Synergy Adjustable Front Lower Control Arms 0-6″ Lift for 2007-2018 Jeep Wrangler JK

Our Synergy Jeep JK / JKU Adjustable Front Lower Control Arms fit seamlessly into your stock control arm mounts, providing a heavier duty option over stock. They are engineered to be stronger than stock control arms and bent to improve ground clearance, making them ideal to use in a lifted Jeep application. The included Synergy Dual Durometer Bushings drastically improve ride quality and stability over OEM bushings, improving your on and offroad experience and increasing longevity of the joints! Finished with a high-quality powder coat to prevent corrosion and rust and protect your investment.

Fitment:

Part #	Description
8051	2007 – 2017 Jeep JK / JKU

Benefits:

• Heavy-duty design prevents bending / breaking on direct impacts, providing worry-free adventures
• Arms are bent up for improved ground clearance over stock
• Synergy Dual Durometer Bushings take your Jeep to the next level, increasing flex, longevity, and providing a smooth ride
• Adjustable length over the fixed stock arms make fitment easy in both stock height and Jeeps with small lifts
• Engineered to fit with OEM wheels and larger tires without the use of an additional wheel spacer
  100% bolt-in components make installation simple and fast
• Synergy double adjuster sleeve & pinch bolt assembly allows for adjustment of control arm length without removing control arm mounting bolt

Features:

• Abrasion-resistant powder coat finish for maximum durability and corrosion resistance
• Made from high-quality, crush resistant 1 3/4″ X .188 wall USA made 1026 DOM tubing
• Small bend to improve ground clearance
• Synergy Dual Durometer Bushings (DDB) with Teflon® bearing surface for a maintenance free design focusing on performance, flex, longevity, and ride quality.
• 100% bolt on components assures an easy, trouble free installation with the use of basic hand tools

Min/Max Lengths:
Measured in a straight line from center of bolt hole to center of bolt hole

• MAX EXTENDED LENGTH: 24″
• MIN COLLAPSED LENGTH: 22.50″

Includes:

8051

(2)  Dual Durometer Bushing (DDB) Assemblies (2) Dual Durometer Bushing (DDB) Flex Joints (2) Dual Durometer Bushing (DDB) Assemblies (2) Adjustable Front Lower Control Arms (2) Pinch Bolts & Grade 8 Hardware (2) Synergy Double Adjuster Sleeves



Notes:

• When upgrading to adjustable control arms, it is recommended to replace the cam bolts with our Synergy Cam Bolt Eliminator Kit Front Lower Control Arm for 2007-2018 Jeep Wrangler JK

Installation Instructions



---



More information: www.p65warnings.ca.gov

The Stage 1 System offers the next level of performance from the Starter System by including a Front Adjustable Track Bar and Rear Track Bar Relocation Bracket in addition to 2″ Lift Springs. These key components allow centering of the front and rear axles and provide a raised roll center height in the rear, resulting in increased handling and performance. This system will fit 33″ tires with stock fenders or 35″ tires with high fenders.

Fitments:

Fitment Notes:

• **Front & Rear shock mounting brackets (8019) are not compatible with aftermarket shocks and are required when using factory shocks. Use of Factory (stock) shocks requires a cut-off wheel for removal of the rear stock lower shock mounts.
• Springs are designed to provide the advertised amount of lift with use of aftermarket bumpers, winches, & tire carriers. More lift will occur on vehicles in stock trim.
• Springs retain the factory rake of the vehicle where the rear is higher than the front. Vehicle should sit level when loaded. Request one size shorter rear springs to level the vehicle out when unloaded.
• RHD = Right Hand Drive

Features:

• Stage 1 key features are a front adjustable track bar and rear track bar relocation bracket
• Front and rear bump stop extension kits
• Rear sway bar links so the factory rears can be used in the front
• Front and rear brake line relocation kits
• Rear track bar relocation bracket raises track bar mounting position increasing suspension roll center height which improves handling on and off road
• Control arm cam bolt kit to correct caster
• Optional shock relocation brackets so the stock shocks can be reused
• Progressive wound coil spring manufactured using the latest in CNC hot winding technology keeps spring from coming unbound at full suspension droop
• Suspension components feature an abrasion-resistant powder coat finish for maximum durability and corrosion resistance
• 100% bolt on components assure an easy, trouble free installation with the use of basic hand tools**
• Requires a maximum 4-3/4″ backspace wheel or wheel spacer with factory wheel setup. 4-1/2″ back spacing is recommended
• Synergy suspension systems are a modular design so all components are available separately
• Available For Right Hand Drive (RHD) Vehicles

8021-20 / 8041-20 Includes:

8021-20-RHD / 8041-20-RHD Includes:

Recommended Components:

• (1) 8007-03 – Fox Hi-Mount Stabilizer Kit
