Zone Offroad 6″ IFS Knuckle & Bracket Kit Lift Kit 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010 Chevy/GMC 2WD

Part: C5

The Zone Offroad Products 6″ suspension lift kit for 2001-06 Chevrolet/GMC Silverado/Sierra 1500HD/2500 & 2001-10 2500HD 2wd pickup trucks is built for everyday driving but sturdy enough for offroad abuse.

The one piece main crossmembers in combination with the CNC machined ductile steering knuckles match the factory geometry for excellent ride and handling. The crossmembers are locked together with strut braces to acheive ideal subframe strength for the heavy duty use of your truck. Complete with torsion bar brackets, sway bar links, rear blocks, u-bolts and twin tube hydraulic shocks for a smooth ride. If quality, performance and value are what you demand, then look no further.

Featured Technology & Benefits

  • One piece 1/4″ steel crossmembers
  • Designed based on the factory geometry to acheive factory like ride quality and handling
  • CNC machined ductile iron steering knuckles
  • Not some cheap import – Over 95% made in America with quality North American Steel
  • Rear block kit for easy installation

Important Notes!

  • Torsion bar unloading/loading tool required.
  • To reduce trimming on new body style HD’s 20″ wheels with 5 3/4″ backspacing recommended.
  • Gas models required minor exhaust modification to clear front driveshaft.
  • Although unusual, some models with a carrier bearing may experience driveline vibration. If this occurs, order appropriate carrier bearing drop listed in the accessories.
  • Not designed for dually models

This product fits the following applications:

  • 2001 Chevy 1500HD Pickup 2WD
  • 2002 Chevy 1500HD Pickup 2WD
  • 2003 Chevy 1500HD Pickup 2WD
  • 2004 Chevy 1500HD Pickup 2WD
  • 2005 Chevy 1500HD Pickup 2WD
  • 2006 Chevy 1500HD Pickup 2WD
  • 2001 Chevy 2500 Pickup 2WD
  • 2002 Chevy 2500 Pickup 2WD
  • 2003 Chevy 2500 Pickup 2WD
  • 2004 Chevy 2500 Pickup 2WD
  • 2005 Chevy 2500 Pickup 2WD
  • 2006 Chevy 2500 Pickup 2WD
  • 2007 Chevy 2500 Pickup 2WD
  • 2008 Chevy 2500 Pickup 2WD
  • 2009 Chevy 2500 Pickup 2WD
  • 2010 Chevy 2500 Pickup 2WD
  • 2001 Chevy 2500HD Pickup 2WD
  • 2002 Chevy 2500HD Pickup 2WD
  • 2003 Chevy 2500HD Pickup 2WD
  • 2004 Chevy 2500HD Pickup 2WD
  • 2005 Chevy 2500HD Pickup 2WD
  • 2006 Chevy 2500HD Pickup 2WD
  • 2007 Chevy 2500HD Pickup 2WD
  • 2008 Chevy 2500HD Pickup 2WD
  • 2009 Chevy 2500HD Pickup 2WD
  • 2010 Chevy 2500HD Pickup 2WD
  • 2001 GMC 2500 Pickup 2WD
  • 2002 GMC 2500 Pickup 2WD
  • 2003 GMC 2500 Pickup 2WD
  • 2004 GMC 2500 Pickup 2WD
  • 2005 GMC 2500 Pickup 2WD
  • 2006 GMC 2500 Pickup 2WD
  • 2007 GMC 2500 Pickup 2WD
  • 2008 GMC 2500 Pickup 2WD
  • 2009 GMC 2500 Pickup 2WD
  • 2010 GMC 2500 Pickup 2WD
  • 2001 GMC 2500HD Pickup 2WD
  • 2002 GMC 2500HD Pickup 2WD
  • 2003 GMC 2500HD Pickup 2WD
  • 2004 GMC 2500HD Pickup 2WD
  • 2005 GMC 2500HD Pickup 2WD
  • 2006 GMC 2500HD Pickup 2WD
  • 2007 GMC 2500HD Pickup 2WD
  • 2008 GMC 2500HD Pickup 2WD
  • 2009 GMC 2500HD Pickup 2WD
  • 2010 GMC 2500HD Pickup 2WD

Quick Specs

  • Front Lift Height: 6″
  • Front Lift Method: IFS Knuckle & Bracket Kit
  • Rear Lift Height: 5″
  • Rear Lift Method: Block Kit
  • Install Time Hrs: 6-8
  • Difficulty Level 1-5: 3
  • Wheel Size: 16 x 8
  • Back Spacing: 4.5
  • Max Tire Size: 35 X 12.50
  • Wheel Size: 17 or 18 x 9
  • Back Spacing: 5-5.5
  • Max Tire Size: 35×12.50
  • Wheel Size: 20 x 9
  • Back Spacing: 5.75
  • Max Tire Size: 35×12.50
2288

on

Zone Offroad 6″ Strut Spacers Lift Kit 2016, 2017, 2018, 2019б 2020 Toyota Tacoma 4WD

Part: T7

Zone Offroad’s 2016 Toyota Tacoma 4wd 6″ Suspension System gives current model owners a complete and affordable system to clear up to 35″ tires, including everything needed to properly outfit your new truck for safe, reliable performance where ever your journey may lead you.

Up front the kits include a pair of heavy duty 1/4″ thick crossmembers, full width differential skid plate, and multipoint differential relocation brackets to create a strong subframe. These combined with the ductile iron steering knuckles all the system to work with the factory ESC System parameters to keep you safe on the road. Finishing off the front of this kit are a pair of top mounted strut spacers, new bump stops, sway bar relocation brackets and all the hardware needed to install. In the rear of these kits is a block kit to level the stance, new u-bolts, brake line extension and your choice of Zone hydro or nitro gas shocks.

Choose your Tacoma suspension lift from Zone Offroad simply because it provides the best parts for the least amount of your hard earned cash with excellent customer service to back it up.

Featured Technology & Benefits

  • Heavy Duty 1/4″ Boxed Front & Rear Crossmembers
  • Full Width Belly Pan For Differential Protection And A Strong Sub-Frame
  • Solid Extended Ductile Iron Steering Knuckles
  • Stout Strut Spacers To Maintain Factory Struts And OE Ride Quality/Handling
  • Durable Black Powder Coat Finish
  • Over 90% Made In The USA

Important Notes!

  • Will not work on TRD Pro Models
  • Minor welding required (steering stops)
  • Requires frame bracket modification
  • Strut compressor required for installation
  • Stock wheels cannot be reinstalled. 18″ or larger wheels must be used.
  • System will work on 2wd PreRunner models
  • 35×12.50 tires require trimming

This product fits the following applications:

  • 2016 Toyota Tacoma 4WD

Quick Specs

  • Front Lift Height: 6″
  • Front Lift Method: Strut Spacers
  • Rear Lift Height: 4″
  • Rear Lift Method: Block Kit
  • Install Time Hrs: 6-8
  • Difficulty Level 1-5: 4
  • Wheel Size: 18×9 min.
  • Back Spacing: 4.5″
  • Max Tire Size: 35×12.50 *notes
5049

on

Zone Offroad 6″ Leaf Springs Lift Kit 2000, 2001, 2002, 2003, 2004, 2005 Ford Excursion 4WD

Part: F3

It’s time to upgrade your Excursion! The revolutionary new Zone 6″ system features new front leaf springs that are designed to not only ride great, but will hold up over the long haul. A 1-1/4″ solid steel track bar is included to properly center the axle after lifting. This track bar features new oversized urethane bushings for long term performance. The shocks were custom valved to work perfectly with the new Zone leaf springs to increase off road performance while still offering unmatched on road ride quality. With the front replacement track bar and the rear block kit, this system is one of the easiest installations on the market for a 6″ system.

Featured Technology & Benefits

  • New front leaf springs with bolt style leaf alignment clamps, anti-friction pads, OE style rubber bushings and tapered leaves for long term performance and great ride qualtiy
  • 1-1/4″ Solid steel track bar with urethane mounts to properly center the axle
  • New front & Rear U-bolt with high nuts & washers
  • Rear 3″ Block kit and Add-A-Leaf
  • Performance custom valved Zone Shocks included

Important Notes!

  • Models with rear CV driveshaft may experience drive line vibration
  • Front and Rear driveshaft modification may be required
  • Due to OE variances, you may need to change the rear blocks to level the truck

This product fits the following applications:

  • 2000 Ford Excursion 4WD Diesel
  • 2001 Ford Excursion 4WD Diesel
  • 2002 Ford Excursion 4WD Diesel
  • 2003 Ford Excursion 4WD Diesel
  • 2004 Ford Excursion 4WD Diesel
  • 2005 Ford Excursion 4WD Diesel
  • 2000 Ford Excursion 4WD Gas
  • 2001 Ford Excursion 4WD Gas
  • 2002 Ford Excursion 4WD Gas
  • 2003 Ford Excursion 4WD Gas
  • 2004 Ford Excursion 4WD Gas
  • 2005 Ford Excursion 4WD Gas

Quick Specs

  • Front Lift Height: 6″
  • Front Lift Method: Leaf Springs
  • Rear Lift Height: 5″
  • Rear Lift Method: Add-A-Leafs & Block Kit
  • Install Time Hrs: 7
  • Difficulty Level 1-5: 2
  • Wheel Size: 16 x 10
  • Back Spacing: 4″
  • Max Tire Size: 35 x 12.50
3169

on

Zone Offroad 6″ Coil Springs Lift Kit 2009, 2010 Dodge Ram 2500/3500

Part: D37/D38/D39

This new Zone Offroad 6″ suspension system for the 09-13 Dodge Ram 2500 & 09-12 Dodge Ram 3500 is performance packed and budget friendly for those looking to get 37″ tires under their HD Dodge truck. The lift uses a unique control arm relocation design. Both the stock upper and lower arms are relocated to relieve angles, properly position the front axle and provide good caster and front pinion angle settings. The 1/4″ steel constructed relocation brackets mount directly to stock locations and only require a few new holes to be drilled for extra support. No cutting of the frame or axle mounts is required. Stock alignment adjustability is retained. Stock control arm angles are maintained to provide a great ride, handling and control.

In addition to the control arm brackets, all the necessary additional components are included. Full-length coil springs, dropped pitman arm, track bar relocation, sway bar relocation and bump stops are included. The rear kits feature new lift blocks and u-bolts. A rear carrier bearing drop kit is available also for trucks featuring a stock 2-piece rear driveshaft.

Featured Technology & Benefits

  • Unique upper and lower control arm relocation bracket design.
  • Heavy 1/4″ steel construction.
  • No cutting of the frame required.
  • High performance at a low price.

Important Notes!

  • Works on 2013 2500 with 4 link front suspension only. Will not fit 1 Ton Trucks.
  • 2-piece rear driveshaft requires carrier bearing drop kit D5505
  • Will not fit dually applications
  • Rear axle diameter will be 3.5″ or 4″, measure before ordering
  • Minor trimming may be required with some tire/wheel combinations. A front bumper spacer kit (D5801) is available to gain clearance if necessary
  • If driveline vibration is present, some 6″ kits may require the transfer case indexing kit (D5805). See installation instructions (step 17) for fitment details.
  • Will work with Power Wagon models with the addition of sway bar link kit D5301. Power Wagon models came factory with a 2″ taller ride height so net lift gain will be 4″ over stock.
  • Gas models may require modification to the front exhaust crossover pipe on driver side when using the transfer case indexing ring

This product fits the following applications:

  • 2009 Dodge/Ram Ram 2500 4WD
  • 2010 Dodge/Ram Ram 2500 4WD
  • 2011 Dodge/Ram Ram 2500 4WD
  • 2012 Dodge/Ram Ram 2500 4WD
  • 2013 Dodge/Ram Ram 2500 4WD
  • 2009 Dodge/Ram Ram 3500 4WD
  • 2010 Dodge/Ram Ram 3500 4WD
  • 2011 Dodge/Ram Ram 3500 4WD
  • 2012 Dodge/Ram Ram 3500 4WD

Quick Specs

  • Front Lift Height: 6″
  • Front Lift Method: Coil Springs
  • Rear Lift Height: 4″
  • Rear Lift Method: Block Kit
  • Install Time Hrs: 6-8
  • Difficulty Level 1-5: 3
  • Wheel Size: 17 X 9
  • Back Spacing: 4.5-5″
  • Max Tire Size: 37 X 12.50
