ICON 0-2.5″ Lift Kit Stage 4 for 2009-2010 Dodge Ram 1500 4WD

Description
ICON 0-2.5″ Lift Kit Stage 4 for 2009-2010 Dodge Ram 1500 4WD

ICON ICON 2009–2022 Ram 1500 4WD .75-2.5 inches Lift Stage 4 Suspension System

Part Number: K213004

Summary: The ICON Vehicle Dynamics Stage 4 suspension system for the 2009–2022 Ram 1500 4WD (including Classic models) provides a versatile .75-2.5 inches lift range designed for serious on and off-road performance. This engineered system focuses on increasing wheel travel and damping ability through vehicle-specific tuned 2.5 Series front coilovers and 2.5 Series Piggyback rear shocks. Featuring the high-articulation Delta Joint tubular upper control arms and dual-rate rear coil springs, this stage significantly enhances chassis stability and ride quality for the demanding driver.

Features

• 2.5 VS Series Coilovers: Internal reservoir design with Eibach coil springs provides exceptional cooling and superior vehicle feel through the range of travel.
• Delta Joint Upper Control Arms: Tubular steel construction with the patented Delta Joint provides high-angle articulation and durability to ensure long-term reliability.
• 2.5 Aluminum Series Rear Shocks: One-piece impact extruded aluminum cylinders provide excellent corrosion resistance to ensure consistent performance and finish.
• Dual-Rate Rear Springs: ICON-engineered 1.5 inches lift dual-rate coil springs provide improved suspension geometry to ensure a balanced ride under varying loads.
• System Durability: CAD plated coilover bodies and 6061 CNC machined aluminum components provide maximum strength to ensure protection against harsh environments.
• Installation: 100% Bolt-on design provides a straightforward upgrade path to ensure no drilling, cutting, or welding is required for installation.

Technical Specifications

Wheel & Tire Fitment

• OEM Wheels & Tires: Yes
• Aftermarket Wheels: 17×8.5 inches with 4.75” Backspace / 0mm Offset
• Aftermarket Tires: 33 inches x 11.50 inches
• Note: Larger tires may fit but fender trimming and modifications will be required. Not compatible with models equipped with OE air suspension. Compatible with 2019-2022 Ram 1500 Classic models.

System Components

• 211000 (qty: 1) | 19-UP RAM 1500 2/4WD 09-18 RAM 1500 4WD 2.5 VS IR COILOVER KIT
• 218550DJ (qty: 1) | 09-23 RAM 1500 TUBULAR UCA DJ KIT
• 212150 (qty: 1) | 09-23 RAM 1500 REAR 1.5 inches DUAL RATE SPRING KIT
• 217715P (qty: 1) | 09-18 RAM 1500 0-3 inches REAR 2.5 VS PB PAIR

Why Choose ICON Stage 4?

• Performance Engineering: Increased wheel travel and damping for superior control.
• Delta Joint Reliability: High-angle articulation with a sealed design for long-lasting off-road use.
• Fully Serviceable: Shocks are rebuildable and revalveable for long-term performance.

Frequently Asked Questions

Is this system compatible with the Ram 1500 Classic?
Yes, this system is compatible with 2019–2022 Ram 1500 Classic models, providing the same .75-2.5 inches lift range.

Can I use my factory wheels with this lift?
Yes, ICON confirms that OEM wheels and tires are compatible with this suspension system.
