground clearance compared to drop bracket kits. The arms are fully boxed, internally gusseted and designed to bolt in the factory location while correcting the suspension geometry at 5.5″ of lift. At the frame mount, the arms utilize extra large, greaseable bushings to isolate road noise and vibrations while the axle mount is designed to retain the factory alignment cams for adjustability. The arms are formed inward to maximize tire clearance and looks great under the new RAM HDs.

In addition to the new radius arms, this system gets its height from 5.5” progressive rate front coils designed for a smooth ride for unmatched highway and trail performance. Steering correction comes from a forged dropped pitman arm and a heavy duty, fully welded front track bar bracket is used at the frame to recenter the front axle securely under the truck. Rounding out the front of this 5.5″ radius arm system are a pair of polyurethane extended bump stops, brake line relocation brackets, and your choice of Zone hydro or Zone nitro shocks along with all the necessary hardware to complete the install. Out back the the new coil sprung rear is lifted using 4.5″ progressive rate coils designed to level the stance while offering a great ride quality on and offroad without hindering the towing capabilities. Also included are extended sway bar links, bump stop extensions and a rear track bar bracket to recenter the rear axle.

In addition to this kit, Zone offers both single and dual steering stabilizer kits to fit the redesigned front end. Available in both white (3000 series) and black (7000 series) finishes, these steering stabilizer kits are far superior to the factory stabilizer unit and a great addition to help control larger tires on and offroad. The single kits are a stock replacement while the dual kits install stacked in the stock location.

Featured Technology & Benefits

  • Utilizes Heavy Duty Drop Brackets
  • Correct Suspension Geometry
  • Progressive Rate Coil Springs

Important Notes!

  • *Kit images show upgraded Nitro (black) shocks*
  • Front driveline vibration may occur at speeds over 35 mph when in 4WD. If this occurs, install the appropriate optional t-case indexing kit. Models with a 6 bolt transfer case use part # D5623. Models with an 8 bolt transfer case use part #D5813.
  • Vehicles equipped with a two piece drive shaft and a carrier bearing require bearing drop kit D5405.
  • Not designed for factory rear airbag suspension models.
  • Fits trucks equipped with the 6.4L gas engines.
  • Will not fit Power Wagon models

This product fits the following applications:

  • 2014 Dodge/Ram Ram 2500 4WD Gas
  • 2015 Dodge/Ram Ram 2500 4WD Gas
  • 2016 Dodge/Ram Ram 2500 4WD Gas
  • 2017 Dodge/Ram Ram 2500 4WD Gas
  • 2018 Dodge/Ram Ram 2500 4WD Gas

Quick Specs

  • Front Lift Height: 5.5
  • Front Lift Method: Replacement Radius Arms
  • Rear Lift Height: 4.5
  • Rear Lift Method: Coil Springs
  • Difficulty Level 1-5: 3
  • Wheel Size: 17×9+
  • Back Spacing: 4.5″
  • Max Tire Size: 35 X 12.50
  • Wheel Size: 17×9+
  • Back Spacing: 5.625″
  • Max Tire Size: 37 X 13.50
2791

on

Zone Offroad 6″ Replacement Radius Arms Lift Kit 2013, 2014, 2015, 2016, 2017 Ram 3500 (GAS)

Part: D67

This kit offers improved strength, performance, and ride quality over the standard drop bracket kit. Engineered to match the brawn of the 2013-2017 RAM 3500 4WD trucks, these systems upgrade the factory front radius arms and offer impressive handling characteristics on road while improving offroad performance and allowing for up to 37″ tires to be installed.

The new radius arms are a substantial upgrade to the factory stamped units and improve the ground clearance compared to drop bracket kits. The arms are fully boxed, internally gusseted and designed to bolt in the factory location while correcting the suspension geometry at 5.5” of lift. At the frame mount, the arms utilize extra large, greaseable bushings to isolate road noise and vibrations while the axle mount is designed to retain the factory alignment cams for adjustability. The arms are formed inward to maximize tire clearance and looks great under the new RAM HDs.

In addition to the new radius arms, this system gets its height from 5.5″ progressive rate front coils designed for a smooth ride for unmatched highway and trail performance. Steering correction comes from a forged dropped pitman arm and a heavy duty, fully welded front track bar bracket is used at the frame to recenter the front axle securely under the truck. Rounding out the front of this 5.5″ radius arm system are a pair of polyurethane extended bump stops, brake line relocation brackets, your choice of Zone hydro or Zone nitro shocks at all 4 corners, and all the necessary hardware to complete the install. Out back the rear is lifted using a 5″ block and long u-bolts to level the stance and allow for up to 37″ tires to be installed.

Featured Technology & Benefits

  • Utilizes Heavy Duty Drop Brackets
  • Correct Suspension Geometry
  • Progressive Rate Coil Springs

Important Notes!

  • *Kit images show upgraded Nitro (black) shocks*
  • Front driveline vibration may occur at speeds over 35 mph when in 4WD. If this occurs, install the appropriate optional t-case indexing kit. Models with a 6 bolt transfer case use part # D5623. Models with an 8 bolt transfer case use part #D5813.
  • Vehicles equipped with a two piece drive shaft and a carrier bearing require optional bearing drop kit D5405
  • Not designed for dually models.
  • Not designed for factory rear airbag suspension models.
  • Fits trucks equipped with the 6.4L gas engines.

This product fits the following applications:

  • 2013 Dodge/Ram Ram 3500 4WD Gas
  • 2014 Dodge/Ram Ram 3500 4WD Gas
  • 2015 Dodge/Ram Ram 3500 4WD Gas
  • 2016 Dodge/Ram Ram 3500 4WD Gas
  • 2017 Dodge/Ram Ram 3500 4WD Gas

Quick Specs

  • Front Lift Height: 5.5
  • Front Lift Method: Replacement Radius Arms
  • Rear Lift Height: 5
  • Rear Lift Method: Block
  • Difficulty Level 1-5: 3
  • Wheel Size: 17×9+
  • Back Spacing: 4.5″
  • Max Tire Size: 35 X 12.50
  • Wheel Size: 17×9+
  • Back Spacing: 5.625″
  • Max Tire Size: 37 X 13.50
2609

on

Zone Offroad 6″ IFS w/Struts Lift Kit 2014 Ford F150 2WD

Part: F43

Choose the Zone Offroad 6″ Suspension System to lift your 2014 Ford F150 and clear up to a 37″ tire.

A 3-point differential mounting system drops and rotates the front differential to bring the CV shafts and driveshaft back to factory operating angles. Visually compare the Zone Offroad porterhouse knuckles to the chuck roast of the competition. Salivate over the fully cast, CNC machined, and resonant frequency tested knuckles that correct the tie rod and ball joint geometry with no track width change. Heavy main crossmembers are included with your meal and are locked solid with a differential skid plate. Choose your side of rear shock, and we’ll fill in the rest with a 5″ dual pin block kit that offsets the axle closer to the center of the wheel well compared to a standard setup.

This kit is all inclusive, so don’t look anywhere else, install a Zone Offroad system on your F150 and have no regrets.

Featured Technology & Benefits

  • Custom Valved Replacement Coil-over Strut
  • CNC Machined Steering Knuckles correctly drilled for the application
  • Heavy 1/4″ thick crossmembers
  • No Track Width Change
  • Differential Skid Plate Included

Important Notes!

  • *Kit images show upgraded Nitro (black) shocks*
  • AWD models will require front driveshaft modification
  • Will not work with 17″ wheels
  • If using 18×9 wheels with 5.5″ backspace, fit the wheels before mounting to check for proper tie rod clearance. Wheel manufacturing variances may affect this clearance.
  • Vehicles equipped with factory powersteps will require E-Brake Relocation Bracket part # F5608.
  • Models equipped with a 2 piece rear driveshaft may require carrier bearing drop kit part # D5405
  • Although rare, rear driveshaft extension part # F5601 may be required
  • Kit includes a 5″ rear block kit (#F2619) that typically nets a slight tail high stance. A 4″ rear block kit (#F2419) is available in the options if a more level stance is preferred.

This product fits the following applications:

  • 2014 Ford F150 2WD

Quick Specs

  • Front Lift Height: 6″
  • Front Lift Method: IFS w/Struts
  • Rear Lift Height: 5″
  • Rear Lift Method: Block & U-bolt Kit
  • Install Time Hrs: 8
  • Difficulty Level 1-5: 3
  • Wheel Size: 18×9
  • Back Spacing: 5″
  • Max Tire Size: 37 x 12.50
  • Wheel Size: 18×9
  • Back Spacing: 4.5″-5″
  • Max Tire Size: 35 x 13.50
  • Wheel Size: 20×9
  • Back Spacing: 5″-5.5″
  • Max Tire Size: 37×12.50
