Fitments:

Part # Description Fitment Mounting Width
(A)		 Bolt Size (D) OD
(C)		 Housing
Part #
4320-01 LOWER CONTROL ARM BUSHING 8033, 8036, 8046, 8047, 8051, 8052, 8153, 8551-04, 8154, 8231,
8551-01, 8563-01, 8585, 8232		 2.618″ 9/16″ / 14MM 2.249″ 4408-01
4320-02 CONTROL ARM BUSHING  8551-02, 8563-02, 8583-02, 8583-04, 8851-01, 8870-01, 8871-01, 8891-05, 8892-06 2.618″ 5/8″ /
16MM		 2.249″ 4408-01
4320-03 DODGE LOWER CONTROL ARM BUSHING 8551-03, 8563-03, 8583-03 2.618″ 3/4″ /
18MM		 2.249″ 4408-01
4320-04 BRONCO REAR CONTROL ARM BUSHING 7052-01, 7054-01 74MM 5/8″ /
16MM		 2.249″ 4408-01
4320-05 BRONCO REAR CONTROL ARM BUSHING 7052-01, 7054-01 70MM 5/8″ /
16MM		 2.249″ 4408-01
4321-01 JEEP FRONT UPPER CONTROL ARM BUSHING 8053, 8853-01 2.000″ 1/2″ /
12MM		 2.124″ 4410-01
4321-02 JEEP UPPER CONTROL ARM BUSHING 8151, 8152 2.000″ 3/8″ /
10MM		 2.124″ 4410-01
4321-03 FRONT UPPER CONTROL ARM BUSHING 8035, 8891-07, 8853-01 2.000″ 1/2″
12MM		 2.124″ 4410-01
4322-01** UPPER CONTROL ARM BUSHING 8038, 8054, 8854-01, 8553-01, 8892-08 2.360″ 9/16″ / 14MM 2.124″ 4407-01
4322-02 UPPER CONTROL ARM BUSHING 8038 2.618″ 9/16″ / 14MM 2.124″ 4407-01
4323-01 JEEP TRACK BAR BUSHING 8062, 8068, 8075, 8087, 8233-03 1.600″ 9/16″ / 14MM 1.499″ 4402-01
4323-02 JEEP TRACK BAR BUSHING 8155-01, 8156 1.600″ 1/2″ /
12MM		 1.499 4402-01
4324-01* DODGE TRACK BAR BUSHING 8550-01, 8550-02 1.600″ 9/16″ / 14MM 1.624″ 4409-01
4324-02* DODGE TRACK BAR BUSHING 8550-01, 1.600″ 5/8″ / 16MM 1.624″ 4409-01
4324-03 21+ BRONCO REAR TRACK BAR BUSHING 7062-01 2.188″ 5/8″ / 16MM 1.633″ 4803-01
4326-02 FRONT UPPER CONTROL ARM BUSHING (AXLE SIDE) 8012-15, 8012-16, 8012-18 2.000″ 1/2″ /
12MM		 1.782″ 8012-18 *
4327-01 JEEP TRACK BAR BUSHING 8075-02, 8862-01, 8875-01 1.600″ 9/16″ / 14MM 1.758″ 4409-01
4327-02 FORD TRACK BAR BUSHING 8675-01, 7675-01, 7675-02 1.732″ 13/16″
20MM		 1.758″ 8675-01*
4327-03 DODGE RAM 2500/3500 2003-2008 8550-11 1.600 9/16″ / 14MM 1.758″ 4409-01
4327-04 DODGE RAM 2500/3500 2008.5-2013 8550-11 1.600 5/8″ / 16MM 1.758″ 4409-01
4328-02 DODGE RAM 2500/3500
2014+		 8704-01*, 8704-11  1.63″ 3/4″ /
18MM		 1.875 4810-01
*Housing only available as part of 8675-01

Specifications:


Part # A
(MOUNTING
WIDTH)		 B
(SHELL LENGTH)		 C
(OD)		 D
(SLEEVE ID)
4320-01 2.618 2 2.267 0.563
4320-02 2.618 2 2.267 0.638
4320-03 2.618 2 2.267 0.717
4321-01 2 1.75 2.135 0.505
4321-02 2 1.75 2.135 0.402
4321-03 2 1.5 2.135 0.505
4322-01 2.32 1.75 2.135 0.563
4323-01 1.6 1.25 1.508 0.563
4323-02 1.6 1.25 1.508 0.525
4324-01 1.6 1.25 1.657 0.563
4324-02 1.6 1.25 1.657 0.638
4327-02 1.732 1.375 1.758 20mm
4328-02 1.6 1.41 1.887 0.717

Features:

  • Synergy Dual Durometer Bushing (DDB) Series
  • Feature a maintenance free, grease less design.
  • Self centering with 30 degrees of misalignment. (4320-01, 4320-02, 4320-03)
  • Outer “soft” durometer acts as bushing cushion and flex material.
  • Inner “hard” durometer lining acts as the bearing surface to allow free floating inner sleeve to rotate. Provides for a maintenance free “zero bind” bushing.
  • Internal bushing ring separates inner and outer materials to prevent inner sleeve gaping at extreme flex.
  • Direct replacement available for aftermarket control arms using OEM Cleveite style lower control arm bushings.
  • Bushings available for all suspension components made by Synergy MFG as well as many other companies.
  • Bushings are sold complete with inner sleeve installed.
  • Check out the Video!

IMPORTANT: Dual Durometer Bushings (DDB) are not a replacement for Synergy products that originally came with Johnny Joints. These bushings are only replacements for Synergy products that came with Dual Durometer Bushings (DDB). Please call/email for more information on specific products. 805.242.0397 / support@synergymfg.com

Notes:

  • Parts in red do not yet come with these bushings.
  • 4320-01, 4320-02 and 4320-03 have nylon outer shell.
  • 4324-01 and 4324-02 replacement bushings are only for 8550-01 and 8550-02 Track Bars who came with these bushings. If upgrading from 4306-01 polyurethane bushings, Dual Durometer Bushings (DDB) can be retrofitted one of two ways depending on bolt size:
    – 94-07 trucks with 14mm or  9/16″ bolt: Replace with 4323-01 Dual Durometer Bushing (DDB) or use 8529-01 Retrofit Kit.
    – 08-13 trucks with 16mm or 5/8″ bolt: Must use 8529-01 Retrofit Kit.
  • 8550-01 track bars built 5/19/2015 and newer and 8550-02 track bars built 2/13/2015 and newer require replacement bushings 4324-01 or 4324-02 depending on bolt size.
  • 4327-03 & 4327-04 are an updated stiffer bushing for the 8550-11
  • **4322-01 bushing is not a retrofit for 8054 that came with Poly bushing halves. Correct replacement bushing is 4303-01 bushing halves.
  • *Housing only available as part of 8012-18 kit


Prop. 65 Warning for California ResidentsMore information: www.p65warnings.ca.gov
