ICON 4.5″ Lift Kit Stage 1 for 2003-2008 Dodge Ram 2500/3500 4WD

Description
ICON 4.5″ Lift Kit Stage 1 for 2003-2008 Dodge Ram 2500/3500 4WD

ICON 2003–2008 Ram 2500/3500 4WD Stage 1 4.5 inches Lift Suspension System

Part Number: K214500T

Summary: The ICON Stage 1 suspension system provides a 4.5 inches lift height for 2003–2008 Ram 2500/3500 4WD trucks, engineered to increase ground clearance while maintaining proper steering geometry. This system features dual-rate coil springs and 2.0 Aluminum Series smooth body shocks to improve ride quality over varied terrain. The inclusion of tubular steel upper and lower link arms ensures a greater range of alignment and reduced bushing bind compared to factory components.

Features

• Dual-Rate Coil Springs: ICON-engineered springs provide a 4.5 inches lift to ensure superior ride quality and increased wheel travel without sacrificing towing capacity.
• 2.0 Aluminum Series Shocks: Internal Reservoir (IR) smooth body shocks provide match-tuned damping to ensure consistent performance on and off-road.
• Fixed Tubular Link Arms: Heavy-duty steel upper and lower links provide increased strength and improved alignment geometry to ensure reduced bind and better handling.
• Steering Correction: Forged pitman arm and track bar drop brackets provide corrected steering geometry to ensure minimized bump steer and proper axle alignment.
• System Durability: CAD-plated shock bodies and high-quality powder-coated steel components provide corrosion resistance to ensure long-term structural integrity.
• Installation: A direct-fit design provides a straightforward bolt-on process to ensure no drive shaft modifications are required.

Technical Specifications

Wheel & Tire Fitment

• OEM Wheels & Tires: Yes
• Aftermarket Wheels: 17×8.5 inches w/ 5.25” BS / 13mm Offset, 18×9 inches w/ 5.50 inches BS / 12mm Offset, or 20×9 inches w/ 5.50 inches BS / 12mm Offset
• Aftermarket Tires: 35 inches x 12.50 inches
• Note: 37 inches tires may fit with minor fender well trimming. Trucks with 03-06 style steering require a 4 inches drop pitman arm (not included) or an upgrade to 07-12 steering. Springs are rated for Diesel engines only.

System Components

• 214010 (qty: 1) | 03-12 RAM HD 4WD 4.5 inches DUAL RATE SPRING KIT
• 214040 (qty: 1) | 03-12 RAM HD 4.5 inches BOX KIT
• 214027 (qty: 1) | 03-12 RAM HD FIXED TUBULAR LINK KIT
• 211205 (qty: 1) | 03-12 RAM HD 4WD 2.5 inches BLOCK KIT
• 37023 (qty: 1) | 99-10 FSD DUALLY/03-12 RAM HD 15\” U-BOLT KIT
• 216523 (qty: 2) | 03-12 RAM HD 4.5 inches FRONT 2.0 VS IR
• 216522 (qty: 2) | 03-12 RAM HD 0-3 inches REAR 2.0 VS IR

Why Choose ICON Stage 1?

• Performance Engineering: Increased wheel travel and damping for superior control.
• Improved Geometry: Tubular link arms and drop brackets correct suspension cycles for a better-than-stock feel.
• Fully Serviceable: Shocks are rebuildable and revalveable for long-term performance.

Frequently Asked Questions

Are these springs compatible with gas engines?
No
