ICON 4.5″ Lift Kit Stage 3 for 2014-2018 RAM 2500 4WD

Description
ICON 4.5″ Lift Kit Stage 3 for 2014-2018 RAM 2500 4WD

ICON 2014–2018 Ram 2500 4WD Stage 3 4.5 inches Suspension System

Part Number: K214523

Summary: The ICON Stage 3 suspension system provides a 4.5 inches lift height for the 2014–2018 Ram 2500 4WD, specifically engineered to enhance ride quality and off-road capability without sacrificing towing capacity. This system features ICON-engineered dual-rate coil springs and 2.5 Aluminum Series remote reservoir shocks for maximum heat dissipation and damping consistency. A key differentiator of the Stage 3 system is the inclusion of CDC (Compression Damping Control) Valve technology, allowing users to manually adjust shock compression characteristics to suit varying terrain and payloads.

Features

• CDC Valve Technology: External adjustment knob provides 10 levels of compression damping control to ensure optimized performance for daily driving, towing, or high-speed off-road use.
• Dual-Rate Coil Springs: ICON-engineered 4.5 inches dual-rate springs provide a soft initial rate for street comfort and a firmer secondary rate to ensure exceptional vehicle control over varying terrain.
• 2.5 Aluminum Series Shocks: One-piece impact extruded aluminum cylinders provide excellent corrosion resistance and superior heat dissipation to ensure consistent damping performance.
• Adjustable Track Bars: Front and rear adjustable track bars provide proper axle alignment to ensure precise handling and steering geometry.
• System Durability: High-strength laser-cut bracketry and billet bump stop spacers provide increased structural integrity to ensure long-term reliability in harsh environments.
• Installation: A complete direct-fitment hardware kit provides a comprehensive solution to ensure a straightforward installation process.

Technical Specifications

Wheel & Tire Fitment

• OEM Wheels & Tires: Yes
• Aftermarket Wheels: 17×8.5 inches w/ 5.25” BS / 13mm Offset, 18×9 inches w/ 5.50 inches BS / 12mm Offset, or 20×9 inches w/ 5.50 inches BS / 12mm Offset
• Aftermarket Tires: 37 inches x 12.50 inches
• Note: Larger tires may fit but fender trimming and modifications will be required. Springs are rated for Diesel engines only. Not compatible with rear factory air ride.

System Components

• 214201 (qty: 1) | 14-UP RAM 2500 4.5 inches FRONT DUAL RATE SPRING KIT
• 214214 (qty: 1) | 14-UP RAM 2500 FRONT ADJUSTABLE TRACK BAR KIT
• 214204 (qty: 1) | 14-UP RAM 2500 REAR ADJUSTABLE TRACK BAR KIT
• 214205 (qty: 1) | 14-UP RAM 2500 4.5 inches BOX KIT
• 217803CP (qty: 1) | 14-UP RAM 2500 4.5 inches FRONT 2.5 VS RR CDCV PAIR
• 217707CP (qty: 1) | 14-UP RAM 2500 2 inches STANDARD REAR 2.5 VS PB CDCV PAIR

Why Choose ICON Stage 3?

• Performance Engineering: Increased wheel travel and damping for superior control and decreased body roll.
• Adjustable Damping: The CDC Valve allows for instant adjustment between soft street settings and firm off-road or towing settings.
• Fully Serviceable: Shocks are rebuildable and revalveable for long-term performance and custom tuning.

Frequently Asked Questions

Will this kit affect my Ram 2500’s towing capacity?
No, this ICON system is designed to increase wheel travel and ride quality with no change in factory towing capacity.

Is this system compatible with Gas engines?
The coil springs in this specific kit (214201) are rated for Diesel engines only.
