ICON 4.5″ Lift Kit Stage 1 for 2014-2018 RAM 2500 4WD

Description
ICON 4.5″ Lift Kit Stage 1 for 2014-2018 RAM 2500 4WD

ICON Ram 2500 4WD Stage 1 4.5 inches Lift Suspension System (2014–2018)

Part Number: K214521

Summary: The ICON Stage 1 suspension system for the 2014–2018 Ram 2500 4WD is engineered to provide a 4.5 inches lift height while significantly enhancing ride quality and vehicle control. This system features ICON-engineered dual-rate coil springs and vehicle-specific 2.0 Aluminum Series shocks to deliver balanced damping for daily driving, towing, and light off-road use. By utilizing high-strength laser-cut bracketry and an adjustable track bar, this kit ensures a level stance and proper axle alignment without compromising factory towing capacity.

Features

• Dual-Rate Coil Springs: ICON-engineered 4.5” dual-rate springs provide exceptional vehicle control over varying terrain to ensure a smooth street ride and increased performance off-road.
• 2.0 Aluminum Series Shocks: Vehicle-specific tuned front and rear internal reservoir shocks provide superior damping and heat dissipation to ensure consistent ride quality.
• Adjustable Track Bar: The included high-strength adjustable track bar provides proper centering of the front axle to ensure correct suspension geometry and handling.
• System Durability: Laser-cut bracketry and billet bump stop spacers provide high-strength reinforcement to ensure long-term structural integrity under heavy-duty use.
• Installation: This direct-fitment system provides all necessary hardware to ensure a complete and straightforward installation process.

Technical Specifications

Wheel & Tire Fitment

• OEM Wheels & Tires: Yes
• Aftermarket Wheels: 17×8.5 inches w/ 5.25” Backspace (13mm Offset), 18×9 inches w/ 5.50 inches Backspace (12mm Offset), or 20×9 inches w/ 5.50 inches Backspace (12mm Offset)
• Aftermarket Tires: 37 inches x 12.50 inches
• Note: Larger tires may fit but fender trimming and modifications will be required. Springs are rated for Diesel engines only. Not compatible with rear factory air ride. Vehicles with 2-piece driveshafts require carrier shim kit 214211.

System Components

• 214201 (qty: 1) | 14-UP RAM 2500 4.5 inches FRONT DUAL RATE SPRING KIT
• 214214 (qty: 1) | 14-UP RAM 2500 FRONT ADJUSTABLE TRACK BAR KIT
• 214205 (qty: 1) | 14-UP RAM 2500 4.5 inches BOX KIT
• 216530 (qty: 2) | 14-UP RAM HD 4.5 inches FRONT LIFT 2.0 VS IR
• 216531 (qty: 2) | 14-UP RAM HD 2 inches REAR LIFT 2.0 VS IR

Why Choose ICON Stage 1?

• Performance Engineering: Increased wheel travel and damping for superior control without sacrificing towing capacity.
• Level Stance: Corrects the factory rake for a more aggressive look and improved ground clearance.
• Fully Serviceable: Shocks are rebuildable and revalveable for long-term performance and custom tuning.

Frequently Asked Questions

Will this kit affect my Ram 2500’s towing capacity?
No, this ICON system is designed to increase wheel travel and ride quality with no change in the vehicle’s factory towing capacity.

Are the shocks in this system serviceable?
Yes, the ICON 2.0 Aluminum Series shocks are fully serviceable, meaning they can be rebuilt or revalved by ICON to extend their lifespan.
