Icon 2.5″ Lift Kit For 2018-2019 Jeep Wrangler JL (Stage 7)

Description
Icon 2.5″ Lift Kit For 2018-2019 Jeep Wrangler JL (Stage 7)

ICON ICON 2018-Up Jeep JL Wrangler, 2.5 inches Lift, Stage 7 Suspension System

Part Number: K22017

Summary: The ICON Stage 7 Suspension System provides a 2.5 inches lift height for the 2018–2023 Jeep Wrangler JL, engineered to drastically improve off-road performance and on-road ride quality. This comprehensive system features 2.5 Aluminum Series remote reservoir shocks and a full suite of adjustable and fixed link arms to optimize suspension geometry. By integrating dual-rate coil springs and adjustable track bars, ICON has increased wheel travel by over 30% (3 inches front and 2 inches rear) to redefine the vehicle’s off-road potential.

Features

• Wheel Travel Increase: 3 inches front and 2 inches rear additional travel provides over a 30% increase in articulation to ensure superior off-road capability.
• Dual Rate Coil Springs: Performance-tuned dual rate rates provide a comfortable street ride and increased bottom-out resistance to ensure consistent handling under various loads.
• 2.5 Aluminum Series Shocks: One-piece impact extruded aluminum cylinders provide excellent corrosion resistance and heat dissipation to ensure consistent damping performance.
• Tubular Steel Link Arms: Adjustable and fixed links with dual durometer bushings provide maximum articulation and minimal bind to ensure noise-free performance.
• System Durability: ICON 1K testing under rigorous conditions provides validated strength and tuning to ensure long-term reliability in extreme environments.
• Installation: 100% bolt-on design provides a straightforward mounting process to ensure a precise fit without permanent vehicle modification.

Technical Specifications

Wheel & Tire Fitment

• OEM Wheels & Tires: Yes
• Aftermarket Wheels: 17×8.5 inches w/ 4.5” Backspace / -6mm Offset or 18×9 inches w/ 4.5” Backspace / -12mm Offset
• Aftermarket Tires: 35 inches x 12.50 inches (37 inches x 12.50 inches with optional bump stop spacer kit PN: 22029)
• Note: Only compatible with models equipped with 3.6L V6 Pentastar engine. Not compatible with 3.6L V6 eTorque engine. 2 Door models sit slightly higher than 4 Door models but remain level.

System Components

• 22021 (qty: 1) | 18-23 JL/20-23 JT FRONT FIXED LOWER LINK KIT
• 22022 (qty: 1) | 18-23 JL/20-23 JT FRONT ADJ UPPER LINK KIT
• 22023 (qty: 1) | 18-23 JL REAR ADJ LOWER LINK KIT
• 22024 (qty: 1) | 18-23 JL REAR FIXED UPPER LINK KIT
• 22025 (qty: 1) | 18-23 JL 2.5 inches/20-23 JT 2 inches FRONT DUAL RATE SPRING KIT
• 22026 (qty: 1) | 18-23 JL 2.5\” REAR DUAL RATE SPRING KIT
• 22027 (qty: 1) | 18-UP JL/20-UP JT FRONT ADJ TRACK BAR KIT
• 22028 (qty: 1) | 18-UP JL REAR ADJ TRACK BAR KIT
• 27821P (qty: 1) | 20-23 JT/18-23 JL 2.5 inches FRONT 2.5 VS RR PAIR
• 27726P (qty: 1) | 18-23 JL 2.5 inches REAR 2.5 VS PB PAIR

Why Choose ICON Stage 7?

• Performance Engineering: Increased wheel travel and damping for superior control.
• Complete Geometry Correction: Includes front and rear adjustable track bars and a full link kit to maintain perfect axle alignment.
• Fully Serviceable: Shocks are rebuildable and revalveable for long-term performance.

Frequently Asked Questions

Can I run 37 inches tires with this system?
Yes
