For 2013, 2014, 2015, 2016, 2017, 2018 Toyota RAV4

Part: 22-328403_22-328410_ASB_24-328425

Position: Front Left (22-328403)

Position: Front Right (22-328410)

Upgrade the suspension performance and off-road capability of your 2013-2018 Toyota RAV4 with the Bilstein B8 TerraSport 1″ Front Lift Assembled Coilovers. Designed to provide a 1-inch front lift, these pre-assembled coilovers enhance ground clearance, improve suspension articulation, and deliver a smoother ride over rough terrain. Built with Bilstein’s monotube gas-pressure technology, the TerraSport coilovers are engineered for maximum durability and consistent performance, making them ideal for overlanding, trail driving, and everyday use.

Key Features:

1″ Front Lift – Provides extra clearance for larger tires and improved off-road capability.
Pre-Assembled for Easy Installation – Direct bolt-on design with no need for spring compressors.
Bilstein Monotube Technology – Ensures consistent performance and superior heat dissipation.
Tuned for Off-Road & On-Road Use – Balances comfort and control across different terrains.
Heavy-Duty Zinc Plated Finish – Resists corrosion and extends lifespan.
Gas-Pressure Technology – Maintains consistent damping performance under load.

Benefits:

  • Increased Ground Clearance – Handles rough trails and uneven terrain with confidence.
  • Enhanced Ride Quality – Reduces body roll and improves overall handling.
  • Improved Suspension Travel – Greater flexibility and control over off-road obstacles.
  • Supports Larger Tires – More clearance for aggressive tire setups.
  • All-Weather Performance – Engineered to withstand harsh conditions, from mud to snow.

Give your Toyota RAV4 the off-road edge with the Bilstein B8 TerraSport 1″ Front Lift Assembled Coilovers. Order now and experience the difference on your next adventure!

REAR SHOCKS:

Part Number: 24-328425

Collapsed Length (in): 11.56

Extended Length (in): 16.88

Collapsed Length (mm): 293.5

Extended Length (mm): 428.7

Lower Mount Type: Eye

Upper Mount Type: Eye

Internal Design: Monotube

Finish: Silver Paint

Boot Included: Yes

Spring Seat Included: No

Adjustable Damping: Non-Adjustable

Kit Supporting Components: 1 x 10mm Spring Spacer; Related Hardware; Detailed Instructions

218

on

Bilstein 4600 Front & Rear Shocks for 2002-2005 Freightliner XC

Part Numbers: Front – 24-234498, Rear – 24-234504
Series: Bilstein B6 (4600)
Position: Front & Rear
Chassis: Freightliner XC / X-Line (XCS, XCR, XCM, XCF, XCL)
Suspension Type: Monobeam Front Axle
Year Range: 2002-2005
Finish: Zinc Plated

Engineered for Motorhome Stability & Comfort

The Bilstein 4600 Series is purpose-built for heavy-duty chassis like the Freightliner XC. These monotube shocks transform your RV’s handling—delivering confident control, fade-free damping, and reduced sway on long hauls or uneven highways. Tuned specifically for the Freightliner X-Line motorhome platform, the B6 series provides the perfect balance of comfort and road feedback without the harshness of typical heavy-duty dampers.

Key Features

  • Monotube Gas Pressure Technology: Ensures consistent, fade-free performance even under demanding conditions.
  • Digressive Piston Design: Automatically adjusts to road inputs for smoother ride quality and sharper response.
  • Vehicle-Specific Valving: Calibrated exclusively for Freightliner XC motorhomes to improve control and comfort.
  • Zinc-Plated Finish: Protects against corrosion for long service life.
  • Direct Bolt-On Fit: No modifications required—engineered to OE mounting specs.

Technical Specs

Position Extended / Collapsed (in) Mount Type (Upper/Lower) Boot Shaft Dia.
Front (24-234498) 24.11 / 15.00 Eye / Eye Black Bellows 14 mm
Rear (24-234504) 20.94 / 13.70 Eye / Eye Blue Straight 14 mm

Applications

Freightliner XC, XC Formed Rail, XC Lowered Rail, XC Modular Rail, XC Raised Rail, XC Straight Rail (2002-2005). Compatible with Monobeam front axle configurations built from February 2002 onward.

Why Upgrade to Bilstein 4600?

Designed for drivers who demand more than stock performance, the Bilstein B6 4600 reduces body roll, improves steering stability, and enhances overall driving confidence—especially important for large Class-A RVs and diesel pushers built on the Freightliner XC chassis. The result: a smoother, more composed ride that feels less fatiguing on long trips.

Warranty & Quality

Backed by Bilstein’s Limited Lifetime Warranty and built in Germany using precision-machined components and high-grade materials. Each shock is tested to meet Bilstein’s stringent OE standards.

9

on

Bilstein B4 OE Replacement Rear Shocks for 1999-2005 Volkswagen Jetta

Part: 19-029429

Notes: Standard Suspension

Bilstein B4 OE Replacement dampers are specifically engineered to be the best choice for maintaining the original ride quality of your vehicle, while meeting or exceeding OE standards. These dampers are the ideal choice for the driver looking to restore the original performance and handling of their vehicle, with the added benefit of world-famous Bilstein quality.

Collapsed Length (in): 15.75

Extended Length (in): 25.20

Collapsed Length (mm): 400.0

Extended Length (mm): 640.0

Lower Mount Type: Eye 10mm

Upper Mount Type: Stem

Internal Design: Twintube

Finish: Black Paint

Boot Included: No

Spring Seat Included: No

16

on

Bilstein B4 OE Replacement Rear Shocks for 1999-2006 Volkswagen Golf

Part: 19-029429

Notes: Standard Suspension

Bilstein B4 OE Replacement dampers are specifically engineered to be the best choice for maintaining the original ride quality of your vehicle, while meeting or exceeding OE standards. These dampers are the ideal choice for the driver looking to restore the original performance and handling of their vehicle, with the added benefit of world-famous Bilstein quality.

Collapsed Length (in): 15.75

Extended Length (in): 25.20

Collapsed Length (mm): 400.0

Extended Length (mm): 640.0

Lower Mount Type: Eye 10mm

Upper Mount Type: Stem

Internal Design: Twintube

Finish: Black Paint

Boot Included: No

Spring Seat Included: No
