Bilstein B8 8112 Black Hawk 1-2.25″ Front Lift Coilovers and 0-1″ Rear Lift for 2022, 2023, 2024, 2025 Toyota Tundra

Part: 41-332245 and 41-332238_25-332315 and 25-352016

Notes: Aftermarket Upper Control Arms required

BILSTEIN B8 8112 Black Hawk 3-Way adjustable coilovers are direct fit, feature packed solutions for trucks and SUVs. The large 2.65” OD Aluminum shock body paired with a unique finned remote reservoir offers ZoneControl® position sensitive damping in both compression and rebound.  Plus, 3 external damping adjustments for high/low speed compression and the internal bump stop provides a wide range of damping option.  The ZoneControl® offers a significant advantage by virtually eliminating hard bottoming and keeping the ride buttery smooth over the small stuff. Whether you’re driving rugged trails or paved roads, fully loaded or unloaded, the B8 8112 Black Hawk offers the “best in class” ride experience.

Collapsed Length (in): 16.80

Extended Length (in): 21.83

Collapsed Length (mm): 426.8

Extended Length (mm): 554.4

Lower Mount Type: Eye 19.05mm

Upper Mount Type: Eye 12mm

Internal Design: Monotube

Finish: Dampers: Zinc Plated/Springs: Black

Reservoir: Yes – Finned Aluminum

Body Design: Smooth Body (Coilover)

Body Diameter (od): 2.65 in.

Piston Diameter: 60mm

Body Material: Aluminum

Boot Included: No

Spring Seat Included: Yes

Front Main Spring Rate (lbs/in): 600 lbs

Shaft Diameter (mm): 22.0

Adjustable Damping: Click Adjusters for High and Low Speed Compression plus internal Bump Stop (JCO)



Rear Shocks:

Part Number: 25-332315 and 25-352016

Notes: Without Rear Air Suspension

Collapsed Length (in): 16.78

Extended Length (in): 25.18

Collapsed Length (mm): 426.3

Extended Length (mm): 639.5

Lower Mount Type: Eye 19.1mm

Upper Mount Type: Stem

Internal Design: Monotube

Finish: EVO Grey

Reservoir: Yes – Finned Aluminum

Body Design: 60mm ID Smooth Body (Non-Coilover)

Body Diameter (od): 2.65 in.

Piston Diameter: 60mm

Body Material: Aluminum

Boot Included: No

Spring Seat Included: No

Shaft Diameter: 18mm

Adjustable Damping: Click Adjusters for High and Low Speed Compression plus internal Bump Stop (JCO)

29

on

Bilstein B8 6100 0-1″ Rear Lift Shocks for 2023, 2024, 2025 Toyota Sequoia 4WD (Heavy Load – 500 lb)

Part: 24-332958

Notes:
  • Heavy Load Option – 500 lb Constant Rear Weight
  • Recommended for use with Heavy Load B12 Special spring kit 53-329299
  • Fits Vehicles With 0-1″ Rear Lift– Without Rear Air Suspension
  • Without Adaptive Variable Suspension (AVS)

Bilstein B8 6100 shock absorbers are filled with the technology perfected over 3 decades of off-road dominance. Bilstein’s monotube gas pressure design with a large 2.65-in OD body and 60mm digressive piston maximizes heat dissipation for increased shock life, and decreases oil foaming to prevent performance loss while providing a smoother ride and more control over rough terrain. The B8 6100 will provide increased durability, making them perfect for vehicles subjected to rugged roads and harsh conditions.

Collapsed Length (in): 16.59

Extended Length (in): 25.18

Collapsed Length (mm): 421.4

Extended Length (mm): 639.5

Stroke/travel Length (in): 8.59

Lower Mount Type: Eye 19.1mm

Upper Mount Type: Stem

Internal Design: Monotube

Finish: Zinc Plated

Reservoir: No

Body Design: Smooth Body (Non-coilover)

Body Diameter (od): 2.65 in.

Piston Diameter: 60mm

Boot Included: Black Bellows

Spring Seat Included: No

Shaft Diameter: 18mm

Adjustable Damping: Non-Adjustable

58

on

Bilstein B8 6100 0-1″ Rear Lift Shocks for 2022, 2023, 2024, 2025 Toyota Tundra 4WD (Heavy Load – 500 lb)

Part: 24-332958

Notes:
  • Heavy Load Option – 500 lb Constant Rear Weight
  • Recommended for use with Heavy Load B12 Special spring kit 53-329299
  • Fits Vehicles With 0-1″ Rear Lift– Without Rear Air Suspension
  • Without Adaptive Variable Suspension (AVS)

Bilstein B8 6100 shock absorbers are filled with the technology perfected over 3 decades of off-road dominance. Bilstein’s monotube gas pressure design with a large 2.65-in OD body and 60mm digressive piston maximizes heat dissipation for increased shock life, and decreases oil foaming to prevent performance loss while providing a smoother ride and more control over rough terrain. The B8 6100 will provide increased durability, making them perfect for vehicles subjected to rugged roads and harsh conditions.

Collapsed Length (in): 16.59

Extended Length (in): 25.18

Collapsed Length (mm): 421.4

Extended Length (mm): 639.5

Stroke/travel Length (in): 8.59

Lower Mount Type: Eye 19.1mm

Upper Mount Type: Stem

Internal Design: Monotube

Finish: Zinc Plated

Reservoir: No

Body Design: Smooth Body (Non-coilover)

Body Diameter (od): 2.65 in.

Piston Diameter: 60mm

Boot Included: Black Bellows

Spring Seat Included: No

Shaft Diameter: 18mm

Adjustable Damping: Non-Adjustable

65

on

Bilstein B8 5100 (Ride Height Adjustable) 0-2.3″ Front and 0-1″ Rear Lift Shocks for 2023, 2024, 2025 Toyota Sequoia (Heavy Load Option – 500 lb)

Part: 24-329200_24-332903

Bilstein B8 5100 (Ride Height Adjustable) shock absorbers are designed for trucks and SUVs with a front OE coilover style suspension. Multiple snap-ring grooves in the body allow for different spring seat positions, providing 0-3 inches of front lift with OE springs (depending on application). The monotube shock absorbers feature a 46mm digressive piston a with self-adjusting deflective disc valve setting.  Bilstein B8 5100 (Ride Height Adjustable) shock absorbers provide increased wheel travel and improved handling. Utilizing a B8 5100 (Ride Height Adjustable) shock absorber is the easiest way to level out your vehicle.

Front Shocks:

Collapsed Length (in) :15.91

Extended Length (in) :20.22

Collapsed Length (mm) :404.0

Extended Length (mm) :513.5

Finish :Zinc Plated

Reservoir :No

Body Design :Snap Ring Grooved Body (Coilover)

Body Diameter (id) :46mm

Spring Seat Included :Yes

Adjustable Damping :Non-Adjustable

Notes:

  • Provides 0-2.3″ Front Lift
  • Without TRD Sport Package



Rear Shocks:

Part Number: 24-332903

Notes:

  • Heavy Load Option – 500 lb Constant Rear Weight
  • Recommended for use with Heavy Load B12 Special spring kit 53-329275
  • Fits Vehicles With 0-1″ Rear Lift– Without Rear Air Suspension
  • Without Adaptive Variable Suspension (AVS)

Collapsed Length (in): 16.59

Extended Length (in): 25.06

Collapsed Length (mm): 421.4

Extended Length (mm): 636.5

Stroke/travel Length (in): 8.47

Lower Mount Type: Eye 19.1mm

Upper Mount Type: Stem

Internal Design: Monotube

Finish: Zinc Plated

Reservoir: No

Body Design: Smooth Body (Non-coilover)

Body Diameter (od): 2.0 in.

Piston Diameter: 46mm

Boot Included: Black Bellows

Spring Seat Included: No

Shaft Diameter: 14mm

Adjustable Damping: Non-Adjustable
