ICON 2.5-3″ Lift Kit Stage 3 for 2016-2024 Nissan Titan XD

Description
ICON 2.5-3″ Lift Kit Stage 3 for 2016-2024 Nissan Titan XD

ICON 2016–2023 Nissan Titan XD 2.5–3 inches Lift Stage 3 Suspension System

Part Number: K83033

Summary: The ICON Stage 3 suspension system is a comprehensive performance upgrade designed for the 2016–2023 Nissan Titan XD, providing 2.5–3 inches of front lift height. This system focuses on bridging the gap between heavy-duty capability and ride refinement by incorporating 2.5 Series remote reservoir coilovers and rear shocks equipped with ICON’s CDC (Compression Damping Control) Valve technology. A key differentiator of this stage is the inclusion of Delta Joint upper control arms, which provide increased durability and superior articulation compared to standard ball joints.

Features

• CDC Valve Technology: ICON Compression Damping Control valves provide 10 levels of user-defined damping adjustment to ensure optimal performance across varying terrains and cargo loads.
• Increased Wheel Travel: Specialized engineering provides an approximately 32% increase in front wheel travel over stock to ensure superior off-road capability and articulation.
• Delta Joint Upper Control Arms: The patented Delta Joint provides the high-angle articulation of a uniball with the sealed longevity of a ball joint to ensure maximum durability in harsh environments.
• System Durability: CAD plated coilover bodies with 7/8 inches shafts and 6061 CNC machined components provide maximum corrosion resistance to ensure long-term structural integrity.
• Installation: A 100% bolt-on design provides a straightforward upgrade path to ensure minimal vehicle downtime and no required frame modifications.

Technical Specifications

Wheel & Tire Fitment

• OEM Wheels & Tires: Yes
• Aftermarket Wheels: 17×8.5 inches w/ 4.75” BS / 0mm Offset, 18×9 inches w/ 5.00 inches BS / 0mm Offset, or 20×9 inches w/ 5.00 inches BS / 0mm Offset
• Aftermarket Tires: 33 inches x 11.50 inches
• Note: Larger tires may fit but fender trimming and modifications will be required. Lift heights are based on 4WD Crew Cab Diesel applications.

System Components

• 81521C (qty: 1) | 16-23 TITAN XD 2.5 RR CDCV COILOVER KIT
• 88510DJ (qty: 1) | 16-23 TITAN XD UCA DJ KIT
• 87705CP (qty: 1) | 16-23 TITAN XD 0-1.5 inches REAR 2.5 VS PB CDCV PAIR
• 88700 (qty: 1) | 16-23 TITAN XD 9 inches U-BOLT KIT
• 191201 (qty: 1) | 1 inches CAST BLOCK KIT

Why Choose ICON Stage 3?

• Performance Engineering: Increased wheel travel and vehicle-specific damping for superior control on and off-road.
• Delta Joint Reliability: High-angle articulation with a sealed, service-free design for quiet operation.
• Fully Serviceable: All ICON shocks are rebuildable and revalveable for long-term custom performance.

Frequently Asked Questions

What is the ICON CDC Valve?
The CDC (Compression Damping Control) Valve is an externally adjustable valve that allows you to restrict oil flow to the reservoir, providing 10 unique settings to stiffen or soften your ride.

Can I use my factory wheels with this system?
Yes, this system is compatible with OEM wheels and tires, though aftermarket wheels are recommended for optimal clearance.
