ICON 2.5-3″ Lift Kit Stage 1 for 2016-2024 Nissan Titan XD

Description
ICON 2.5-3″ Lift Kit Stage 1 for 2016-2024 Nissan Titan XD

ICON Stage 1 2.5-3 inches Lift Suspension System (Nissan Titan XD 2016–2023)

Part Number: K83031

Summary: The ICON Stage 1 Suspension System for the 2016–2023 Nissan Titan XD is engineered to bridge the gap between heavy-duty capability and refined ride quality. This system provides an adjustable 2.5–3 inches front lift height, specifically tuned to enhance performance for both 2WD and 4WD applications. By utilizing ICON 2.5 Series coilovers and 2.0 Aluminum Series rear shocks, this system delivers a significant 32% increase in front wheel travel while maintaining the vehicle’s original towing capacity.

Features

• 2.5 Series Coilovers: Adjustable 2.5-3 inches lift height provides increased ground clearance to ensure superior off-road capability.
• Increased Wheel Travel: Approximately 32% increased front wheel travel provides enhanced articulation to ensure better traction and control on rough terrain.
• Vehicle Specific Tuning: Custom-valved front and rear shocks provide optimized damping to ensure the best ride quality on the market.
• System Durability: CAD plated coilover bodies and 6061 CNC machined aluminum components provide maximum corrosion resistance to ensure long-term structural integrity.
• FK Rod End Bearings: Precision-grade bearings provide minimal deflection and extended longevity to ensure consistent suspension geometry.
• Installation: 100% bolt-on design provides a straightforward upgrade path to ensure no permanent vehicle modifications are required.

Technical Specifications

Wheel & Tire Fitment

• OEM Wheels & Tires: Yes
• Aftermarket Wheels: 17×8.5 inches w/ 4.75” BS / 0mm Offset, 18×9 inches w/ 5.00 inches BS / 0mm Offset, or 20×9 inches w/ 5.00 inches BS / 0mm Offset
• Aftermarket Tires: 33 inches x 11.50 inches
• Note: Larger tires may fit but fender trimming and modifications will be required. Lift heights based on 4WD Crew Cab Diesel.

System Components

• 81021 (qty: 1) | 16-23 TITAN XD 2.5 IR COILOVER KIT
• 86535 (qty: 2) | 16-23 TITAN XD 0-1.5 inches REAR 2.0 VS IR
• 88700 (qty: 1) | 16-23 TITAN XD 9 inches U-BOLT KIT
• 191201 (qty: 1) | 1 inches CAST BLOCK KIT

Why Choose ICON Stage 1?

• Performance Engineering: Increased wheel travel and damping for superior control.
• Fully Serviceable: Shocks are rebuildable and revalveable for long-term performance.
• Heavy Duty Integrity: Designed specifically for the Titan XD’s unique chassis to improve ride quality without sacrificing its 3/4-ton capability.

Frequently Asked Questions

Will this system affect my towing capacity?
No, the Stage 1 system is designed to increase ride quality over stock with no change in the vehicle’s towing capacity.

Are the shocks in this kit rebuildable?
Yes, all ICON shock absorbers are fully serviceable, meaning they can be rebuilt or re-valved to extend the life of your investment.
