ICON 2.5″ Lift Kit Stage 5 for 2003-2010 Dodge Ram 2500/3500 4WD

Description
ICON 2.5″ Lift Kit Stage 5 for 2003-2010 Dodge Ram 2500/3500 4WD

ICON 2003–2012 Ram 2500/3500 4WD 2.5 inches Lift Stage 5 Suspension System

Part Number: K212505T

Summary: The ICON Stage 5 Suspension System is the ultimate performance-oriented leveling solution for the 2003–2012 Ram 2500/3500 4WD, providing a 2.5 inches front lift height. This system is engineered for maximum versatility, featuring 2.5 Series Aluminum shocks equipped with CDCV technology for user-adjustable compression damping. The inclusion of heavy-duty tubular upper and lower links, along with an adjustable track bar with PTFE-lined FK bearings, ensures superior axle positioning and significantly improved ride quality over any terrain.

Features

• CDCV Adjustment: Compression Damping Control Valve provides external adjustability of compression valving to ensure optimal performance across varying terrains and cargo loads.
• Dual Rate Coil Springs: ICON-engineered dual rate springs provide increased wheel travel and ride quality to ensure a level stance without sacrificing towing capacity.
• Adjustable Track Bar: PTFE-lined FK bearings provide improved rigidity and adjustability to ensure the front axle is perfectly centered under the vehicle.
• Tubular Link Kit: Heavy-duty steel upper and lower link bars provide improved alignment range and reduced bind to ensure smooth suspension cycling and eye-catching style.
• System Durability: Impact-extruded one-piece aluminum shock cylinders provide excellent corrosion resistance to ensure a consistent finish and long-term reliability.
• Installation: Direct fitment design provides a straightforward bolt-on process to ensure no drive shaft modifications are required.

Technical Specifications

Wheel & Tire Fitment

• OEM Wheels & Tires: Yes
• Aftermarket Wheels: 17×8.5 inches w/ 5.25” BS / 13mm Offset, 18×9 inches w/ 5.50 inches BS / 12mm Offset, or 20×9 inches w/ 5.50 inches BS / 12mm Offset
• Aftermarket Tires: 33 inches x 11.50 inches
• Note: Larger tires may fit but fender trimming and modifications will be required. Springs are rated for Diesel engines only.

System Components

• 212500: 03-12 RAM HD 4WD 2.5 inches DUAL RATE SPRING KIT
• 214030: 03-12 RAM HD ADJ TRACK BAR KIT
• 214027: 03-12 RAM HD FIXED TUBULAR LINK KIT
• 217800CP: 03-12 RAM HD 2.5 inches FRONT 2.5 VS RR CDCV PAIR
• 217701CP: 03-12 RAM HD 2-3 inches REAR 2.5 VS PB CDCV PAIR

Why Choose ICON Stage 5?

• Performance Engineering: Increased wheel travel and damping for superior control on and off-road.
• CDCV Tuning: External knobs allow you to tune your ride from soft to firm in seconds.
• Fully Serviceable: Shocks are rebuildable and revalveable for long-term performance.

Frequently Asked Questions

Are these shocks adjustable?
Yes, the Stage 5 system includes ICON’s CDCV (Compression Damping Control Valve) which allows you to manually adjust the shock valving for different terrains.

Will this kit work with a HEMI gas engine?
No, these specific coil springs are rated for Diesel engines only to ensure the advertised lift height and ride quality.
