ICON 1-3″ Lift Kit Stage 4 for 2007-2016 GM Silverado/Sierra 1500 Small Taper

Description
ICON 1-3″ Lift Kit Stage 4 for 2007-2016 GM Silverado/Sierra 1500 Small Taper

ICON ICON 2007-2016 GM 1500 1-2.5 inches Lift Stage 4 Suspension System (Small Taper)

Part Number: K73004

Summary: The ICON Stage 4 Suspension System for the 2007–2016 GM Silverado/Sierra 1500 is engineered to provide a 1-2.5 inches lift height while drastically increasing wheel travel and damping ability. This system features 2.5 Series remote reservoir coilovers and 2.5 Aluminum Series piggyback rear shocks to ensure consistent performance during extended off-road use. By including Tubular Upper Control Arms with the high-articulation Delta Joint, this stage optimizes suspension geometry and durability for drivers seeking premium performance on and off-road.

Features

• Remote Reservoir Coilovers: 2.5 inches adjustable bodies with remote reservoirs provide increased oil volume and cooling to ensure consistent damping during aggressive off-road use.
• Delta Joint Upper Control Arms: Tubular steel design with the patented Delta Joint provides high-angle articulation and durability to ensure long-term reliability in harsh environments.
• 2.5 Aluminum Series Rear Shocks: One-piece impact extruded aluminum cylinders provide excellent corrosion resistance to ensure a consistent finish and superior heat dissipation.
• Eibach Coil Springs: ICON-developed coil springs provide superior vehicle feel to ensure performance throughout the entire range of travel.
• System Durability: CAD plated coilover shock bodies with 7/8 inches shafts provide maximum strength and corrosion resistance to ensure longevity.
• Installation: 100% Bolt-on design provides a straightforward upgrade path to ensure no drilling, cutting, or welding is required for installation.

Technical Specifications

Wheel & Tire Fitment

• OEM Wheels & Tires: Yes
• Aftermarket Wheels: 17×8.5 inches w/ 4.75” BS, 18×9 inches w/ 5” BS, or 20×9 inches w/ 5” BS (0mm Offset)
• Aftermarket Tires: 33 inches x 11.50 inches
• Note: Larger tires may fit but fender trimming and modifications will be required. Small taper applications are identified by forged steel OE front lower control arms. Not compatible with Magnetic Ride Control, Hybrid models, or SUV models. Only compatible with OE spindles.

System Components

• 71555 (qty: 1) | 07-18 GM 1500 1-2.5 inches 2.5 VS RR COILOVER KIT
• 78600DJ (qty: 1) | 07-16 GM 1500 TUBULAR UCA DJ KIT (SMALL TAPER)
• 77700P (qty: 1) | 07-18 GM 1500 0-1.5 inches REAR 2.5 VS PB PAIR

Why Choose ICON Stage 4?

• Performance Engineering: Increased wheel travel and damping for superior control.
• Delta Joint Reliability: High-angle articulation with a sealed design that combines the durability of a ball joint with the performance of a uniball.
• Fully Serviceable: Shocks are rebuildable and revalveable for long-term performance.

Frequently Asked Questions

Is this system compatible with MagneRide?
No, this system is not compatible with models equipped with Magnetic Ride Control.

How do I identify if I have a “Small Taper” model?
Small taper applications can be identified by their factory forged steel original equipment front lower control arms.
