The Stage 2 System is the first to include lower control arms and is the first system you’ll be comfortable dragging over rocks. It includes all the components from the Stage 1.5 System with the addition of Heavy Duty Lower Control Arms (front/rear) to correct caster and increase durability off road. These lower control arms are designed to take abuse and are adjustable for low maintenance and worry free wheeling. This system will fit 35″ tires with stock fenders or 37″ tires with high fenders.

Fitments:

Part # Description
8022-30 JK / JKU 2-Door 3″ Lift Stage 2 Kit (Fits 35″ Tires, 37″ with High Fenders)
8042-30 JK / JKU 4-Door 3″ Lift Stage 2 Kit (Fits 35″ Tires, 37″ with High Fenders)

Fitment Notes:

  • 2012+ JK’s lifted over 2″ will require exhaust spacers (5017), or a front aftermarket drive shaft to prevent interference with the exhaust.
  • “3” and up lifts, aftermarket driveshafts are recommended. When a rear aftermarket driveshaft is used with the Stage 2 Suspension System, rear adjustable upper control arms must also be used to correct the rear pinion angle.
  • Springs are designed to provide the advertised amount of lift with use of aftermarket bumpers, winches, & tire carriers. More lift will occur on vehicles in stock trim.
  • Springs retain the factory rake of the vehicle where the rear is higher than the front. Vehicle should sit level when loaded. Request one size shorter rear springs to level the vehicle out when unloaded.
  • Requires 16″ or larger wheel diameter

Features:

  • Stage 2 key features are front and rear track bar relocation brackets, flipped drag link, and heavy duty fixed length lower control arms
  • Front and rear bump stop extension kits
  • Front and rear sway bar links
  • Front and rear extended stainless steel braided brake lines
  • Synergy double adjuster sleeve & pinch bolt assembly allows for adjustment of control arm, track bar, tie rod, and drag link length without removal
  • Front and rear track bar relocation brackets raise track bar mounting positions increasing suspension roll center heights which improves handling on and off road
  • Lower control arms manufactured from high quality crush resistant 1-3/4″ X .188″ Wall 1026 DOM tubing to increase durability and correct caster
  • Features Synergy Dual Durometer Bushings (DDB) with Teflon® bearing surface for a maintenance free design focusing on performance, flex, longevity, and ride quality.
  • Front and rear lower shock mounts
  • Optional front sway bar disconnect system for ultimate trail articulation mounts sway bar up and out of the way when disconnected from the axle
  • Progressive wound coil spring manufactured using the latest in CNC hot winding technology keeps spring from coming unbound at full suspension droop
  • Suspension components feature an abrasion-resistant powder coat finish for maximum durability and corrosion resistance
  • 100% bolt on components assure an easy, trouble free installation with the use of basic hand tools
  • Requires a maximum 4-3/4″ backspace wheel or wheel spacer with factory wheel setup. 4-1/2″ back spacing is recommended
  • Synergy suspension systems are a modular design so all components are available separately

Includes:

8022-30 / 8042-30 Includes:

8022-30 – 2-Door JK / JKU 8042-30 – 4-Door JK / JKU
(1) 8063-20 3″ Front Coil Springs
(1) 8064-20 3″ Rear Coil Springs
(1) 8057-10 Snap-Lock Bump Stop Spacers
(1) 8858-30 Rear Bumpstop Extension, 3.0 Tall
(1) 8059-11 Front Sway Bar Links
(1) 8060-11 Rear Sway Bar Links
(2) 8066 Front/Rear Brake Line Kit
(1) 8056 Rear Track Bar Bracket
(1) 8055 Front Track Bar Bracket
(1) 8000-01 Drag Link
(1) 8051 – Front Lower Adjustable Control Arms
(1) 8052 – Rear Lower Adjustable Control Arms
(1) 8074 Rear Lower Shock Mounts
(1) 8073 Front Lower Shock Mounts
(1) 8097 Rear Coil Wedges		 (1) 8063-30 3″ Front Coil Springs
(1) 8064-30 3″ Rear Coil Springs
(1) 8057-10 Snap-Lock Bump Stop Spacers
(1) 8858-30 Rear Bumpstop Extension, 3.0 Tall
(1) 8059-11 Front Sway Bar Links
(1) 8060-11 Rear Sway Bar Links
(2) 8066 Front/Rear Brake Line Kit
(1) 8056 Rear Track Bar Bracket
(1) 8055 Front Track Bar Bracket
(1) 8000-01 Drag Link
(1) 8051 – Front Lower Adjustable Control Arms
(1) 8052 – Rear Lower Adjustable Control Arms
(1) 8074 Rear Lower Shock Mounts
(1) 8073 Front Lower Shock Mounts
(1) 8097 Rear Coil Wedges

Recommended Components:

Prop. 65 Warning for California ResidentsMore information: www.p65warnings.ca.gov
4

on

Synergy Adjustable Front Track Bar 0-6″ Lift for 2007-2018 Jeep Wrangler JK/JKU

The Synergy Jeep JK / JKU Adjustable Front Track Bar is used to help center your axles when running a suspension lift. This track bar also significantly improves lateral stiffness over stock to hold up to the abuse of large tires and aggressive off road driving. Length is adjustable on the vehicle to make adjustments a breeze. Uses maintenance free Synergy Dual Durometer Bushings on both ends. Designed to clear most aftermarket differential covers.

Fitments:

Part # Description
8075-02 Synergy Jeep JK Front Track Bar

Benefits:

  • Made from high quality 1.50 inch x .250 wall DOM
  • Retains factory track bar mounting bolts & hardware
  • Suspension components feature an abrasion-resistant powder coat finish for maximum durability and corrosion resistance
  • Synergy double adjuster sleeve & pinch bolt assembly allows for adjustment of track bar length without removing mounting bolt
  • Features Synergy Dual Durometer Bushings (DDB) with Teflon® bearing surface for a maintenance free design focusing on performance, flex, longevity, and ride quality
  • 100 percent bolt-on components assure an easy, trouble free installation with the use of basic hand tools

Features:

  • Eliminates the track bar from contributing to steering shimmy or death wobble
  • Allows centering of front axle when running a suspension lift
  • Adjustable without removing from vehicle
  • Maintenance Free, no greasing required
  • Synergy Dual Durometer Bushings eliminate binding issues associated with stock vulcanized bushings
  • No jam nuts that are impossible to keep tight
  • No modifications required to install
  • Isolates Noise, Vibration, and Harshness (NVH) increasing ride quality
  • Designed to clear most aftermarket differential covers
  • Limited Lifetime Warranty

Min/Max Length:

  • Min/max lengths: 32.25/33.00 inches

Notes:

  • Compatible from 0-7 inches of lift. Synergy MFG Front Track Bar Relocation Bracket recommended for lifts 3 inches and taller and requires a minimum 3 inches of bump stop spacing.
  • The replacement adjustable joint is 4812-01 and the replacement bushings are 4327-01
  • Replaces part number 8075

Installation Instructions (8075-02)

Prop. 65 Warning for California ResidentsMore information: www.p65warnings.ca.gov
5

on

Synergy Jeep JT / JL / JLU / JK / JKU Coil Spring Spacers provide a simple yet effective solution to lift your vehicle. Whether you want to level out your vehicles stance or give it a more aggressive appearance, our coil spring spacers offer a cost-effective alternative to a full suspension upgrade. Designed for durability and ease of installation, these spacers are crafted from high density polyurethane to retain your factory ride quality and fit perfectly in either the stock springs or the Synergy Multi-Rate Coil Springs.

Navigating the world of aftermarket parts can be challenging, especially when it comes to achieving a perfectly level ride height. Variations in vehicle weight due to different accessories, cargo, or modifications can make it difficult to maintain an even stance. This is where our premium coil spring spacers come in, providing a practical solution ensuring a balanced and consistent ride height regardless of additional weight or aftermarket modifications.

Fitments:

Part # Lift Description Tire Size Fitment
8017-075 0.750″ Front Coil Spring Spacers 32″ JK /  JL / JT
8016-075 0.750″ Rear Coil Spring Spacers 32″ JK
8816-075 0.750″ Rear Coil Spring Spacers 32″ JL
8809-075 0.750″ Rear Coil Spring Spacers 32″ JT
8017-150 1.50″ Front Coil Spring Spacers 33″  JL / JT
8809-150 1.50″ Rear Coil Spring Spacers 33″ JT
8017-175 1.750″ Front Coil Spring Spacers 33″ JK /  JL /  JT
8016-175 1.750″ Rear Coil Spring Spacers 33″ JK
8017-200 2.00″ Front Coil Spring Spacers 35″ JL / JT
8816-200 2.00″ Rear Coil Spring Spacers 35″ JL

Benefits:

  • Increased ride height to allow for larger tires and more ground clearance
  • Levels out your vehicle to eliminate sagging and ensures consistent ride height and quality
  • Available in multiple sizes, you can easily fine tune your vehicle suspension to find the perfect height without the extra expense of new coil springs
  • Simple installation makes it easier than ever to add height or level your vehicle

Features:

  • Manufactured from high density polyurethane
  • Simple, easy install on top of either the stock or Synergy spring with no welding or drilling required
  • Sold in pairs

Includes:

(2) Polyurethane Coil Spring Spacers

Notes:

  • If you want the vehicle to sit level (without the stock rake) when unloaded, our front coil springs will accommodate up to a .75 inch front coil spacer (8017-075) without requiring additional bump stop spacing

pdf-icon.gifInstallation Instructions

Prop. 65 Warning for California ResidentsMore information: www.p65warnings.ca.gov
4

on

Synergy Front Track Bar Relocation Bracket 3″+ Lift for 2007-2018 Jeep Wrangler JK/JKU

Our Synergy Jeep JK / JKU Front Track Bar Relocation Bracket corrects suspension geometry after lifting your Jeep Wrangler 3″ or more. Laser cut and precision CNC bent heavy-duty steel strengthens and supports the stock factory mount with an easy, bolt-on installation. By raising the roll center, this track bar bracket reduces body roll and dramatically improves vehicle handling and road manners. This bracket also includes a space to mount your steering stabilizer up out of harm’s way. We finish this bracket off with a durable powder coating, preventing rust and corrosion!

Fitment:

Part # Description
8055 2007 – 2017 Jeep JK / JKU

Benefits:

  • Moves the axle-side track bar mount up, correcting steering geometry and improving road manners
  • Raises the roll center, reducing body roll to improve handling
  • Strengthens the factory mount through our durable, bolt-on design preventing premature failure the stock bracket is known for
  • Relocates the factory or aftermarket steering stabilizer, getting it up out of harms way

Features:

  • Precision laser cut from heavy-duty 3/16″ steel, CNC bent for accurate fitment &
  • Two-stage powder coat finish for maximum strength, durability, and corrosion resistance
  • Steering stabilizer relocation mount to prevent unnecessary damage
  • 100% bolt on components assures an easy, trouble free installation with the use of basic hand tools
8055
(1) Track bar relocation bracket
(1) Sway bar link relocation bracket
(1) Track bar relocation bracket hardware kit

Notes:

  • Requires use of minimum 3″ bump stop spacer
  • Requires use of steering Synergy Tie Rod End Flip Adapter Front for 2007-2018 Jeep Wrangler JK
  • This track bar bracket is not recommended for hydro assist applications; For hydro assist, use the Synergy 8812-13 weld-on track bar bracket which includes hydro assist tabs
  • Synergy 8075-02 front track bar required for lifts taller than 4.5″
  • If using a front adjustable track bar other than Synergy, make sure track bar can be collapsed far enough to center axle. Track bar will need to be close to stock length once relocated.

Installation Instructions – 8055
