Bilstein B4 OE Replacement Rear Shocks for 2000, 2001, 2002, 2003 Mercedes-Benz E320

Part: 24-100564

Bilstein B4 OE Replacement dampers are specifically engineered to be the best choice for maintaining the original ride quality of your vehicle, while meeting or exceeding OE standards. These dampers are the ideal choice for the driver looking to restore the original performance and handling of their vehicle, with the added benefit of world-famous Bilstein quality.

Collapsed Length (in): 17.99

Extended Length (in): 21.59

Collapsed Length (mm): 457.0

Extended Length (mm): 548.5

Lower Mount Type: Eye 10.4mm

Upper Mount Type: Stem

Internal Design: Monotube

Finish: Black Paint

Boot Included: Black Straight

Spring Seat Included: No

22

on

Bilstein 5100 0-1.8″ Front Lift Pre-Assembled Coilovers + 0-1″ Rear Shocks for 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014 Chevy/GMC Suburban

Part: 5100BILCS07S

Level your Chevy/GMC Suburban with a matched front and rear package. The front Bilstein 5100 coilovers arrive fully assembled with OE-style coils and new top mounts, so you skip the spring compressor. Rear 5100 shocks are sized for 0-1″ rear lift to keep the truck composed and controlled.

What’s Included

  • Front (pre-assembled): 2 x Bilstein 5100 ride-height-adjustable struts 24-317818 (old 24-186940) with OE/OEM-style replacement coils, new top mounts, isolators, dust covers, and hardware
  • Rear: 2 x Bilstein 5100 shocks 24-187237 for 0-1″ rear lift

Front perch settings (clip positions)

  • Clip 4: ~1.77″ lift
  • Clip 3: ~1.18″ lift
  • Clip 2: ~0.59″ lift
  • Clip 1: 0″ stock

Actual lift varies with bumper/winch weight, accessories, and spring condition.

Why you’ll like it

  • No spring compressor needed – fronts come fully assembled
  • Adjustable 0-1.8″ front lift – set a level stance or mild lift for tire clearance
  • Bilstein 5100 control – 46 mm monotube, digressive valving for consistent, fade-resistant damping
  • OE-style comfort – tighter body control while keeping daily ride quality

Fitment

  • Vehicles: Chevy/GMC Suburban 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014
  • Drivetrain: 2WD or 4WD
  • Heights: front adjustable 0-1.8″ rear shocks matched to 0-1″ rear lift components

Technical notes

  • Snap-ring grooves set front spring seat height within the stated range
  • Monotube, nitrogen gas-charged, 46 mm piston
  • Alignment is required after installation
  • Coilover assembly time: 3-10 business days

FAQ

Do these come assembled? Yes. New coils, mounts, and hardware are installed up front.

Which clip should I choose? Start at Clip 2 or 3 for a typical level; adjust for added front weight or preferred rake.

Will the rear shocks lift my truck? No. They are sized and valved to work with up to 1″ rear lift springs or spacers.

11675

on

Bilstein B16 (PSS10) Front and Rear Kit for 2015, 2016, 2017, 2018, 2019, 2020, 2021 Volkswagen GTI

Part: 48-251570

Notes:

  • Front Lowered Height: 30-50mm
  • Rear Lowered Height: 30-50mm
  • Without Electronic Suspension
  • With Independent Rear Suspension
  • With 55mm Outside Strut Diameter

Bilstein B16 (PSS10) suspension kits feature ride height adjustability with 10-stage manually adjustable dampers in an OE quality, direct fit package. The 10-stage damping system adjusts both rebound and compression with each click to provide the best handling performance in any condition. These kits offer monotube performance dampers with matched springs that are tuned for each specific application. The zinc coated and threaded body design will give you the flexibility to find the perfect ride height setting for your intended use while providing unsurpassed protection against the harshest road elements. B16 (PSS10) suspension kits are made in Germany and feature technology tested on the famed Nürburgring.

Internal Design: Monotube

Finish: Dampers: Zinc Front Yellow Rear/Springs: Blue

Front Main Spring Rate (lbs/in): 399

Front Main Spring Type: Progressive

Rear Main Spring Rate (lbs/in): 302

Rear Main Spring Type: Linear

Front Tender Spring Rate (lbs/in): N/A

Rear Tender Spring Rate (lbs/in): N/A

18

on

Bilstein B16 (PSS10) Front and Rear Kit for 2015, 2016, 2017, 2018, 2019 Golf R

Part: 48-251570

Notes:

  • Front Lowered Height: 30-50mm
  • Rear Lowered Height: 30-50mm
  • Without Electronic Suspension
  • With Independent Rear Suspension
  • With 55mm Outside Strut Diameter

Bilstein B16 (PSS10) suspension kits feature ride height adjustability with 10-stage manually adjustable dampers in an OE quality, direct fit package. The 10-stage damping system adjusts both rebound and compression with each click to provide the best handling performance in any condition. These kits offer monotube performance dampers with matched springs that are tuned for each specific application. The zinc coated and threaded body design will give you the flexibility to find the perfect ride height setting for your intended use while providing unsurpassed protection against the harshest road elements. B16 (PSS10) suspension kits are made in Germany and feature technology tested on the famed Nürburgring.

Internal Design: Monotube

Finish: Dampers: Zinc Front Yellow Rear/Springs: Blue

Front Main Spring Rate (lbs/in): 399

Front Main Spring Type: Progressive

Rear Main Spring Rate (lbs/in): 302

Rear Main Spring Type: Linear

Front Tender Spring Rate (lbs/in): N/A

Rear Tender Spring Rate (lbs/in): N/A

20
