Zone Offroad 6″ IFS System Lift Kit 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006 Silverado/Sierra 1500 4WD

Part: C3

Ready for all your friends to be jealous? The Zone Offroad Products 6″ Suspension Lift Kit for 1999-2006 Chevrolet 1500 Silverado & GMC 1500 Sierra pickups is the ultimate in style and performance.

Whether you are just driving to work or playing on the trail, this system was designed to perform. The main crossmembers were designed to match the factory geometry with the new Zone CNC machined steering knuckles creating a true factory quality driving experience. Match this geometry with the heavy duty differential skid plate that locks the main crossemembers together and the compression struts that tie back to the frame and you have a system ready for some serious abuse!

Featured Technology & Benefits

  • CNC Machined ductile iron knuckles
  • Diffential skid plate included to protect the front differential and lock the crossmembers together
  • Compression struts included to support the main crossmembers for serious off roading
  • 1/4″ thick steel used to make indestructable crossmembers
  • 3-point differential mounting system correctly positions the differential so the factory driveshaft can be used

Important Notes!

  • Torsion bar unloading tool required.
  • Requires frame bracket modification and differential mount modification.
  • Will not fit HD models. See kit #C4
  • Compression struts won’t work with early ’99 models with an “S” shaped transmission crossmember.
  • If equipped with 17″ stock wheels, 17″ or larger aftermarket wheels must be used.
  • Minor welding required.
  • Will not fit old body tyle 1999 models.
  • It may be required to order the rear add-a-leaf kit C6159 for a slightly above level to tail high appearance.
  • Optional Add-a-leaf kit is recommended on Crew Cab models to acheive more level stance.

This product fits the following applications:

  • 1999 Chevy 1500 Pickup 4WD Gas
  • 2000 Chevy 1500 Pickup 4WD Gas
  • 2001 Chevy 1500 Pickup 4WD Gas
  • 2002 Chevy 1500 Pickup 4WD Gas
  • 2003 Chevy 1500 Pickup 4WD Gas
  • 2004 Chevy 1500 Pickup 4WD Gas
  • 2005 Chevy 1500 Pickup 4WD Gas
  • 2006 Chevy 1500 Pickup 4WD Gas
  • 1999 GMC 1500 Pickup 4WD Gas
  • 2000 GMC 1500 Pickup 4WD Gas
  • 2001 GMC 1500 Pickup 4WD Gas
  • 2002 GMC 1500 Pickup 4WD Gas
  • 2003 GMC 1500 Pickup 4WD Gas
  • 2004 GMC 1500 Pickup 4WD Gas
  • 2005 GMC 1500 Pickup 4WD Gas
  • 2006 GMC 1500 Pickup 4WD Gas

Quick Specs

  • Front Lift Height: 6″
  • Front Lift Method: IFS System
  • Rear Lift Height: 5″
  • Rear Lift Method: Block Kit
  • Install Time Hrs: 8
  • Difficulty Level 1-5: 4
  • Wheel Size: 16 x 8
  • Back Spacing: 4.5″
  • Max Tire Size: 35 x 12.50
  • Wheel Size: 17 x 9
  • Back Spacing: 5″
  • Max Tire Size: 35 x 12.50
  • Wheel Size: 20 x 8
  • Back Spacing: 5.75″
  • Max Tire Size: 35 x 12.50
6549

on

Zone Offroad 6″ IFS System w/Strut Top Spacers Lift Kit 2006, 2007, 2008 Dodge Ram 1500

Part: D4

The Zone Dodge 6″ Suspension System is centered around two main crossmembers that are locked together with a substantial differential skid plate. CNC machined steering knuckles correct steering geometry while reducing installation time. Strut top spacers are used to maintain factory ride and no strut disassembly is required. The block and u-bolt kit combined with the strut spacer makes this system one of the easiest to install on the market.

Featured Technology & Benefits

  • Strut Top Spacer and Rear Block Kit reduces installation time
  • Factory like ride
  • Differential Skid Plate Included
  • CNC Machined Steering Knuckles Made in the USA

Important Notes!

  • Will not fit Mega-Cab models.
  • Not recommended for AWD models
  • TRX models require removal of the lower skid plate but it is replaced in our lift system.

This product fits the following applications:

  • 2006 Dodge/Ram Ram 1500 4WD
  • 2007 Dodge/Ram Ram 1500 4WD
  • 2008 Dodge/Ram Ram 1500 4WD

Quick Specs

  • Front Lift Height: 6″
  • Front Lift Method: IFS System w/Strut Top Spacers
  • Rear Lift Height: 4″
  • Rear Lift Method: Block & U-bolt Kit
  • Install Time Hrs: 8
  • Difficulty Level 1-5: 3
  • Wheel Size: 17 x 9
  • Back Spacing: 4.5″
  • Max Tire Size: 37 x 13.50
  • Wheel Size: 20 x 9
  • Back Spacing: 4.5″-5″
  • Max Tire Size: 37 x 13.50
1848

on

Zone Offroad 6″ Upper Strut Mounts Lift Kit 2009, 2010, 2011 Dodge Ram 1500

Part: D2/D15

The Zone Dodge Ram 1500 pickup 6″ Suspension Kit System for 2009-2011models is centered around two main crossmembers that are locked together with a substantial differential skid plate. CNC machined steering knuckle correct steering geometry while reducing installation time. Strut top spacers are used to lift the vehicle and maintain the factory ride. Strut dissaseembly is only required if the optional preload spacers included in the kit are used. The rear is lifted with new Zone coil springs, track bar relocation and a rear four link relocation system.

Two rear lift height options are available and when combined with the included optional front pre-load spacers, really allows you to fine tune the stance of your truck.

Featured Technology & Benefits

  • Strut Top Spacer with optional pre-load spacer
  • Factory Like Ride And Handling Characteristics
  • Differential Skid Plate Included
  • CNC Machined Steering Knuckles
  • Rear Shocks Included

Important Notes!

  • Will not fit Mega Cab models.
  • Not recommended for AWD models.
  • These trucks are typically between 1″ and 3″ tail high. Please measure your truck and order the appropriate rear lift height.
  • TRX models will achieve aproximately 1″ of additional lift. This lift is not recommended for use on the TRX models due to possible CV shaft vibration caused by the additional lift. Instead, consider our 4″ lift system for about 5″ of lift or replace the TRX struts with standard struts for use with this system.

This product fits the following applications:

  • 2009 Dodge/Ram Ram 1500 4WD
  • 2010 Dodge/Ram Ram 1500 4WD
  • 2011 Dodge/Ram Ram 1500 4WD

Quick Specs

  • Front Lift Height: 6″
  • Front Lift Method: Upper Strut Mounts
  • Rear Lift Height: 3 or 5″
  • Rear Lift Method: Coil Springs
  • Install Time Hrs: 8-10
  • Difficulty Level 1-5: 3
  • Wheel Size: 17 x 9
  • Back Spacing: 4.5″
  • Max Tire Size: 37 x 13.50
  • Wheel Size: 18 x 9
  • Back Spacing: 5″
  • Max Tire Size: 37 x 13.50
  • Wheel Size: 20 x 9
  • Back Spacing: 5″
  • Max Tire Size: 37 x 13.50
976

on

Zone Offroad 6″ Coil Springs Lift Kit 2008, 2009, 2010 Ford F250/F350

Part: F34/F35/F36/F37

Lift your Super Duty with Zone Offroad’s 6″ radius arm suspension lift for an attention grabbing, smooth riding, complete, and affordable system. For less than the cost of some radius arm drop kits on the market, you can buy this system with bullet proof radius arms that provide more ground clearance, better looks, and a big strength improvement over the stockers. American made, gas & diesel specific coil springs will not sag to provide you the lift to clear 37’s and a ride you might not expect from a system this price competitive.

This system includes everything you need and more, including a dropped pitman arm and track bar relocation bracket, but for a complete list check out the features tab. To avoid stacking rear blocks or going too tall with a single block, Zone includes a 5″ cast iron block with an integrated bump stop as well as dual add-a-leafs. This block & AAL system will reduce spring wrap, will level the truck, and is also designed to shift the axle forward to ensure the tire stays centered in the rear wheel well.

For a top shelf 6″ lift without the top shelf price, buy from Zone Offroad with an elevated level of customer service to back it up.

Featured Technology & Benefits

  • 1/4″ boxed radius arms with oversize greasable bushings
  • Diesel or gas specific coil springs for an accurate lift height and proper ride quality
  • Increased ground clearance and better looks than a radius arm drop system
  • Track bar bracket and dropped pitman arm included to correct steering geometry
  • Sway bar drop brackets to maintain the OE sway bar angle
  • Front bump stop spacers
  • Front and rear brake line relocation brackets
  • Steering stabilizer relocation bracket
  • 5″ rear block with integrated bump stop
  • Dual rear add-a-leafs
  • Designed to level the truck with removal of the factory block

Important Notes!

  • Removal of the factory rear block is required. Net rear height gain will vary based on size of the factory block, but will result in a level stance.
  • If equipped with a 2-piece rear drive shaft, then a drivshaft alignment kit may be required. It is available in the optional accessories (part # F5401).
  • Although extremely rare, front drive line vibration may occur.
  • Rear box kit not designed for dually models.
  • Front exhaust modification may be required to clear the front driveshaft on gas models.

This product fits the following applications:

  • 2008 Ford F250 4WD
  • 2009 Ford F250 4WD
  • 2010 Ford F250 4WD
  • 2008 Ford F350 4WD
  • 2009 Ford F350 4WD
  • 2010 Ford F350 4WD

Quick Specs

  • Front Lift Height: 6″
  • Front Lift Method: Coil Springs
  • Rear Lift Height: 4″
  • Rear Lift Method: Dual Add-A-Leafs & Block Kit
  • Install Time Hrs: 6
  • Difficulty Level 1-5: 3
  • Wheel Size: 17 & up
  • Back Spacing: 4.5″
  • Max Tire Size: 37 X 12.50
2599
