Fox Factory Race Series 2.0 ATS Stabilizer for 2008-2016 Ford F-250/350 4WD Super Duty Crew Cab and Chassis

Description
Fox Factory Race Series 2.0 ATS Stabilizer for 2008-2016 Ford F-250/350 4WD Super Duty Crew Cab and Chassis

Fox Factory Race Series 2.0 ATS Stabilizer for 2008-2016 Ford F-250/350 4WD Super Duty Crew Cab and Chassis

Part Number: 983-02-144

Summary: The FOX Factory Race Series 2.0 ATS Stabilizer is engineered to eliminate unwanted steering feedback and the common push-pull forces associated with conventional stabilizers. Utilizing an Adjustable Through Shaft (ATS) architecture, this stabilizer prevents fluid displacement throughout its entire travel range. The integrated external piggyback reservoir increases fluid capacity and employs an Internal Floating Piston (IFP) to maintain consistent damping by separating nitrogen gas from the oil. Designed for the Ford Super Duty, this single bolt-on solution provides professional-grade steering control without the need for dual opposing setups.

Features

• Adjustable Through Shaft (ATS): Through-shaft architecture provides equalized pressure in both directions to ensure the elimination of unidirectional steering pull.
• External Piggyback Reservoir: Increased fluid capacity provides enhanced cooling to ensure consistent damping performance during demanding use.
• External Adjuster: 24 clicks of manual adjustment provides the ability to fine-tune steering feel to ensure the stabilizer is tailored to specific driving styles and tire setups.
• Internal Floating Piston (IFP): High-pressure nitrogen separation provides a barrier between gas and oil to ensure the elimination of fluid cavitation.
• 6061-T6 Aluminum Body: CNC machined clear anodized aluminum provides superior heat dissipation to ensure resistance to rust and corrosion over time.

Technical Specifications

Fitment

• 2008-2016 Ford F-250 Super Duty 4WD Crew Cab and Chassis
• 2008-2016 Ford F-350 Super Duty 4WD Crew Cab and Chassis
• Note: Fits 4WD models only.

What’s Included

• Sold Individually
• Integrated Tie Rod Clamp mounting hardware

Why Choose This Product?

• Engineering Advantage: The ATS architecture solves the physics-based “volume displacement” issue found in standard stabilizers, allowing for neutral steering pressure without the complexity of a dual-stabilizer bracket system.
• Performance Benefit: Drivers experience highly customizable steering resistance and the elimination of erratic feedback, resulting in a more controlled and stable front-end feel.

Frequently Asked Questions

How does the ATS architecture benefit my steering?
The Adjustable Through Shaft (ATS) eliminates the fluid displacement that typically causes a steering stabilizer to push or pull in one direction, ensuring a neutral steering feel throughout the full range of travel.

What is the purpose of the 24-click adjuster?
The external adjuster allows you to fine-tune the damping force of the stabilizer, providing 24 distinct settings to accommodate various tire sizes and driving preferences.

Does this stabilizer require a separate mounting bracket?
This unit features a built-in tie rod clamp and eyelet mount designed for a direct bolt-on installation on compatible Ford Super Duty trucks.
