Zone Offroad 6.5″ Replacement Radius Arms Lift Kit 2014, 2015, 2016, 2017, 2018 Ram 2500 (DIESEL)

Part: D58N

Engineered to match the strength of the 2014-17 RAM 2500 4WD trucks, these systems upgrade the factory front radius arms and offer great ride quality and handling characteristics on road while improving offroad performance and allowing 37″ tires to be installed. The new radius arms are a substantial upgrade to the factory stamped units and improve the ground clearance compared to drop bracket kits. The arms are fully boxed, internally gusseted and designed to bolt in the factory location while correcting the suspension geometry at 6.5″ of lift. At the frame mount, the arms utilize extra large, greaseable bushings to isolate road noise and vibrations while the axle mount is designed to retain the factory alignment cams for adjustability. The arms are formed inward to maximize tire clearance and looks great under the new RAM HDs.

In addition to the new radius arms, this system gets its height from 6.5” progressive rate front coils designed for a smooth ride for unmatched highway and trail performance. Steering correction comes from a forged dropped pitman arm and a heavy duty, fully welded front track bar bracket is used at the frame to recenter the front axle securely under the truck. Rounding out the front of this 6.5″ radius arm system are a pair of polyurethane extended bump stops, brake line relocation brackets, and your choice of Zone hydro or Zone nitro shocks along with all the necessary hardware to complete the install. Out back the the new coil sprung rear is lifted using 4.5″ progressive rate coils designed to level the stance while offering a great ride quality on and offroad without hindering the towing capabilities. Also included are extended sway bar links, bump stop extensions and a rear track bar bracket to recenter the rear axle.

In addition to this kit, Zone offers both single and dual steering stabilizer kits to fit the redesigned front end. Available in both white (3000 series) and black (7000 series) finishes, these steering stabilizer kits are far superior to the factory stabilizer unit and a great addition to help control larger tires on and offroad. The single kits are a stock replacement while the dual kits install stacked in the stock location.

Featured Technology & Benefits

  • Utilizes Heavy Duty Drop Brackets
  • Correct Suspension Geometry
  • Progressive Rate Coil Springs

Important Notes!

  • *Kit images show upgraded Nitro (black) shocks*
  • Front driveline vibration may occur at speeds over 35 mph when in 4WD. If this occurs, install the appropriate optional t-case indexing kit. Models with a 6 bolt transfer case use part # D5623. Models with an 8 bolt transfer case use part #D5813.
  • Vehicles equipped with a two piece drive shaft and a carrier bearing require bearing drop kit D5405.
  • Not designed for factory rear airbag suspension models.
  • Will not fit Power Wagon models

This product fits the following applications:

  • 2014 Dodge/Ram Ram 2500 4WD Diesel
  • 2015 Dodge/Ram Ram 2500 4WD Diesel
  • 2016 Dodge/Ram Ram 2500 4WD Diesel
  • 2017 Dodge/Ram Ram 2500 4WD Diesel
  • 2018 Dodge/Ram Ram 2500 4WD Diesel

Quick Specs

  • Front Lift Height: 6.5
  • Front Lift Method: Replacement Radius Arms
  • Rear Lift Height: 4.5″
  • Rear Lift Method: Coil Springs
  • Difficulty Level 1-5: 3
  • Wheel Size: 17×9+
  • Back Spacing: 4.5″
  • Max Tire Size: 35 X 12.50
  • Wheel Size: 17×9+
  • Back Spacing: 5.625″
  • Max Tire Size: 37 X 13.50
6779

on

Zone Offroad 8″ Coil Springs Lift Kit 2009, 2010, 2011, 2012, 2013 Dodge Ram 2500/3500

Part: D36

This new Zone Offroad 8″ suspension system for the 09-13 Dodge Ram 2500 & 09-12 Dodge Ram 3500 is performance packed and budget friendly for those looking to get 37″ tires under their HD Dodge truck. The lift uses a unique control arm relocation design. Both the stock upper and lower arms are relocated to relieve angles, properly position the front axle and provide good caster and front pinion angle settings. The 1/4″ steel constructed relocation brackets mount directly to stock locations and only require a few new holes to be drilled for extra support. No cutting of the frame or axle mounts is required. Stock alignment adjustability is retained. Stock control arm angles are maintained to provide a great ride, handling and control.

In addition to the control arm brackets, all the necessary additional components are included. Full-length coil springs, dropped pitman arm, track bar relocation, sway bar relocation and bump stops are included. The rear kits feature new lift blocks and u-bolts. A rear carrier bearing drop kit is available for trucks featuring a stock 2-piece rear driveshaft.

Featured Technology & Benefits

  • Unique upper and lower control arm relocation bracket design.
  • Heavy 1/4″ steel construction.
  • No cutting of the frame required.
  • High performance at a low price.

Important Notes!

  • Works on 2013 2500 with 4 link front suspension only. Will not fit 1 Ton 2013 Trucks.
  • 2-piece rear driveshaft requires carrier bearing drop kit D5505
  • Will not fit dually applications
  • Minor trimming may be required with some tire/wheel combinations. A front bumper spacer kit (D5801) is available to gain clearance if necessary
  • Depending on the factory transmission mount, in rare cases some 8″ kits may not require the transfer case indexing kit. See installation instructions for details.
  • Lift springs are designed for diesel models only.

This product fits the following applications:

  • 2009 Dodge/Ram Ram 2500 4WD Diesel
  • 2010 Dodge/Ram Ram 2500 4WD Diesel
  • 2011 Dodge/Ram Ram 2500 4WD Diesel
  • 2012 Dodge/Ram Ram 2500 4WD Diesel
  • 2013 Dodge/Ram Ram 2500 4WD Diesel
  • 2009 Dodge/Ram Ram 3500 4WD Diesel
  • 2010 Dodge/Ram Ram 3500 4WD Diesel
  • 2011 Dodge/Ram Ram 3500 4WD Diesel
  • 2012 Dodge/Ram Ram 3500 4WD Diesel

Quick Specs

  • Front Lift Height: 8″
  • Front Lift Method: Coil Springs
  • Rear Lift Height: 5″
  • Rear Lift Method: Block Kit
  • Install Time Hrs: 6-8
  • Difficulty Level 1-5: 3
  • Wheel Size: 17 X 9
  • Back Spacing: 4.5-5″
  • Max Tire Size: 38 X 13.50
9657

on

Zone Offroad 8″ Coil Springs Lift Kit 2008 Dodge Ram 2500/3500

Part: D30/D31

This new Zone Offroad 8″ suspension system for the 2008 Dodge Ram 2500/3500 is performance packed and budget friendly for those looking to get 38″ tires under their HD Dodge truck. The lift uses a unique control arm relocation design. Both the stock upper and lower arms are relocated to relieve angles, properly position the front axle and provide good caster and front pinion angle settings. The 1/4″ steel constructed relocation brackets mount directly to stock locations and only require a few new holes to be drilled for extra support. No cutting of the frame or axle mounts is required. Stock alignment adjustability is retained. Stock control arm angles are maintained to provide a great ride, handling and control.

In addition to the control arm brackets, all the necessary additional components are included. Full-length coil springs, dropped pitman arm, track bar relocation, sway bar relocation and bump stops are included. The rear kits feature new lift blocks and u-bolts. A rear carrier bearing drop kit is available so for trucks featuring a stock 2-piece rear driveshaft.

Featured Technology & Benefits

  • Unique upper and lower control arm relocation bracket design.
  • Heavy 1/4″ steel construction.
  • No cutting of the frame required.
  • High performance at a low price.

Important Notes!

  • 2-piece rear driveshaft requires carrier bearing drop kit D5505
  • Will not fit dually applications
  • Rear axle diameter will be 3.5″ or 4″, measure before ordering
  • Minor trimming may be required with some tire/wheel combinations. A front bumper spacer kit (D5801) is available to gain clearance if necessary
  • Depending on the factory transmission mount, in rare cases some 8″ kits may not require the transfer case indexing kit. See installation instructions for details.
  • Lift springs are designed for diesel models only.

This product fits the following applications:

  • 2008 Dodge/Ram Ram 2500 4WD Diesel
  • 2008 Dodge/Ram Ram 3500 4WD Diesel

Quick Specs

  • Front Lift Height: 8″
  • Front Lift Method: Coil Springs
  • Rear Lift Height: 5″
  • Rear Lift Method: Block Kit
  • Install Time Hrs: 6-8
  • Difficulty Level 1-5: 3
  • Wheel Size: 17 X 9
  • Back Spacing: 4.5-5″
  • Max Tire Size: 38 X 13.50
8900

on

Zone Offroad 8″ Coil Springs Lift Kit 2003, 2004, 2005, 2006, 2007 Dodge Ram 2500/3500

Part: D24/D25

This new Zone Offroad 8″ suspension system for the 2003-2007 1 ton and 3/4 ton Dodge Ram is performance packed and budget friendly for those looking to get 38″ tires under their HD Dodge truck. The lift uses a unique control arm relocation design. Both the stock upper and lower arms are relocated to relieve angles, properly position the front axle and provide good caster and front pinion angle settings. The 1/4″ steel constructed relocation brackets mount directly to stock locations and only require a few new holes to be drilled for extra support. No cutting of the frame or axle mounts is required. Stock alignment adjustability is retained. Stock control arm angles are maintained to provide a great ride, handling and control.

In addition to the control arm brackets, all the necessary additional components are included. Full-length coil springs, dropped pitman arm, track bar relocation, sway bar relocation and bump stops are included. The rear kits feature new lift blocks and u-bolts. A rear carrier bearing drop kit is available also for trucks featuring a stock 2-piece rear driveshaft.

Featured Technology & Benefits

  • Unique upper and lower control arm relocation bracket design.
  • Heavy 1/4″ steel construction.
  • No cutting of the frame required.
  • High performance at a low price.

Important Notes!

  • 2-piece rear driveshaft requires carrier bearing drop kit D5505.
  • Will not fit dually applications
  • Rear axle diameter will be 3.5″ or 4″, measure before ordering
  • Minor trimming may be required with some tire/wheel combinations. A front bumper spacer kit (D5801) is available to gain clearance if necessary
  • Depending on the factory transmission mount, in rare cases some 8″ kits may not require the transfer case indexing kit. See installation instructions for details.
  • Lift springs are designed for diesel models only.

This product fits the following applications:

  • 2003 Dodge/Ram Ram 2500 4WD Diesel
  • 2004 Dodge/Ram Ram 2500 4WD Diesel
  • 2005 Dodge/Ram Ram 2500 4WD Diesel
  • 2006 Dodge/Ram Ram 2500 4WD Diesel
  • 2007 Dodge/Ram Ram 2500 4WD Diesel
  • 2003 Dodge/Ram Ram 3500 4WD Diesel
  • 2004 Dodge/Ram Ram 3500 4WD Diesel
  • 2005 Dodge/Ram Ram 3500 4WD Diesel
  • 2006 Dodge/Ram Ram 3500 4WD Diesel
  • 2007 Dodge/Ram Ram 3500 4WD Diesel

Quick Specs

  • Front Lift Height: 8″
  • Front Lift Method: Coil Springs
  • Rear Lift Height: 5″
  • Rear Lift Method: Block Kit
  • Install Time Hrs: 6-8
  • Difficulty Level 1-5: 3
  • Wheel Size: 17 X 9
  • Back Spacing: 4.5-5″
  • Max Tire Size: 38 X 13.50
