Bilstein 5100 4-6″ Front Assembled Coilovers and 4″ Rear Lift Shocks 2011-2018 RAM 1500 4WD

Description
Bilstein 5100 4-6″ Front Assembled Coilovers and 4″ Rear Lift Shocks 2011-2018 RAM 1500 4WD

Bilstein 5100 4-6″ Front Lift Pre-Assembled Coilovers + 4″ Rear Lift Shocks – 2011-2018 RAM 1500 4WD

Part: SL5100R1500B

Level your RAM 1500 with a matched front and rear package. The front Bilstein 5100 coilovers arrive fully assembled with OE-style replacement coils and new top mounts, so you skip the spring compressor. Rear 5100 shocks are sized for 4″ rear lift components for balanced ride and control.

What’s Included

• Front (pre-assembled): 2 x Bilstein 5100 ride-height-adjustable struts utilizing Bilstein tuned shocks for SuperLift’s 6″ Lift Kits with OE replacement coils, new mounts, insulators, dust covers, and hardware
• Rear: 2 x Bilstein 5100 shocks for 4″ rear lift

Front Perch Settings (clip positions)

• Clip 5: ~6″
• Clip 4: ~5.5″
• Clip 3: ~5″
• Clip 2: ~4.5″
• Clip 1: 4″ stock

Actual lift varies with vehicle weight, bumper/winch, accessories, and spring wear.

Why You’ll Like It

• No spring compressor needed – fronts come fully assembled
• Adjustable 4-6″ front lift – dial in level stance or mild lift for tire clearance
• Bilstein 5100 control – monotube, 46 mm digressive piston for consistent, fade-resistant damping
• OE-style comfort – tighter body control while keeping daily ride quality

Front Shock Specs

• Series: 5100
• Extended length: n/a
• Collapsed length: n/a
• Design: snap-ring grooved body (coilover), monotube, nitrogen gas-charged, 46 mm piston

Rear Shock Specs

• Series: 5100
• Extended length: n/a
• Collapsed length: n/a
• Design: smooth body (non-coilover), monotube, nitrogen gas-charged, 46 mm piston
• Rear lift support: 0-1″ components (shocks do not add lift by themselves)

Fitment

• Vehicle: RAM 1500 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018
• Drivetrain: 4WD only
• Exclusions: will not work on trucks with the TRX package
• Height ranges: front adjustable 4-6″; rear shocks matched to 4″ rear lift components

Processing Time

• Coilover assembly time: Depends on availability. Average: 3 Days

Technical Notes

• Multiple snap-ring grooves set spring seat height within the stated range
• Monotube design with self-adjusting deflective-disc valving increases wheel travel and improves handling
• Alignment is required after installation
• Tire clearance depends on wheel width and offset – verify after install

FAQ

Do these come assembled? Yes – new coils, mounts, and hardware are installed up front.

Which clip should I choose? Clip 1 for 4″, Clip 5 for 6″ for a typical level; adjust based on added front weight and desired rake.

Will the rear shocks lift my truck? No – they are sized and valved to work with up to 1″ rear lift springs or spacers.
