ICON 0-2.5″ Lift Kit Stage 5 for 2009-2010 Dodge Ram 1500 4WD

Description
ICON 0-2.5″ Lift Kit Stage 5 for 2009-2010 Dodge Ram 1500 4WD

ICON ICON 2009–2022 Ram 1500 4WD .75-2.5 inches Lift Stage 5 Suspension System

Part Number: K213005

Summary: The ICON Stage 5 suspension system provides a versatile .75–2.5 inches lift height for 2009–2018 Ram 1500 4WD and 2019–2022 Ram 1500 Classic models. This engineered system focuses on maximizing wheel travel and damping ability through vehicle-specific tuned 2.5 Series coilovers and rear shocks equipped with ICON’s Compression Damping Control (CDC) Valve. A key differentiator for this stage is the inclusion of Tubular Steel Upper Control Arms with the Delta Joint, ensuring superior articulation and long-term durability for serious on and off-road use.

Features

• 2.5 Series Coilovers: Adjustable .75-2.5 inches lift coilovers provide increased wheel travel and damping to ensure outstanding vehicle control and ride quality.
• CDC Valve Technology: ICON Compression Damping Control Valve provides 10 levels of user-adjustable damping force to ensure optimized performance for varying terrains and cargo loads.
• Delta Joint UCA: Tubular Steel Upper Control Arms with Delta Joints provide high-angle articulation and a sealed design to ensure maximum durability and longevity.
• Dual Rate Rear Springs: 1.5 inches Dual Rate coil springs provide a balanced spring rate to ensure superior vehicle “feel” and performance front-to-rear.
• System Durability: CAD plated shock bodies with 7/8 inches shafts and 6061 aircraft-grade aluminum components provide corrosion resistance to ensure long-term structural integrity.
• Installation: 100% Bolt-on design provides a straightforward fitment to ensure no drilling, cutting, or welding is required for installation.

Technical Specifications

Wheel & Tire Fitment

• OEM Wheels & Tires: Yes
• Aftermarket Wheels: 17×8.5 inches with 4.75” Backspace / 0mm Offset (Recommended)
• Aftermarket Tires: 33 inches x 11.50 inches
• Note: Larger tires may fit but fender trimming and modifications will be required. Recommended aftermarket wheel size for specific fitments: 17×8.5 inches with 5.75” Backspace / 25mm Offset.

System Components

• 211000: 19-UP RAM 1500 2/4WD 09-18 RAM 1500 4WD 2.5 VS IR COILOVER KIT
• 218550DJ: 09-23 RAM 1500 TUBULAR UCA DJ KIT
• 212150: 09-23 RAM 1500 REAR 1.5 inches DUAL RATE SPRING KIT
• 217715CP: 09-18 RAM 1500 0-3 inches REAR 2.5 VS PB CDCV PAIR

Why Choose ICON Stage 5?

• Performance Engineering: Increased wheel travel and damping for superior control.
• Delta Joint Reliability: High-angle articulation with a sealed design for protection against the elements.
• Fully Serviceable: Shocks are rebuildable and revalveable for long-term performance.

Frequently Asked Questions

Is this system compatible with the Ram Air Suspension?
No, this system is not compatible with models equipped with OE air suspension.

Can I adjust the damping of the shocks?
Yes, the included ICON CDC Valve allows for 10 levels of quick and easy end-user adjustability to fine-tune your ride.
