Synergy Weld-On Rear Axle Truss for 2007-2018 Jeep Wrangler JK

Jeep JK rear axle truss designed to strengthen the factory rear axle housing. CNC formed design significantly reduces installation time compared to multi-piece designs and is compatible with all Synergy rear track bar relocation brackets. Recommended to be used in conjunction with 8012-15 front axle truss.

Fitment: 2007-2017 Jeep Wrangler

Features:

  • Strengthens factory JK axle housing
  • Formed design significantly reduces installation time compared to multi-piece designs
  • Compatible with stock, Synergy Bolt-On, and Synergy Weld-On Track Bar Relocation Brackets
  • CNC formed 3/16 inch Steel Construction
  • Seams welded
  • Compatible with both Rubicon and non-Rubicon Jeeps
  • Does not require additional bump-stop spacer height
  • Requires cutting/welding experience – should be installed by experienced welder/fabricator

Notes:

  • Compatible with bolt-on and weld-on rear track bar relocation brackets, 8076, 8076-RHD, 8056, 8056-RHD and 8072-01.
  • Axle truss and track bar brackets can be installed in any order.
  • Recommended to be used in conjunction with 8012-15 front axle truss.
  • Requires welding
  • Some trimming/fitment may be required due to slight variations from axle to axle
  • Length of this truss is 26-3/8 inches

Installation Instructions

Prop. 65 Warning for California ResidentsMore information: www.p65warnings.ca.gov
6

on

Replacement Double Adjuster Sleeve for all Synergy Items that use Double Adjuster Assemblies. See table below for adjuster sleeve part number that matches the item you are trying to replace it on.

Part # Style ID Thread OD Thread Fits Adjuster
Tube Adapter		 Replacement for Part #
3622-06-16-10-PL Pin 3/4 – 16 LH 1 – 16 RH – 8062, 8068, 8075, 8087, 8156, 8233-03
3622-07-14L-10-PL Pin 7/8 – 14 LH 1-1/8 – 16 RH 3620-0703
3620-0701		 8550-01, 8550-02, 8550-11
3622-07-14L-PL Hex 7/8 – 14 LH 1-1/8 – 16 RH 3620-0703
3620-0701		 8035, 8053, 8075-02, 8151, 8152, 8232, 8853-01, 8862-01, 8875-01
3622-07-18-PL Hex 7/8 – 18 LH 1-1/8 – 16 RH 3620-0702
3620-0704		 8000-01, 8001, 8002, 8002-15, 8121-02, 8155-01
3622-10-14-PL Hex 1 – 14 LH 1-1/4 – 14 RH 3620-0801
3620-0802		 8038, 8054, 8553-01, 8567-01, 8567-02, 8567-03, 8567-11, 8567-12, 8567-13, 8568-01, 8568-02, 8568-03, 8701-01, 8800-01, 8802-01, 8802-11, 8704-01, 8600-01, 8675-01, 8568-21, 8568-22, 8568-23
3622-12-12-PL Hex 1-1/4 – 12 LH 1-1/2 – 12 RH 3620-10013620-1002 8033, 8036, 8051, 8052, 8153, 8231, 8551-01, 8551-02, 8551-03, 8583-02, 8583-03, 8585, 8551-04, 8583-04, 8702-01, 8702-11 8851-01, 8602-01, 7052-01, 7054-01, 7675-01, 7675-02

Prop. 65 Warning for California ResidentsMore information: www.p65warnings.ca.gov
5

on

Replacement Double Adjuster Sleeve for all Synergy Items that use Double Adjuster Assemblies. See table below for adjuster sleeve part number that matches the item you are trying to replace it on.

Part # Style ID Thread OD Thread Fits Adjuster
Tube Adapter		 Replacement for Part #
3622-06-16-10-PL Pin 3/4 – 16 LH 1 – 16 RH – 8062, 8068, 8075, 8087, 8156, 8233-03
3622-07-14L-10-PL Pin 7/8 – 14 LH 1-1/8 – 16 RH 3620-0703
3620-0701		 8550-01, 8550-02, 8550-11
3622-07-14L-PL Hex 7/8 – 14 LH 1-1/8 – 16 RH 3620-0703
3620-0701		 8035, 8053, 8075-02, 8151, 8152, 8232, 8853-01, 8862-01, 8875-01
3622-07-18-PL Hex 7/8 – 18 LH 1-1/8 – 16 RH 3620-0702
3620-0704		 8000-01, 8001, 8002, 8002-15, 8121-02, 8155-01
3622-10-14-PL Hex 1 – 14 LH 1-1/4 – 14 RH 3620-0801
3620-0802		 8038, 8054, 8553-01, 8567-01, 8567-02, 8567-03, 8567-11, 8567-12, 8567-13, 8568-01, 8568-02, 8568-03, 8701-01, 8800-01, 8802-01, 8802-11, 8704-01, 8600-01, 8675-01, 8568-21, 8568-22, 8568-23
3622-12-12-PL Hex 1-1/4 – 12 LH 1-1/2 – 12 RH 3620-10013620-1002 8033, 8036, 8051, 8052, 8153, 8231, 8551-01, 8551-02, 8551-03, 8583-02, 8583-03, 8585, 8551-04, 8583-04, 8702-01, 8702-11 8851-01, 8602-01, 7052-01, 7054-01, 7675-01, 7675-02

Prop. 65 Warning for California ResidentsMore information: www.p65warnings.ca.gov
