ICON 0-3.5″ STAGE 3 Lift Kit with Billet UCA for 2003-2009 GX470

Description
ICON 0-3.5″ STAGE 3 Lift Kit with Billet UCA for 2003-2009 GX470

ICON 2003–2009 Lexus GX470 0-3.5 inches Lift Stage 3 Suspension System Billet UCA

Part Number: K53173

Summary: The ICON Stage 3 suspension system provides a comprehensive performance upgrade for the 2003–2009 Lexus GX470, delivering 0-3.5” of adjustable front lift height. This system features 2.5 Series extended travel coilovers paired with billet aluminum upper control arms equipped with the patented Delta Joint to maximize wheel travel and alignment precision. Additionally, this stage includes a rear coil conversion kit to replace the factory air bags, along with billet lower trailing arms for superior strength and optimized pinion angle.

Features

• Extended Travel Coilovers: 2.5-inch diameter shock bodies with internal reservoirs provide increased oil capacity for superior damping and control during aggressive off-road use.
• Delta Joint UCA: Billet aluminum upper control arms featuring the patented Delta Joint provide the high-angle articulation of a uniball with the sealed durability of a ball joint to ensure predictable handling and long-term reliability.
• Billet Lower Links: 6061 CNC machined aluminum trailing arms provide increased strength and on-vehicle adjustability to ensure optimum pinion angle and correct roll steer geometry.
• Rear Coil Conversion: The included conversion kit eliminates the factory rear air bag system to provide a consistent 2 inches lift and improved off-road articulation.
• System Durability: CAD plated shock bodies with 7/8 inches shafts and 6061 aircraft-grade aluminum components provide maximum corrosion resistance to ensure performance in harsh environments.
• Installation: A 100% bolt-on design provides a direct fitment to ensure a straightforward installation without the need for cutting or welding.

Technical Specifications

Wheel & Tire Fitment

• OEM Wheels & Tires: Yes
• Aftermarket Wheels: 17×8.5 inches w/ 4.75” BS / 0mm Offset, 18×9 inches w/ 5.00” BS / 0mm Offset, or 20×9 inches w/ 5.00” BS / 0mm Offset
• Aftermarket Tires: 33 inches x 11.50 inches
• Note: Larger tires may fit but fender trimming and modifications will be required. Suspension system is compatible with KDSS; KDSS equipped vehicles require rear track bar 54200. Front sway bar relocation brackets are not used for KDSS equipped vehicles.

System Components

• 58645 (qty: 1) | 07-09 FJ/03-09 4RNR/03-09 GX EXT TRAVEL 2.5 VS IR COILOVER KIT
• 58551DJ (qty: 1) | 07-14 FJ/03-24 4RNR/03-23 GX BILLET UCA DJ KIT
• 54000 (qty: 1) | 07-14 FJ/03-23 4RNR/08-21 LC 200/03-23 GX BILLET LOWER TRAILING ARM KIT
• 52700 (qty: 1) | 07-14 FJ/03-24 4RNR/03-23 GX REAR 2 inches SPRING KIT
• 56110 (qty: 1) | GX460/GX470 REAR COIL CONVERSION KIT
• 56505 (qty: 2) | 07-14 FJ/03-24 4RNR/03-23 GX 1-3\” REAR 2.0 VS IR

Why Choose ICON Stage 3?

• Performance Engineering: Increased wheel travel and vehicle-specific damping for superior control on and off-road.
• Delta Joint Reliability: High-angle articulation with a fully sealed
