ICON Stage 1 0-3.5″ Lift Kit for 2010-2023 Lexus GX460

Description
ICON Stage 1 0-3.5″ Lift Kit for 2010-2023 Lexus GX460

ICON 2010–2022 Lexus GX460 0-3.5 inches Lift Stage 1 Suspension System

Part Number: K53181

Summary: The ICON Stage 1 suspension system provides a versatile 0-3.5 inches lift range for the 2010–2022 Lexus GX460, engineered to significantly enhance both on-road handling and off-road capability. This system features vehicle-specific tuned 2.5 Series front coilovers and 2.0 Aluminum Series rear shocks for balanced damping performance. A key differentiator for the GX460 platform is the inclusion of an adjustable rear track bar, which ensures KDSS compatibility and corrects rear-end alignment after lifting.

Features

• 2.5 VS Series Coilovers: Internal reservoir design provides exceptional cooling properties to ensure consistent damping performance during extended use.
• Adjustable Lift Height: Threaded shock bodies provide 0-3.5 inches of front lift to ensure clearance for larger, more aggressive wheel and tire combinations.
• 2.0 Aluminum Series Shocks: Vehicle-specific valving and 5/8 inches shafts provide superior shock damping to ensure a balanced ride quality from front to rear.
• Adjustable Rear Track Bar: Multi-stage adjustment provides proper axle alignment to ensure KDSS compatibility and improved handling.
• System Durability: CAD plated coilover bodies and 6061 aircraft-grade aluminum components provide maximum corrosion resistance to ensure long-term reliability in harsh environments.
• Installation: Direct bolt-on fitment provides a straightforward upgrade path to ensure no cutting or welding is required for installation.

Technical Specifications

Wheel & Tire Fitment

• OEM Wheels & Tires: Yes
• Aftermarket Wheels: 17×8.5 inches w/ 4.75” Backspace / 0mm Offset, 18×9 inches w/ 5.00” Backspace / 0mm Offset, or 20×9 inches w/ 5.00” Backspace / 0mm Offset
• Aftermarket Tires: 33 inches x 11.50 inches
• Note: Larger tires may fit but fender trimming and modifications will be required. GX460 models equipped with factory rear air ride require ICON Rear Coil Conversion Kit #56110. Suspension system is KDSS compatible.

System Components

• 58646 (qty: 1) | 10-14 FJ/10-24 4RNR/10-23 GX 2.5 VS IR COILOVER KIT
• 52700 (qty: 1) | 07-14 FJ/03-24 4RNR/03-23 GX REAR 2 inches SPRING KIT
• 54200 (qty: 1) | 07-14 FJ/03-24 4RNR/03-23 GX REAR ADJ TRACK BAR KIT
• 56505 (qty: 2) | 07-14 FJ/03-24 4RNR/03-23 GX 1-3 inches REAR 2.0 VS IR

Why Choose ICON Stage 1?

• Performance Engineering: Increased wheel travel and damping for superior control.
• KDSS Integration: Specifically designed to maintain the functionality of the Lexus Kinetic Dynamic Suspension System.
• Fully Serviceable: Shocks are rebuildable and revalveable for long-term performance.

Frequently Asked Questions

Is this system compatible with the Lexus GX460 Rear Air Suspension?
Yes, however, models equipped with factory rear air ride require the additional ICON Rear Coil Conversion Kit (Part #56110) to complete the installation.

Can I use my factory wheels with this lift kit?
Yes, this system is compatible with factory wheels and tires, though aftermarket wheels with specific backspacing are recommended for optimal performance.
