ICON 1-3″ Lift Kit Stage 5 (Large Taper) for 2014-2016 GM Silverado/Sierra 1500 Truck

Description
ICON 1-3″ Lift Kit Stage 5 (Large Taper) for 2014-2016 GM Silverado/Sierra 1500 Truck

ICON Stage 5 1-2.5 inches Lift Suspension System for 2014–2018 GM 1500

Part Number: K73005A

Summary: The ICON Vehicle Dynamics Stage 5 suspension system provides a 1-2.5 inches lift height for the 2014–2018 GM Silverado/Sierra 1500, engineered to drastically improve both on-road handling and off-road damping. This high-performance system features 2.5 Series remote reservoir coilovers and piggyback rear shocks, both equipped with ICON’s Compression Damping Control Valve (CDCV) for precision tuning. A key differentiator in this system is the inclusion of Tubular Upper Control Arms with the heavy-duty Delta Joint, ensuring superior articulation and durability for aggressive use.

Features

• ICON CDCV Technology: Compression Damping Control Valve provides fully adjustable tuneability to ensure external control over shock damping for various terrains.
• Remote Reservoir Architecture: 2.5 inches Remote Reservoir front coilovers and piggyback rear shocks provide increased oil volume and cooling to ensure consistent performance during extended off-road use.
• Delta Joint UCA: Tubular Steel Upper Control Arms with Delta Joints provide high-angle articulation with a sealed design to ensure long-term reliability and improved suspension geometry.
• System Durability: CAD plated shock bodies with 7/8 inches shafts and 6061 CNC machined aluminum components provide maximum corrosion resistance to ensure component longevity.
• Installation: 100% Bolt-on design provides a straightforward upgrade path with no cutting, drilling, or welding required to ensure a factory-quality fitment.

Technical Specifications

Wheel & Tire Fitment

• OEM Wheels & Tires: Yes
• Aftermarket Wheels: 17×8.5 inches w/ 4.75” BS / 0mm Offset, 18×9 inches w/ 5.00” BS / 0mm Offset, or 20×9 inches w/ 5.00” BS / 0mm Offset
• Aftermarket Tires: 33 inches x 11.50 inches
• Note: Larger tires may fit but fender trimming and modifications will be required. Only compatible with OE spindles. Not compatible with Magnetic Ride Control or Hybrid models.

System Components

• 71555C: 07-18 GM 1500 1-2.5 inches 2.5 VS RR CDCV COILOVER KIT
• 78601DJ: 14-18 GM 1500 TUBULAR UCA DJ KIT (LARGE TAPER)
• 77700CP: 07-18 GM 1500 0-1.5 REAR 2.5 VS PB CDCV PAIR

Why Choose ICON Stage 5?

• Performance Engineering: Increased wheel travel and damping for superior control.
• Delta Joint Reliability: High-angle articulation with a sealed design that combines the durability of a ball joint with the performance of a uniball.
• Fully Serviceable: Shocks are rebuildable and revalveable for long-term performance.

Frequently Asked Questions

Is this system compatible with Magnetic Ride Control?
No, this system is specifically designed for non-Magnetic Ride Control models and is not compatible with Hybrid models.

Can I use aftermarket spindles with this kit?
No, these components are only compatible with OE spindles. Do not install in combination with any aftermarket spindles.
