ICON 0-3″ Lift Kit Stage 3 for 2004-2015 Nissan Titan

SKU: K83003
5 out of 5 based on 1 customer rating
(1 customer review)
ICON 0-3" Lift Kit Stage 3 for 2004-2015 Nissan Titan
ICON 0-3" Lift Kit Stage 3 for 2004-2015 Nissan Titan

Description
ICON 0-3″ Lift Kit Stage 3 for 2004-2015 Nissan Titan

ICON Nissan Titan Stage 3 Suspension System 0-3 inches Lift (2004–2015)

Part Number: K83003

Summary: The ICON Vehicle Dynamics Stage 3 suspension system for the 2004–2015 Nissan Titan is engineered to provide a significant increase in wheel travel and damping ability for the serious driver. This system features height-adjustable 2.5 Series front coilovers and 2.5 Aluminum Series piggyback reservoir rear shocks, offering a lift range of 0-3” to accommodate larger tire packages. A key differentiator in this Stage 3 kit is the inclusion of ICON’s CDC (Compression Damping Control) Valve, allowing users to fine-tune the ride stiffness for various terrains and cargo loads.

Features

  • 2.5 Series Coilovers: Vehicle-specific tuned internal reservoir shocks provide exceptional cooling and increased wheel travel to ensure superior vehicle control on and off-road.

  • ICON CDC Valve: An externally adjustable compression valve provides 10 levels of damping adjustment to ensure optimal ride quality for specific terrains or weight requirements.

  • FK Rod End Bearings: PTFE-lined spherical bearings provide minimal deflection and extended longevity to ensure precise handling under extreme conditions.

  • System Durability: CAD-plated shock bodies and 6061 CNC-machined aluminum components provide high-grade corrosion resistance to ensure long-term structural integrity.

  • Installation: A 100% bolt-on design provides a straightforward upgrade path with no cutting, drilling, or welding required to ensure a factory-clean fitment.

Technical Specifications

Specification Value
Stage Stage 3
Front Lift Range 0-3 inches
Shock Series 2.5 Series Coilover / 2.5 Aluminum Series Piggyback Rear with CDCV
UCA Type Not Included
Rear Spring Type Not Included (Compatible with OEM)

Wheel & Tire Fitment

  • OEM Wheels & Tires: Yes

  • Aftermarket Wheels: 17×8.5 inches w/ 4.75” BS / 0mm Offset, 18×9 inches w/ 5.00 inches BS / 0mm Offset, or 20×9 inches w/ 5.00 inches BS / 0mm Offset

  • Aftermarket Tires: 33 inches x 11.50 inches

  • Note: Larger tires may fit but fender trimming and modifications will be required. Coilover heights indicated are for a stock equipped vehicle.

System Components

  • 81000 (qty: 1): 04-15 TITAN 2.5 VS IR COILOVER KIT

  • 87700CP (qty: 1): 04-15 TITAN 0-1.5 inches REAR 2.5 VS PB CDCV PAIR

Why Choose ICON Stage 3?

  • Performance Engineering: Increased wheel travel and damping for superior control.

  • CDC Valve Adjustability: User-adjustable compression settings to switch between street comfort and off-road performance.

  • Fully Serviceable: Shocks are rebuildable and revalveable for long-term performance.

Frequently Asked Questions

Can I adjust the lift height after installation?
Yes, the front coilovers are height adjustable from 0-3” of lift, allowing you to level the vehicle or clear larger tires.

What does the CDC Valve do?
The Compression Damping Control (CDC) Valve allows you to manually adjust the stiffness of the shock with a simple dial, ranging from soft for daily driving to firm for high-speed off-road use.

Customer reviews

Rated 5 out of 5 stars
1 review
5 stars 1 100 %
4 stars 0 0 %
3 stars 0 0 %
2 stars 0 0 %
1 star 0 0 %

1 review for ICON 0-3″ Lift Kit Stage 3 for 2004-2015 Nissan Titan

Add a review

Use one of the allowed file type: jpg,png,jpeg.

    Questions and answers of the customers

      Does this fit 2021 titan pro4x non xd
    1. 0 votes
      Q Does this fit 2021 titan pro4x non xd
      A No it will fit for 2004-2015 Nissan Titan. For 2021 titan we can offer only https://www.suspensionlifts.com/?swoof=1&pa_vehicle-year=2021&pa_make=nissan&pa_model=titan&pa_product-type=shocks
      2. I have a 2015 pro 4x with a leveling kit in the front, extended sway arm ends and 1 inch blocks in the back. Using stock struts, rear shocks. As it is now, my upper control arms hit my strut buckets at full extension. Very loud inside. Why is this kit listed without telling people they need different upper control arms for longer travel and longer front sway bar ends?
    2. 0 votes
      Q I have a 2015 pro 4x with a leveling kit in the front, extended sway arm ends and 1 inch blocks i...... Read more
      There are no answers for this question yet.
      3. Will this fit a 2019 Nissan Titan Pro-4X?
    3. 0 votes
      Q Will this fit a 2019 Nissan Titan Pro-4X?
      A If you have Titan XD we can offer https://www.suspensionlifts.com/?post_type=product&s=ICON+titan+xd&asp_active=1&p_asid=1&p_asp_data=Y3VycmVudF9wYWdlX2lkPTI4NTgxJndvb19jdXJyZW5jeT1VU0QmcXRyYW5zbGF0ZV9sYW5nPTAmZmlsdGVyc19jaGFuZ2VkPTAmZmlsdGVyc19pbml0aWFsPTEmYXNwX2dlbiU1QiU1RD10aXRsZSZhc3BfZ2VuJTVCJTVEPWNvbnRlbnQmYXNwX2dlbiU1QiU1RD1leGNlcnB0JmN1c3RvbXNldCU1QiU1RD1wcm9kdWN0X3ZhcmlhdGlvbiZjdXN0b21zZXQlNUIlNUQ9cHJvZHVjdA==
      4. I have a 2011 Nissan Titan Pro4x Offroad. Will this work? What kits will work with that model? Is this the complete kit?
    4. 0 votes
      Q I have a 2011 Nissan Titan Pro4x Offroad. Will this work? What kits will work with that model? Is...... Read more
      A Yes, it will work. This kit lifts the front end, rear will need sobme blocks or add a leafs if you want to lift also the rear
